Introduction
Thank you for having chosen a Univox
Please read this user guide carefully before installation and use of this product.
A digital to analog converter is a product that converts digital audio signals into
analog audio. It can be used if you have a loop amplifier, wireless headset or
neckloop that does not have a digital input.
First, check that your audio equipment works properly and then turn it off before
installation.
The package contains
•
HDA-2M digial to analog converter (1.)
•
Optical cable (2.)
•
Power adaptor (3.)
In some product packages there is also an audio cable included.
(1.)
Univox® HDA-2M
Digital to Analog Converter
product. We hope you will be satisfied!
®
(2.)
Part No 281041
User Guide
(3.)
1
Advertisement
Table of Contents
Summary of Contents for Univox HDA-2M
- Page 1 Digital to Analog Converter Part No 281041 User Guide Introduction Thank you for having chosen a Univox product. We hope you will be satisfied! ® Please read this user guide carefully before installation and use of this product. A digital to analog converter is a product that converts digital audio signals into analog audio.
- Page 2 Overview Optical cable Audio cable Connect the converter to the TV 1. Remove the plastic cover from the connectors on the optical cable. Picture shows the connectors when the covers are removed. 2. Connect to Toslink input on the connector and to the TV. Use the Toslink/ Optical Output on the TV.
- Page 3 Connect the converter to the loop amplifier (or the transmitter of the wireless headset/neckloop) Use the audio cable that was delivered with the loop amplifier/transmitter or was included with the connector. 1. Connect the red and white connector to the converter (R/L) 2.
-
Page 4: Maintenance And Care
Should the product not work after having made the test as described above, please contact the local distributor of the product for further instructions. If the product should be sent to Bo Edin AB, please enclose a filled Service Form (pdf), www.univox.eu/documents. -
Page 5: Technical Data
Technical data For additional information, please refer to product data sheet/brochure and CE certificate which can be downloaded from www.univox.eu/products. If required other technical documents can be ordered from support@edin.se. Environment When this product is finished with, please follow existing disposal regulations. - Page 8 Distributor Univox by edin, the world’s leading expert and producer of high quality hearing loop systems, created the very first true loop amplifier 1969. Ever since our mission is to serve the hearing community with the highest degree of service and performance with strong focus on Research and Development for new technical solutions.
