DT595A USER MANUAL
2-Wire Audio Entry System
Read this manual carefully before using the product, and keep it safe for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DT595A and is the answer not in the manual?

Questions and answers

Summary of Contents for Doorentryonline DT595A

  • Page 1 DT595A USER MANUAL 2-Wire Audio Entry System  Read this manual carefully before using the product, and keep it safe for future use.

  • Page 2: Parts And Function

    Parts and Function The 595A audio door panel is designed for all DT 2-wire systems. The front panel is made of zinc alloy for better protection against vandalism & cauterization, and the call button is also made of zinc alloy with blue backlight for auxiliary illumination, the unlock and talking LED indicator ensures the door panel is working efficiently.
  • Page 3 DT-CAM user instructions for details (Not available from Doorentryonline Ltd) PL(White): external lock power input, connect to the power positive (power +). S1+(Yellow): lock power(+) output. S1-(Black): lock power(-) output. Unit Mounting The location of the door panel should be kept away from direct weather and all intensity light.
  • Page 4 Multi Door Panel Connection 4# Panel 3# Panel 2# Panel 1# Panel ID=11 ID=01 ID=10 ID=00 Handsets L1 L2 PL S1+ S2+ S- L1 L2 PL S1+ S2+ S- L1 L2 PL S1+ S2+ S- L1 L2 PL S1+ S2+ S- DIP=on,off,off A B C D DBC4S...
  • Page 5 Multi Handset with DBC4S 4 way branch connector monitor 7 monitor 8 3 4 5 6 3 4 5 6 Impedance Code=6, DIP-6=on Code=7, DIP-6=on OFF ON switch DIP=on,off,off monitor 5 monitor 6 3 4 5 6 3 4 5 6 Code=4, DIP-6=on Code=5, DIP-6=on monitor 4...
  • Page 6 With DT-CAM wiring mode - NOT available from Doorentryonline Ltd The audio door station DT595A can be extended an additional CCTV camera to be a video door station. For more details about the camera, please refer to DT-CAM user instructions.

  • Page 7: Dip Switch Settings

    DIP Switch Settings The DIP switch is designed to set the code for door panel and monitor, there are two states for each DIP switch, please refer to the following: ON(1) OFF(0) Door panel DIP setting Total of 3 bits can be configured, bit-1 and bit-2 are used to assign the ID code for the door panel, bit-3 is used to match the video impedance.The switches can be modified either before or after installation.

  • Page 8: Specification

    Bit state User code Bit state User code Bit state User code code=0 code=6 code=11 3 4 5 3 4 5 3 4 5 code=1 code=7 code=12 3 4 5 3 4 5 3 4 5 code=2 code=8 code=13 3 4 5 3 4 5 3 4 5 code=3...

  • Page 9: Cable Requirements

    Cable Requirements The maximum distance of the wiring is limited in the DT system. Using different cables may also affect the maximum distance which the system can reach. The farest monitor monitor with two or four monitors monitor monitor DBC4S DPS &...
