SIRKOM - SRK-1080P-B Player
User Manual
Feb 09, 09
FCC Notices
It's herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation is
subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a residential
installation. This equipment generated uses and can radiate radio frequency energy and if not
installed and used in accordance with the instruction manual may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio of television
reception, which can be determined by turning the equipment off or on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio TV technician for help.
CE Declaration
This device complies with CE class B.
EN55022
IEC 61000-4-4
EN61000-3-2
IEC 61000-4-5
EN61000-3-3
IEC 61000-4-6
EN55024
IEC 61000-4-8
IEC 61000-4-2
IEC 61000-4-11
IEC 61000-4-3
Printed in Spain
All contents are subject to change without notice.
All trademarks are the property of their respective owner.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRK-1080P-B and is the answer not in the manual?

Questions and answers

Related Manuals for Sirkom SRK-1080P-B

Summary of Contents for Sirkom SRK-1080P-B

  • Page 1 FCC Notices SIRKOM - SRK-1080P-B Player It’s herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. User Manual This device must accept any interference received, including interference that may cause undesired operation.

  • Page 2: Table Of Contents

    2. INTRODUCTION 9. Http Command Function………….……………………….. 26 9.1 Player Control………………….……………………….. 27 The SRK-1080P-B Player is a digital media player that plays HD WMV9 and WMA from CF memory card without a computer. 9.2 Network Setup………………………………………….. 28 9.3 Timer Setup…………………………………………….. 29 The SRK-1080P-B Player supports High Definition movie hardware decode acceleration, 10.

  • Page 3: Features

    Exports the Configuration Value: You can export the configuration value to the CF card. HDMI Connector: Connects to devices that support HDMI input. The configuration can be modified on your PC, and can be applied to the SRK-1080P-B RS-232 Connector: Used for computer control with ASCII command.

  • Page 4: Remote Control

    Status 1: If the “AUTOPLAY (Movie, Picture or All Files)” function is enabled and there OSD display function on/ off are media files on the CF card, the SRK-1080P-B Player will auto play the files on the CF Auto-play function on/ off card after power on.

  • Page 5: Setting Up

    7.1 NETWORK SETUP (continued) 7. SETTING UP Assign IP Address: If the SRK-1080P-B Player is connected to a network without a DHCP In the main menu, please using the “▼” button on remote control to select the “SETUP” server or you want to use Local FTP Server function, enter the fixed IP address, Mask, item, then press the “ENTER”...

  • Page 6: Ftp Setup

    Continental GMT (U.S. & (GMT-07:00) (GMT+03:30) Tehran Local FTP Server: Turn on/ off the SRK-1080P-B Player server. Canada) (If you use the SRK-1080P-B Player server, please disable the DHCP function and input a (GMT-07:00) Arizona (GMT+04:00) Baku, Tbilisi, Ere van (GMT-06:00)

  • Page 7: Video Setup

    SlideShow Interval: Set the time each photo is shown to 10, 15, 30 or 60 seconds. Lock Remote Controller: Enable/ disable the auto key lock function. (The SRK-1080P-B Player will auto lock when there is no further input for 1 minute.) Lock Password Setup: Press the “Enter”...

  • Page 8: Using The Srk-1080P-B Player

    8.1 PLAY MEDIA FILES ON THE CF CARD Step 1: Insert the CF card with media files, then turn on the SRK-1080P-B Player and press the “ENTER” button on the remote control when “’mnt/CF” is highlighted to take you into the CF card.

  • Page 9: Using The Remote Control When Media File Is Playing

    8.1.1 Using the Remote Control When Media File Is Playing PAUSE/STEP: Pause the playback or play frame by frame. SETUP: Press the button to adjust the brightness, contrast or saturation while the movie or ZOOM: Zoom in/ out on the movie or picture. picture is playing.

  • Page 10: Download Function

    8.2.2 Auto Download Function server at the designated time. If there is more than one SRK-1080P-B Player, you can use ftp tools to divide them into different regional group. NOTE: The filename of the media files in FTP server cannot have any spaces.

  • Page 11: Play The Media Files On The Pc

    Step 3: Click the “Library” tab, and then click “Add to Library”. NOTE: If the network connection is unstable or broken, a pop-up window will appear as shown below. The SRK-1080P-B Player will attempt to resume downloading in 2 minutes. The user can terminate the download by pressing the “RETURN” button.
  • Page 12 Step 5: Click the “Library” tab, and then click “Media Sharing”. Step 8: Confirm that the SRK-1080P-B Player is connected to the network. In the list of devices below the “Share my media to” check box, select the device (SRK-1080P-B Player), and click “Allow” to share the media files.

  • Page 13: Download/ Upload Media Files

    Step 3: Please setup your router or firewall, and open a port 21 for the SRK-1080P-B Player. Step 11: Select the file you want to play, and press “ENTER” or “PLAY” button on the remote The following figure is an example, please refer to your user’s manual of router for opening control to play the file.

  • Page 14: Rs-232 Function

    NOTE：Must include the round brackets. [number]: Play the file by index. (numbers < upper case letters < lowercase letter) - Select the files you want upload to the SRK-1080P-B Player, or download the files to your PC. Pin Assignment D Sub 9Pin Female...

  • Page 15: Http Command Function

    (Default User Name: root, Default Password: admin) to login. After login, all the media files on the CF card on the SRK-1080P-B Player will be listed. You can download and upload the media files between CF card and your PC.

  • Page 16: Network Setup

    Network Interface: Select your network connection Disable/ RJ45. DHCP: Enable/ Disable the DHCP function. IP Address: Enter the fixed IP address, Mask, Gateway and DNS for the SRK-1080P-B Player. FTP Server: Enable/ Disable the FTP Server function. You can also change the User ID, Password and port of the FTP Server.

  • Page 17: Basic Schedule

    10.2.1 Basic Schedule 10. SCHEDULE FUNCTION In the “Basic Schedule” mode, you can select files that you want to play and the set up the play times of each file. NOTE: The “NTP Server” or “Local Time” must be set before using the Add：Click this button to add a file.

  • Page 18: Advance Schedule

    Click the “Browser” button to select a file that you want to play. You can also set up the NOTE：Do not rename the file (schedule.ini), otherwise the SRK-1080P-B Player will not be able to “Play Times” of the file in the window. Click the “OK” button to complete the setup.

  • Page 19: Explanation Of The Warning Message

    Put the “schedule.ini” file and the associated media files on the memory card, and insert the memory card to the SRK-1080P-B Player. The SRK-1080P-B Player will auto play the files at the designated time.

  • Page 20: Optional Auxiliary Equipment

    Press one of the play buttons to play the corresponding file. Hardware Connection 11.3.1 Using the PIR Sensor Step 1：Insert the CF card to the SRK-1080P-B Player, and the SRK-1080P-B Player will play the default file automatically while powered on. Play the Media File By the Play-Button Step 2：After sensing approaching subjects, the SRK-1080P-B Player will play the first demo file.

  • Page 21: Troubleshooting

    11.4.4 Play the Demo Files 1. Check if the mute function is on. Step 1：Insert the CF card to the SRK-1080P-B Player, and the SRK-1080P-B Player will play the No sound 2. Check if the volume is set properly.
