- Page 1 INSTRUCTION MANUAL SL2150 Series L-Band Fiber Optic Extender 191 FOREST AVENUE LOCUST VALLEY, NY 11560-2132 USA (800)-488-8378 / (516)-671-7278 FAX (516)-671-3362 sales@multidyne.com www.multidyne.com REV A, Sep 21, 2011...
- Page 2 MULTIDYNE, the Multidyne logo, SL2150-FTX and SL2150-FRX are registered trademarks of MULTIDYNE Electronics, Inc. Copyright 2011 MULTIDYNE Electronics, Inc., Locust Valley, New York. Printed in the United States of America. All Rights Reserved. Contents of this publication may not be reproduced in any form without the written permission of MULTIDYNE Electronics, Inc.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ........................1 FEATURES AND OPERATION ....................1 OPERATION: ........................2 TRANSMITTER, SL2150-FTX ..................... 2 RECEIVER, SL2150-FRX ....................4 INSTALLATION ........................5 APPENDIX A. BLOCK DIAGRAMS ..................6 APPENDIX B. TECHNICAL SPECIFICATIONS ..............7 REV A, Sep 21, 2011... -
Page 4: Introduction
They have been designed to provide very low carrier-to-noise ratio and extremely linear performance. This means a cost effective technically superior installation for the satellite signal user. Multidyne systems have been engineered to give industry-leading performance when compared with any other fiber optic link. Only SL2150 links have ultra wide dynamic range so that automatic gain control is not required to cope with changing signal intensity caused by meteorological conditions. -
Page 5: Operation
Instruction Manual, SL2150 Series FEATURES and OPERATION 2 OPERATION: TRANSMITTER, SL2150-FTX The transmitter module front and back is shown in figure 1. Figure 1. Front and Back of SL2150-FTX The FTX front panel has a POWER LED that glows green when power is applied. The POWER LED will flash red if there is a fault. - Page 6 Instruction Manual, SL2150 Series FEATURES and OPERATION 3 down the list to highlight the parameter you wish to change. When the desired parameter is highlighted, press the right or left edges of SELECT to cycle thru the settings. When you have arrived at the desired setting, push SELECT straight in to invoke it.
-
Page 7: Receiver, Sl2150-Frx
Instruction Manual, SL2150 Series FEATURES and OPERATION 4 1V to the polarity power voltages to offset any voltage drop caused by long coax cable runs. This change in LNB voltage will also be reflected on the Power Status screen. An example... -
Page 8: Installation
RF output signal integrity is impaired. Link gain should be between -8 to +9dB. INSTALLATION The SL2150 Series operates from 85 to 240 VAC with the included wall-mount 12V power supply or other source in a range from 9 to 24 VDC and at least 10W of power. It uses a coaxial type connector (sleeve ground) on the rear panel labeled POWER. -
Page 9: Appendix A. Block Diagrams
Instruction Manual, SL2150 Series APPENDIX A. Block Diagrams 6 APPENDIX A. Block Diagrams LBAND TX BLOCK DIAGRAM FRONT DISPLAY 22KHZ Ind. H or V Ind. 12V Sense Laser Failure Laser fail Laser Current Laser current Display settings RF IN Optical Out... -
Page 10: Appendix B. Technical Specifications
Instruction Manual, SL2150 Series APPENDIX B. Technical Specifications 7 APPENDIX B. Technical Specifications General Dimensions (LxWxH): ..........7.09"x5.57"x1.52" (141x180x37mm) Weight (Each end) ............. 24 oz (0.68Kg) Operating Temperature Range ........0° C to +50°C Relative Humidity ............0 to 95% Storage Temperature Range ........
