XX123-00-02
AURC-NIU NETWORK INTERFACE UNIT FOR
AURORACORD DIGITAL RECORDER
Copyright © 2003 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
Windows is a trademark of Microsoft Corp.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: +44 (0) 1489 566300 WEB: www.vicon-cctv.com
Vicon part number 8009-8123-00-02
Section 4 Rev 203
Advertisement
Table of Contents
Related Manuals for Vicon XX123-00-02
Summary of Contents for Vicon XX123-00-02
- Page 1 Copyright © 2003 Vicon Industries Inc. All rights reserved. Product specifications subject to change without notice. Vicon and its logo are registered trademarks of Vicon Industries Inc. Windows is a trademark of Microsoft Corp. VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788...
-
Page 5: Quick Installation
Quick Installation Connections to Install the IPInstaller Quick Installation • • i XX123-00-02 Rev 203 Network Interface... -
Page 6: Connections For Operation
Connections for Operation Standalone ii • • Quick Installation XX123-00-02 Rev 203 Network Interface... - Page 7 Network Quick Installation • • iii XX123-00-02 Rev 203 Network Interface...
-
Page 9: Installation
Manual XX091 for operating instructions for the AurorAcorD recorder. Installation Unpacking and Inspection All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to deliver the equipment in the same condition as it left the factory. Inspection For Visible Damage Immediately inspect the cartons upon delivery. -
Page 10: Product Overview
LED indicators. Refer to Figure 2 and Table 2 for those functions. A basic knowledge of Windows™ platform and networking is required to install and operate the unit. Vicon recommends that the GUI be loaded onto a freshly loaded operating system. Vicon recommends using Windows 2000, ME or XP operating systems. -
Page 11: Downloading Applications
2. Click once on the drive directory icon to select it. Two files will appear in the directory. 3. Copy and paste the file named IPInstaller.exe and place it on your desktop. See Figure below. 4. Double click on the file named Vicon DVR; the Vicon DVR application will self-install onto the PC. See Figure below. - Page 12 IP Setting to the connected AURC-NIU. Keep a permanent record of this address. e. IP Install: If IPInstaller.exe was successfully completed, the following message is displayed: IP installation is completed You must restart the server (Note: the server is the AURC-NIU) 4 • • Installation XX123-00-02 Rev 203 Network Interface...
- Page 13 NIU, it may indicate that there is “No Reply from…”, however a reply could take as long as 60 seconds before it will echo back “Reply from…” This is a normal response. Installation • • 5 XX123-00-02 Rev 203 Network Interface...
- Page 14 HUB, disconnect the Ethernet connection to the PC and connect a standard (non-crossover) Cat5e cable from the Ethernet port on the AURC-NIU to the Ethernet port on the HUB/switch. 6 • • Installation XX123-00-02 Rev 203 Network Interface...
-
Page 15: Operation
Refer to the AurorAcorD instruction manual, XX091, for basic operating instructions using the front panel keyboard. Double click the Vicon DVR icon on your desktop to launch the GUI. See below. The following screen will display. (Note: The PC monitor settings must be 1024 x 768 pixels (minimum) and color setting equivalent to 32 bit for screen image to display correctly.) - Page 16 AURC-NIU and give it a name. Click Connect. The Login screen will display, as shown below. From the drop down list, select admin; the default password is “vicon”. Click OK. Note: If multiple AURC-NIUs are connected to the system, and IP addresses have been programmed in them, they all can be added to the Site List at this time.
- Page 17 Frame choices include 5, 4, 3, 2, or 1 frame per 1 second. Image Record: Use to take a “snapshot” of an image. Click Save to record. Operation • • 9 XX123-00-02 Rev 203 Network Interface...
- Page 18 Account: Click the Account Management tab to add users with unique passwords; click the Change Password tab to change the current administrator password. If password is forgotten, refer to Preset Button section of the manual. 10 • • Operation XX123-00-02 Rev 203 Network Interface...
- Page 19 Operation • • 11 XX123-00-02 Rev 203 Network Interface...
-
Page 20: Preset Button
Resets Video Setup to NTSC, 640 x 240, normal. • Clears all the user accounts and passwords; user reverts to “admin” and password reverts “vicon” It is important to note that a result of using the PRESET button is that the next time (no matter how long after the action) the unit is powered down and then powered up after pressing the PRESET button;... -
Page 21: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. -
Page 22: Coaxial Cable Recommendations
Coaxial Cable Recommendations Caution: Careful selection of proper cable is essential to obtain the b est performance from this equipment. Vicon assumes no responsibility for poor performance when cables other than those recommended, or equivalent, are installed. In all cases, coaxial cable impedance should be 75 ohms. -
Page 23: Technical Information
Data Bits: 8. Parity/Stop Bits: none/1. VIDEO PERFORMANCE Image Compression: Method: JPEG compression. Compression Level: Resolution: 640 x 480, 640 x 240, 320 x 240. Performance: 30 frames/sec @ 320 x 240. Technical Information • • 15 XX123-00-02 Rev 203 Network Interface... - Page 24 Depth: 3.7 in. (95 mm). Weight: 0.9 lb (400 g). Finish: Black. ENVIRONMENTAL Operating Temperature Range: 32 to 122° F (0 to 50° C). Humidity: Up to 90% relative, noncondensing. 16 • • Technical Information XX123-00-02 Rev 203 Network Interface...
- Page 25 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Brussels Office Planet II - Unit E...
- Page 26 18 • • Technical Information XX123-00-02 Rev 203 Network Interface...
