SS8IO-3
8 Channel Audio Interface
User's Manual
Revision 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS8IO-3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Soundscape SS8IO-3

  • Page 1 D I G I T A L A U D I O W O R K S T A T I O N S SS8IO-3 8 Channel Audio Interface User’s Manual Revision 1.0...
  • Page 2 Information in this document is subject to change without notice and does not represent a commitment on the part of Soundscape Digital Technology Ltd. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose without the express permission of Soundscape Digital Technology Ltd or Sydec NV.

  • Page 3: Front Panel

    TDIF interfaces as standard. Examples of these include the popular Yamaha 02-R and 03-D consoles. The components used in the SS8IO-3 for analogue input and output are of the highest quality, ensuring that in this very important area, the audio performance is excellent. The 20 bit analogue to digital (AD) and digital to analogue (DA) converters are from AKM and are well known as providing superior quality digital audio conversion.

  • Page 4: Technical Specifications

    Soundscape SS8IO-3 8 Channel Audio Interface The SS8IO-3 rear panel has 8 unbalanced analogue inputs and outputs, all with RCA/cinch connectors. A standard female 25-way sub-D connector for the TDIF port is also provided, with two RCA (cinch) connectors for generating or receiving external Wordclock or Superclock.

  • Page 5: Main Operation

    TDIF connector on the mixtreme PCI Card or SSHDR1-Plus unit. Normally the TDIF Clock setting should be used for the SS8IO-3, as the SSHDR1-Plus or mixtreme PCI Card would be set to Internal Clock and so would determine the sample rate.
  • Page 6 Soundscape SS8IO-3 8 Channel Audio Interface TDIF Out selects the type of wordclock that is generated for the TDIF interface port. Revision 1.0a...

  • Page 7: Test Mode

    Soundscape SS8IO-3 8 Channel Audio Interface The settings are shown from left to right, so for example, Switch 2 (SyncOut1) is set to ‘0’ (up) and Switch 3 (SyncOut0) is set to ‘1’ (down), so reading both switches gives 01.
  • Page 8 Soundscape SS8IO-3 8 Channel Audio Interface Press any button. Step 3: The Unit is now in "firmware revision" mode. The value is shown on LED's ch#1..8(red). Revision 1.0 : off/off/off/on/off/off/off/off Revision 1.1: off/off/off/on/off/off/off/on high nibble low nibble S.RATE CLOCK Press any button.
  • Page 9 Soundscape SS8IO-3 8 Channel Audio Interface INDEX SS8IO-3 8 Channel Audio Interface Front Panel Rear Panel Technical Specifications Main Operation S. RATE CLOCK Using the SS8IO-3 with the mixtreme PCI Card or SSHDR1-Plus Rear Panel Settings OPTION 8-Way DIL Switch Test Mode Revision 1.0a...
