Point Source Audio CO-8WD Owner's Manual

Series 8
Hide thumbs
1
2

Advertisement

Quick Links

Download this manual
CO-8WD Specifications
Omnidirectional Headset Microphone
ELEMENT:
Back Electret Condenser
POLAR PATTERN:
Omni-directional
FREQUENCY RESPONSE:
20 Hz ~ 20 kHz
SENSITIVITY:
-54dB ±3dB
(0dB = 1V/microbar at 1kHz)
OUTPUT IMPEDANCE:
1400
(at 1kHz)
OPERATING VOLTAGE:
1 ~ 10 V
CABLE LENGTH:
4 ft .077 in. + connector
NET WEIGHT:
0.6 oz
MAXIMUM SPL:
148dB SPL
INCLUDED ACCESSORIES:
Windscreen, body clip,
storage box
CR-8D Specifications
Cardioid Headset Microphone
ELEMENT:
Back Electret Condenser
POLAR PATTERN:
Uni-directional
FREQUENCY RESPONSE:
160 Hz ~ 14 kHz
SENSITIVITY:
-70dB ±3dB
(0dB = 1V/microbar at 1kHz)
OUTPUT IMPEDANCE:
5000
(at 1kHz)
OPERATING VOLTAGE:
1 ~ 10 V
CABLE LENGTH:
4 ft .077 in. + connector
NET WEIGHT:
0.6 oz
MAXIMUM SPL:
135dB SPL
INCLUDED ACCESSORIES:
Windscreen, body clip,
storage box
www.point-sourceaudio.com
SERIES8 | CO-8WD | CR-8D
Headset Microphone
Owner's Manual
Read the enclosed instructions and cautions thoroughly before
using this product. Failure to observe the proper use of this
product could result in voiding your warranty.
w w w . p o i n t - s o u r c e a u d i o . c o m

Advertisement

loading
Need help?

Need help?

Do you have a question about the CO-8WD and is the answer not in the manual?

Questions and answers

Related Manuals for Point Source Audio CO-8WD

Summary of Contents for Point Source Audio CO-8WD

  • Page 1 4 ft .077 in. + connector NET WEIGHT: 0.6 oz NET WEIGHT: 0.6 oz MAXIMUM SPL: 148dB SPL MAXIMUM SPL: 135dB SPL SERIES8 | CO-8WD | CR-8D Headset Microphone INCLUDED ACCESSORIES: Windscreen, body clip, INCLUDED ACCESSORIES: Windscreen, body clip, Owner’s Manual storage box storage box Read the enclosed instructions and cautions thoroughly before using this product.

  • Page 2: Microphone Placement

    Read Before Use Microphone Placement Using with Your Wireless System Read the enclosed instructions and cautions thoroughly before using Carefully adjust the boom portion of this product. Failure to observe the proper use of this product could the mic to curve around the face. result in voiding your warranty.

This manual is also suitable for:

Cr-8d
