DATEC DPP-350 Programmer's Manual page 22

1 DATECS DPP-350
44. Specifying / Canceling highlighting (ESC G)
Code: [1Bh] + [47h] + n
Same as command ESC E.
45. Specifying / Canceling Italic Print (ESC I)
Code: [1Bh] + [49h] + n
n can be from 0 to 255, but only the least significant bit is of significance.
Value 0: Normal Print
Value 1: Italic Print
46. Printing and Paper Feed n/203 inches (ESC J)
Code: [1Bh] + [4Аh] + n
n can be from 0 to 255.
Prints data in the print buffer and feeds paper by n/203 inch.
• This function is temporary and does not affect the feed operation thereafter.
• The beginning of the line is to be considered as the next printing start position.
47. Selecting page mode (ESC L)
Code: [1Bh] + [4Ch]
The command switches from standard mode to page mode. In this mode the printing is not immediately,
but is accumulated in a reserved for this purpose memory area. The resulting image is printed using one
of the commands ESC FF, GS FF or GS Z.
The page area is the maximum (576 x 2432 dots for wide paper or 408x 2432 dots foe narrow paper) or
the result of the last executed command ESC W.
The print direction is the default (left to right) or the result of the last executed command GS T.
The current print position is (0, 0) depending on the selected print direction.
The command is not valid in page mode.
The command is supported in firmware version 1.42 or higher.
48. Reading programmed serial number (ESC N)
Code: [Bh] + [4Eh]
The command returns the programmed serial number of the printer as an ASCIIZ string. Number length
is 13 characters. If no serial number is programmed, then only one symbol is returned - 00h.
Note:
The command is present in firmware versions 1.09 or newer.
49. Selecting Country (ESC R)
Code: [1Bh] + [52h] + n
n can be from 0 o 13 and has the following meaning:
N Character Set
0
U.S.A.
1
France
23 24 40 5B
h h h h
# $ @ [
# $ à º
22
Programmer's manual VER.1.50
Changed characters
5C 5D 5E 60
h h h h
\ ] ^ `
¢ § ^ `
7B 7C 7D 7E
h h h h
{ | } ~
é ù è ¨
