www.cdlxkj.com
-Networking alarm transmission: alarms and video can be sent to the security center via IP/ADSL; 3G/Wi-Fi optional;
-Video monitoring & control camera's rotation via 2G/3G smart phone (ANDROID\SYMBIAN\IOS, etc. supported);
-H.264 video compression format; support dual-stream (D1 SD704 * 576 & CIF352*288);
-Adjustable frame rate (1-30);
-Built-in PTZ, H270°/V110° rotation;
-Video-Recording into your PC, via software;
-Video-Recording into TF card (4-32GB supported);
-Remote monitoring and voice warning functions: can shout to the intruder directly;
-Support 485 PTZ port (PELCO, etc. protocol supported);
-Max. 90 wireless zones supported;
-Low light level infrared cameras.
TEL: +86-28-87 86 88 80
Features Overview
Wiring Information
Light Activated Switch: Turn on/off
infrared lamp based on surrounding light
level;
Infrared Lamp: Night vision range is 5-
10meters;
LED light: green flashing for disarming
status/ off for arming status;
Camera: Standard 3.66mm
SUNEYE Investment & Holdings (HK) Co., Ltd.
Chengdu Ideal Technology Development Co., Ltd.
SY9502 Alarm Camera & Control Panel
User Manual
-TF card slot
-USB port for
external 3G/WiFi
-RS485 port
-PC programming
-10/100M
ethernet port
-Antenna
-Power
Advertisement
Table of Contents
Summary of Contents for Suneye SY9502
- Page 1 User Manual SUNEYE Investment & Holdings (HK) Co., Ltd. Chengdu Ideal Technology Development Co., Ltd. www.cdlxkj.com TEL: +86-28-87 86 88 80 SY9502 Alarm Camera & Control Panel Features Overview -Networking alarm transmission: alarms and video can be sent to the security center via IP/ADSL; 3G/Wi-Fi optional;...
- Page 2 Installation Information 1. Pls kindly check the TF card slot, and insert proper TF card for video-recording 2. Connecting the internet via IP ethernet or external 3G modem 3. Connect the USB cable with PC to program 4. Don't forget the AC power supply CMS Information Installing on the phone: 1.
- Page 3 For example Camera HTTP Port TCP Port 10.6.0.10 8080 34570 10.6.0.11 8081 34571 10.6.0.12 8082 34572 2.1 System Settings of the camera: set the HTTP and TCP port 2.2 After camera settings, pls kindly do virtual server setting of the router 2.3 Visit 'http:// 124.90.159.61:8080' etc.
