Summary of Contents for swiss pro CLIMA PISO
- Page 1 HOT & COLD WATER PURIFIER CLIMA PISO User Manual 15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357 Tel +65-6276’1005 ,Fax +65-6276’1006 www.swisspro.sg info@swisspro.sg...
-
Page 2: Table Of Contents
CONTENTS: Instructions related with power ------------------------------------------------------- 2 Installation Instruction ------------------------------------------------------------------- 3 How to use ---------------------------------------------------------------------------------- 4 Life span of the filters -------------------------------------------------------------------- 8 Basic Troubleshooting--------------------------------------------------------------------- 9 Specification -------------------------------------------------------------------------------- 11 Filter Elements ------------------------------------------------------------------------------ 13 MESA PISO 15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357 Tel +65-6276’1005 ,Fax +65-6276’1006 www.swisspro.sg info@swisspro.sg... -
Page 3: Instructions Related With Power
Please read the instruction contained in this manual carefully to avoid misuses and injury. Instructions related with Power Use only AC 240V and do not Do not touch or pull the cord with modify the power cord without wet hands. permission. -
Page 4: Installation Instruction
Installation Instructions DON’T Install the product at least 10 mm Do not disassemble and repair distance away from the wall without permissions. Install the product on the flat and Do not impact or apply force to the firm surface. product Keep the product away from water Do not twist or snap the inlet hose or moist area. -
Page 5: How To Use
Other Instructions Let the purified water to flow out over 20L at the first time use after installation or if the product is not been used for a long time. Use only genuine parts and filters by us for installation and replacement. - Page 6 How to use the hot water child safety lock Push to release the child safety lock Release to activate child safety lock Removing Filters Set (MESA) *We strongly advise to engage service center for experienced personnel for filter replacement (1) Disconnect the power plug and (2) Unscrew the top cover at the close the valve connected with back of the system.
- Page 7 Removing Filters Set (PISO) *We strongly advise to engage service center for experienced personnel for filter replacement (1) Turn off & disconnect the (2) Push down the bottom cover to power plug. Close the water valve open and access the filter set. connected to the dispenser.
- Page 8 Removing Filters Set – cont. (4)(a) To disconnect the hoses from (4)(b) Then apply pressure to the the valves, firstly to take out the valve to loosen the hose. locking clips at the valve. (4)(c) And at the same time pull (5) Once at the sink, open the filter the hose out.
-
Page 9: Life Span Of The Filters
Filter System Life span of Filters The life span might be varies depending on water quality and usage. • Filter Prefilter Carbon Filter Ceramic Filter Lifespan 9 – 12 months 9 – 12 months 2 – 3 years 15, Jalan Kilang Barat, #06-01 Frontech Centre, Singapore 159357 Tel +65-6276’1005 ,Fax +65-6276’1006 www.swisspro.sg info@swisspro.sg... -
Page 10: Basic Troubleshooting
Basic Troubleshooting Please check below for troubleshooting. If the problem persists, please contact and inquire to the authorized service center. Symptom Cause Measure Temperature of Supplied power Check supplied power is 240V, and if not, hot water is low is low. adjust power to 240V. - Page 11 Symptom Cause Measure Water Leakage Joints are Close the main valve connected to the defective tap and turn off power. Contact service center. Bad taste or odor Carbon filter is Replace Carbon filter and drain at least is present reaching its 10 L of water before use.
-
Page 12: Specification
MESA PISO Specifications Country of Origin South Korea Dimension 340 (W) x 375 (D) x 1100 (H) – PISO 340 (W) x 375 (D) x 530 (H) – MESA Heating & Cooling Storage Capacity 10 L / hr (Hot) 22 L / hr (Cold) Cold Water Temperature C ~ 12 Hot Water Temperature... -
Page 13: Filter Elements
3 Steps Swisspro Filter Process Filter Elements Step 1: Prefilter Step 2: Carbon Filter It works effectively against suspended solids Is a high performance activated carbon filter that are more than 5 micron, such as rust that removes other organic contaminants & and/or sand particles, without any use of heavy metals such as Lead.
