DGPS SENSOR
JLR-4341
<INTRODUCTION>
Thank you for choosing the JRC GPS sensor DGPS224.
This manual describes Model DGPS224, JRC DGPS Sensor and Beacon receiver with Built-In
Antenna and SBAS capability.
• To ensure correct operation of the DGPS224, please read this Instruction Manual carefully before starting
to use.
• This manual should be kept on hand to provide as quick reference whenever you need it.
• It will also help you if you come across any problems in its operation.
<NOTES TO USERS>
In order to ensure safe and correct use of the equipment, symbols in this manual and on the
equipment itself alert the user to important operational precautions that could prevent personal
injury or damage. The followings show such symbols and their meanings. Please read this
manual carefully and take note of these symbols.
WARNING
CAUTION
Other Symbols and Their Meanings:
This symbol indicates that the action is prohibited.
Prohibited
This symbol indicates that the action must be taken.
Do This
CODE : 7ZPNA4162
ＤＧＰＳ２２４
This symbol indicates warning items that, if ignored,
may result in serious personal injury or even death.
This symbol indicates cautionary items that, if
ignored, may result in personal injury or physical
damage.
1/20
DGPS224(JLR-4341)
JRC

Advertisement

   Related Manuals for JRC DGPS224

   Summary of Contents for JRC DGPS224

  • Page 1

    This manual describes Model DGPS224, JRC DGPS Sensor and Beacon receiver with Built-In Antenna and SBAS capability. • To ensure correct operation of the DGPS224, please read this Instruction Manual carefully before starting to use. • This manual should be kept on hand to provide as quick reference whenever you need it.

  • Page 2

    SECTION 1 GENERAL INFORMATION 1.1 Function By receiving GPS signals from up to twelve satellites, DGPS224 sensor provides highly accurate position fixing. Furthermore, the DGPS224 can implement DGPS measurement by receiving the correction data, and can achieve the measurement of high accuracy than the GPS measurement.

  • Page 3

    SECTION 2 PARTS AND FUNCTIONS φ134mm ①Sensor 155mm ③Base Mounting Screw 1"-14UNS-2B ④Connector ②Cable 15m Mass：Approx. 1.7Kg Fig. 2.1 Parts of DGPS224 Not Use (Brown) 12VDC/24VDC (Red) ５ １ Set Data Input (Yellow) ６ ４ Data Output (Green) 0VDC (Black) ２...

  • Page 4

    SECTION 3 INSTALLATION 3.1 Unpacking and Checking Take out the DGPS224 from the packing case carefully. Check each item listed in Table 1-1 is contained in the case. Save the case and the packing material until the equipment will be installed successfully.

  • Page 5

    DGPS224(JLR-4341) 3.3 Installation Procedure 3.3.1 Installation of the Sensor The sensor base contains 1 inch 14UNS-2B screw holes. It can be attached to poles with cut male screws, or off-the-shelf adapters. (1) When performing attachment, always hold and turn the sensor base. Holding and turning the radome may result in a large amount of force applied at the junction of the base and the radome, resulting in damage to the sensor.

  • Page 6

    DGPS224(JLR-4341) 3.3.2 Installation of the Sensor to pass a cable through a pole It is possible to pass cable into pole, when DGPS sensor attached to poles with cut male screws. (1”-14 UNS-2A). In this case, Cable guard rubber (attached article) used.

  • Page 7

    DGPS224(JLR-4341) (3) When DGPS sensor attached to poles with cut male screws, round off the corners. See below. round off the corners About 25mm 1”14-UNS－2A Fig. 3-5 How to attached to poles and work example (4) When performing attachment, always hold and turn the sensor base. Holding and turning the radome may result in a large amount of force applied at the junction of the base and the radome, resulting in damage to the sensor.

  • Page 8

    When the DGPS224 is connected to directly connectable GPS navigation equipment, 12 VDC is supplied from the equipment to the DGPS224. In this case, connect the 6-pin connector to the plug where the GPS/DGPS label is attached on the rear panel of the equipment.

  • Page 9

    It may also cause poor waterproofing. If the DGPS224 appears to be defective, check the connection again. If the equipment still appears faulty after that, stop using the equipment and contact our representative or our sales office directly.

  • Page 10

    TOKYO OFFICE 10-1, Nishi-Shinjuku 6-chome, Shinjuku-ku, Tokyo 160-8328 JAPAN Phone : +81-3-3348-4126 Fax : +81-3-3348-4183 Web : http://www.jrc.co.jp 1021 SW Klickitat Way, Bldg. D, SEATTLE BRANCH OFFICE Suite 101, SEATTLE, WA98134 USA Phone : +1 (206) 654-5644 Fax : +1 (206) 654-7030 Web : http://www.jrcamerica.com...

  • Page 11

    DGPS224(JLR-4341) Appendix１ Data Format １．Protocol ・Bit Rate ：4800,9600,19200,38400bps selectable（Defaute:4800bps） When power is turned on, bit rate is set to 4800bps. ・Data Bit ：8 bit ・Parity ：None ・Stop Bit ：1 bit ・Output Interval ：1 second 2.Output Data (1)GGA (Global Positioning System Fix Data) Version 1.5...

  • Page 12

    DGPS224(JLR-4341) (2)VTG (Track Made Good and Ground Speed) Version 1.5 $GPVTG, xxx.x,T,,,xxx.x,N,,<CR><LF> Version 2.1 $GPVTG, xxx.x,T,,,xxx.x,N,xxx.x,K*hh<CR><LF> Version 2.3, IEC $GPVTG, xxx.x,T,,,xxx.x,N,xxx.x,K,x*hh<CR><LF> 6 7 8 1, 2 : Course bearing (deg) 3, 4 : Speed (knots) 5, 6 : Speed (km/h) : Checksum (Version 1.5, 2.1)

  • Page 13

    DGPS224(JLR-4341) (4)GLL (Geographical Position, Latitude / Longitude) Version 1.5 $GPGLL,ddmm.mm,a,dddmm.mm,a<CR><LF> Version 2.1 $GPGLL,ddmm.mmmm,a,dddmm.mmmm,a,hhmmss.ss,A*hh<CR><LF> Version 2.3, IEC $GPGLL,ddmm.mmmm,a,dddmm.mmmm,a,hhmmss.ss,A,x*hh<CR><LF> 6 7 8 1, 2 : Latitude (deg, min), N / S 3, 4 : Longitude (deg, min), E / W : UTC time (hours, minutes, seconds 1/100 sec fixed at 00) Measured UTC [1/100 sec] (Version 2.3, IEC)

  • Page 14

    : Datum symbol W84 - WGS84 W72 - WGS72 IHO - datum code (Version 2.1: JRC proprietary value) IHO - datum code (Version 2.3, IEC: IHO datum code) (Please refer to "Tables 1 and 2" for datum code) 999 - user defined number...

  • Page 15

    DGPS224(JLR-4341) (9)GBS (GPS satellite fault detection for RAIM) Version 2.1, 2.3, IEC only $GPGBS,hhmmss.ss,uxxx.x,uxxx.x,uxxx.x,xx,x.xxxxx,uxxxx.x,xxxx.x*hh<CR><LF> : Measured UTC (hr. min. sec. 1/100 sec) : Latitude estimated error [m] u: sign (+,-) The sign is omitted if value is positive. (IEC) : Longitude estimated error [m] u: sign (+,-) The sign is omitted if value is positive.

  • Page 16

    DGPS224(JLR-4341) 3.Input Data Interval of two input sentences must be more than 1 second. (1)PJRCI,GP (Initial Position and Time setting) $PJRCI, GP, llll.ll, a, yyyyy.yy, a, uxxxx, hhmmss, xx, xx, xxxx, A, A, A, A, A, A*hh<CR><LF> 9 10 1112131415 16...

  • Page 17

    DGPS224(JLR-4341) (3) E0 (Beacon manual setting) E0BfBfBfBfDf (Binary data) : Manual search setting : Frequency Bf Bf Bf Bf : fff.f kHz ex) 309.0kHz : B3B0B9B0 : Bit rate D5 : 50bps D6 : 100bps D7 : 200bps (4) E1 (Beacon automatic setting)

  • Page 18

    DGPS224(JLR-4341) (8)PJRCE,GP,2 (Station health, Smoothing setting) $PJRCE, GP, 2, x, xxx*hh<CR><LF> 1 2 3 : Station health Range from 0 to 7 (default 5:JLR-4341 6:JLR-4340) : Smoothing level Range from 0 to 99 seconds Setting of variable smoothing level in PJRCE,GP,0 : Checksum Table 1.

  • Page 19

    Southwest Base(Faial, Graciosa, Pico, Sao Jorge, ４６ Terceira Island) Timbalai 1948(Brunei, East Malaysia) ４７ ** : No appear in s-60 *** : CODE is not appeared in s-60 There is no CODE, JRC original local geodetic number is appeared. 19/20...

  • Page 20

    DGPS224(JLR-4341) 有毒有害物质或元素的名称及含量 (Names & Content of toxic and hazardous substances or elements） : JLR-4341 形式名 名称 : DGPS Receiver (Type) (Name) 有毒有害物质或元素 (Toxic and Hazardous Substances and Elements) 部件名称 (Part name) 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd)
