Capetune TUTA-GW2 User Manual

3g video alarm camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TUTA-GW2
3G VIDEO ALARM CAMERA

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TUTA-GW2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Capetune TUTA-GW2

  • Page 1: User Manual

    TUTA-GW2 3G VIDEO ALARM CAMERA User Manual...
  • Page 2 It will therefore detect any unauthorized entry into your house and notify you via SMS, MMS, video calls or E-mail. All services and functions need to be supported by the GSM and WCDMA network and a SIM/USIM card. This brochure suits for TUTA-GW2 model.

  • Page 3: Table Of Contents

    Chapter 1 Features and accessories ......................7 1.1 Main functions ........................7 1.2 Package contents ........................ 7 1.3 TUTA-GW2 host instruction ....................8 1.4 Light indicator ........................8 Chapter 2 Installation ............................ 9 2.1 Install the SIM/USIM card ....................9 2.2 Extending the camera’s base board ..................
  • Page 4 （Version:V1.4) TUTA-GW2 user manual 5.1.1 Warning tone upon alarm triggering (Default) ............... 24 5.1.2 No warning tone upon alarm .................... 24 5.1.3 No SMS notification upon alarm ..................24 5.1.4 SMS notification upon alarm (Default) ................24 5.1.5 No MMS notification upon alarm ..................24 5.1.6 MMS notification upon alarm (Default) ................

  • Page 5: For Your Safety

    （Version:V1.4) TUTA-GW2 user manual 1. Purchase a SIM/USIM card (mobile phone card) from 3G network service and install it in the camera. This SIM/USIM card number is referred as camera number on this brochure. 2. User should activate the MMS function and Caller ID Presentation function of SIM/USIM card, and deactivate PIN code of the SIM/USIM card.
  • Page 6 （Version:V1.4) TUTA-GW2 user manual 4. We hold no responsibility for any loss of data or income; or any special, incidental, consequential or indirect damages howsoever caused. 5. The contents of this document are provided “as is”. Except as required by applicable law, no warranties of any kind, either expressed or implied, including, but not limited to the accuracy, reliability or contents of this document.

  • Page 7: Chapter 1 Features And Accessories

    （Version:V1.4) TUTA-GW2 user manual Chapter 1 Features and accessories 1.1 Main functions • Multi-mode alarm: Camera can send alarm notification in 4 ways – send to mobile phone by SMS, MMS and video phone-call (Need 3G network support), also can send photos to E-mail address.

  • Page 8: Tuta-Gw2 Host Instruction

    （Version:V1.4) TUTA-GW2 user manual 1.3 TUTA-GW2 host instruction Figure 1: TUTA-GW2 camera Instructions 1． SIM/USIM card Slot（rubber cover） 7. Power Interface (Mini USB) 2． Camera 8. Line Holder 3． Infrared lights（8 pcs） 9. Slot buckle 4． Microphone 10. Hanging hole 5．...

  • Page 9: Chapter 2 Installation

    （Version:V1.4) TUTA-GW2 user manual Color Action Status Light two seconds Successfully reset factory setting. Note: 1.Slow flashes 1 time per second, quick flashes 2 times per second. 2. Under normal working conditions, the indicator can be closed absolutely: Under normal working conditions, press SET key for 5-10 seconds, the indicator will open/close.

  • Page 10: Mount The Camera

    （Version:V1.4) TUTA-GW2 user manual resuming the use of external power source.” • Low battery: The configure setting can not be saved when the camera is operating on low battery. 2.4 Mount the camera The camera can be mounted on a wall (vertically with the screws) or put down on any suitable horizontal surface.

  • Page 11: Chapter 3 Define The User

    （Version:V1.4) TUTA-GW2 user manual Chapter 3 Define the user 3.1 User Authorization level • There are two levels, each with a different password and authorization level, namely Administrator and Operators. Both’s authority is realized by password. • Default password for operators is 1234, for administrator is 5678.

  • Page 12: Define Alarm Number

    （Version:V1.4) TUTA-GW2 user manual 1. All the SMS commands are composed with password and words, password must be input before the words for each command. Different passwords have different authority.(See Appendix: SMS command list) 2. Administrator and operator users’ SMS command format: password commands 3.

  • Page 13: Chapter 4 Basic Use And Settings

    （Version:V1.4) TUTA-GW2 user manual Change the administrator password: OldAdminPswd change admin passcode NewAdminPswd Change the operator password: OldOprtPswd change password NewOprtPswd • The NewAdminPswd and NewOprtPswd are four digit numbers. • The original OldAdminPswd is 5678. • The original OldOprtPswd is 1234.

  • Page 14: E-Mail Settings

    （Version:V1.4) TUTA-GW2 user manual Ì Method Set MMS parameters: PSWD MMS param URL,ConnectionType,Proxy,Port,DataAccountID For example: 1234 MMS param http://mmsc.monternet.com,1,10.0.0.172,80,0 • The URL should be the MMS center URL address of GSM/WCDMA provider. • ConnectionType should be the code of connection type when sending MMS...

  • Page 15: Add/ Modify An E-Mail Address For Sending Image

    （Version:V1.4) TUTA-GW2 user manual • If the user wishes receiving image by an appointd E-mail address when needed, see 4.4.2 send image to E-mail address. • If the user wishes the camera sending the alarm image to appointed E-mail address, see 5.1.10 MMS notification to pre-set E-mail address.

  • Page 16: Send Image To E-Mail Address

    （Version:V1.4) TUTA-GW2 user manual • ImageQuantity should be in the range of 1-6. But the actual images quatity depends on the history image qantity storaged on the camera TF memory card, because the camera can send maximum all history images on memory card and one on-spot image to email box.
  • Page 17 （Version:V1.4) TUTA-GW2 user manual 2. Type in the password: After connecting with the camera, your mobile phone will show password dialog box (see following picture), 4 digits valid password must be input for continuing. Mobile phone keys of the video calling menu are as bellows:...
  • Page 18 （Version:V1.4) TUTA-GW2 user manual 3. Watch the on-spot vide: If the input password is verified correctly, users can watch and control the on-spot video through following keys on mobile phone: DTMF(KEY) Functions for video calling Reduce Enlarge Enter menu Motor turns upward...

  • Page 19: Listen In The Monitoring Area

    （Version:V1.4) TUTA-GW2 user manual Modifying user’s password interface: 4.6 Listen in the monitoring area 4.6.1 Call the camera and listen in Ì Method The user calls the camera with any mobile phone after which it will beep for inputting password. If the input password is verified correctly, users can listen to the on-spot monitoring area.

  • Page 20: Infrared Body Detector

    （Version:V1.4) TUTA-GW2 user manual answering the call. • If the alarm number user does not answer the call, the camera will redial the for two times. 4.7 Infrared body detector & Description When the camera is working under arming mode, if someone approaches to the detecting area, the built-in infrared body detector will trigger the camera alarm as preset ways.

  • Page 21: Arming Or Disarming The Camera

    （Version:V1.4) TUTA-GW2 user manual Ì Method The user sends following SMS message in order to: Deactivate motion detection (default setting): PSWD motion off (15) Activate motion detection: PSWD motion on (16) • The PSWD should be four digit numbers password.

  • Page 22: Check Status

    （Version:V1.4) TUTA-GW2 user manual 4.10 Check status & Description The user can check camera memory card by computer, check camera working status by mobile phone. Ì Method Check memory card by computer: Connect the camera with computer via USB cable; make sure the camera is in turn-on status.

  • Page 23: Chapter 5 Advanced Settings

    （Version:V1.4) TUTA-GW2 user manual factory setting (clear of all users’ setting), and resume to regular work status. • After the camera is reset, it will need to reset the alarm number. Refer to chapter 3.2 Define alarm number. Note This function needs to be used carefully as it also erases the setting values.

  • Page 24: Warning Tone Upon Alarm Triggering (Default)

    （Version:V1.4) TUTA-GW2 user manual 5.1.1 Warning tone upon alarm triggering (Default) PSWD beep on (21) • For example：1234 beep on • After successful set, the camera will sound “Di…” tone when alarming. If warning tone and phone call are set at the same time, warning tone will close once the phone goes through.

  • Page 25: Call Notification Upon Alarm (Default)

    （Version:V1.4) TUTA-GW2 user manual 5.1.8 Call notification upon alarm (Default) PSWD make call on (28) • For example：1234 make call on • Note: The camera will make video call first to alarm number, if video call doesn’t work, it will make voice call. If the video call function is closed, the camera will make voice all directly.

  • Page 26: Recording Function

    （Version:V1.4) TUTA-GW2 user manual 5.2 Recording function & Description The camera must be with TF card to realize this function. When the recording function is set, camera will save the images and video in TF card to users to check the on-spot recording. Image and video can’t be taken simultaneously.

  • Page 27: Chapter 6 Maintenance

    （Version:V1.4) TUTA-GW2 user manual • A Driver Program needs to be installed on computer before you check the recording. Installing instructions please refer to the attached disk. • After the driver software is installed, connect the camera with computer via USB...

  • Page 28: Appendix: Sms Commands List

    （Version:V1.4) TUTA-GW2 user manual General Trouble Possible Reason Solution parameters setting. and set the parameters according to SMS commands list. Camera or operating mobile Contact network provider to active phone is not with WCDMA SIM card function. Pay for the Camera can’t connect...
  • Page 29 （Version:V1.4) TUTA-GW2 user manual Category Function Command User (6)PSWD data account Data Set data account Operator DataAccountID,APN,AuthorType,UserName,Pas account sword Add/modify a Operator receiving E-mail (7) password email address Email address E-mail password email param AccountName, settings Add/modify a AccountAddress, UserName,...
  • Page 30 （Version:V1.4) TUTA-GW2 user manual Category Function Command User No SMS notification Operator (23) PSWD send sms off upon alarm SMS notification Operator (24) PSWD send sms on upon alarm (Default) No MMS notification Operator (25) PSWD send mms off upon alarm...
