General Characteristics Sales of products The board is predisposed for direct connection to a maximum of 8 trays with 9 spirals per tray. The correct dispensing of the product is assured by the patented system which controls the rotation of the spirals at 360° + X° -X° where X is programmable for each spiral. The graphic display allows a simple and efficient use of the machine.
Page 3
General Information on the logic board Connection of the payment systems A parallel coin mechanism can be connected to the 10 pin connector CN6 or to the 16 pin connector CN5. These connectors supply, respectively, a power supply of 12V and 24V to the coin mechanism. A serial coin mechanism with Executive protocol can be connected to connector CN8.
Service menu Use of the keypad All of the service and programming functions of the working parameters are accessed through the use of the keypad of the machine. Keep the “Help” (3) key pressed down to visualize the current functions of the keys in that particular menu or sub-menu: The keys “1”...
Page 5
“Load products” Menu Reload all Remaining products Reload quantity Expiry of products Expiry of reload “Remaining products” has 72 counters relating to each possible product which decrease by 1 every time that specific product has been dispensed. “Expiry of products” has 72 counters relating to each possible product which decrease by 1 with each passing day.
Page 6
At the end of this list is available the visualization of a total counter of the takings of an absolute type (which can’t be zeroed). “Total partial takings” visualizes directly the sum of the actual values of all partial counters and thus represents a total counter of the partial type takings (which can be zeroed).
Page 7
“Parallel coin mechanism” is the amalgamation of values, in real currency, relative to the 6 coin channels of the parallel coin mechanism and the 4 channels of the parallel banknote reader. There is also available the option of automatic annulment of the remaining credit (only from parallel systems and not executive systems) with relative zeroing time.
be accessible without later inserting the password. Instead, inserting the correct password using keys “1”-“5” and “Shift” all menus will be accessible up to exiting the service menu. “Clock set-up” Menu Set time/date On/off programs “Set time/date” allows the regulation of the date and current time on the machine clock. This clock is used for various machine functions.
Page 9
Prog. Day of the week Saturday Saturday Saturday Sunday Note: the character * signifies “Whichever”. Example 3. Needs a weekly programming the same for every week of every year: Monday from 8:00 Tuesday from 8:15 Wednesday from 8:30 Thursday from 8:45 Friday from 9:00 Saturday...
Page 10
“Test machine” Menu Test trays Test lift Test flap Test optical sensor “Test trays” consents the cyclical testing of all the spirals of all the trays. Remember that all spirals for which the price is set at “Not used” are excluded from the test. “Test lift”...
Page 11
Other functions of the logic board Data-logger of events The board avails of an automatic register of events. The events are memorized in the form of lines of text in the internal of which there is different useful information on the event itself. Connecting a Personal Computer to the CN1 connector for programming the board using a standard serial cable it is possible to read this information and save it to a text file.
Page 12
By PC it is also possible to set-up the clock of the machine or read, save to file and visualize the contents of the data-logger. An innovative characteristic of the board is the possibility to modify and personalize all the graphic images which appear on the display.
Page 13
FAULT LED LINE NEON+BOARD FUSE 230V MAIN FUSE 3 POLES FAULT LED 9 POLES SWITCH LCD72A DISPLAY KEY9B KEYBOARD DISPLAY CONTRAST CN13 8 X MOTOR CONNECTORS CN30/CN22 CN23/CN15 IM7A/IM11A INTERFACES IM7A IM7A VENDING MOTORS CAB1 BOARD FAULT LED COOLER FUSE 22V LED 11V LED 12 POLES...
