Portable Power Charger
PURE
edition
USER'S MANUAL
GB NL D DK
F
DECLARATION OF CONFORMITY
We, the undersigned
Company: TE-GROUP nv
Address: Kapelsestraat 61, 2950 Kapellen - BELGIUM
declare, that the following equipment:
Product Name: mr Handsfree Portable Power charger 10400 mAh set
Product Type: Portable Power Charger 10400 mAh
Conforms with the following safety requirements of the directives 2004/108/EC and 2006/95/EC, and is
guaranteed by the CE-symbol.
Standards:
EN 55022:2010
EN 55024:2010
EN 61000-3-2:2006+A1:2009+2:2009
EN 61000-3-3:2008
---
QRG/PORTABLE POWER CHARGER 10400 mAh Pure/10-13/V01

PACKAGE CONTENTS

• Portable Power Charger
• Micro USB charging cable 50 cm

CHARGING THE PORTABLE POWER CHARGER

1. Connect the micro USB charging cable in the Portable Power Charger's IN port.
Option 1 (See illustration 1):
Connect the charging cable to your computer's USB port or another USB 2.0 (or higher) compatible port.
Option 2 (See illustration 2):
Connect the charging cable to the USB port of the universal USB AC adapter (not provided, optional, see
www.mrhandsfree.com) . Plug the AC adapter into a wall socket.
Option 3 (See illustration 3):
Connect the charging cable to one of the USB ports of a Duo USB car charger (not provided, optional, see
www.mrhandsfree.com). Plug the car charger into a cigarette lighter socket.
2. The Portable Power Charger's LED indicators will be blinking to indicate that the battery is being charged. The
number of LED's that is continuously ON, indicates the remaining battery capacity:
4 LED's ON: 75-100% remaining power
3 LED's ON: 50-75% remaining power
2 LED's ON: 25-50% remaining power
1 LED's ON: 0-25% remaining power
0 LED's ON: battery is empty
The charger can be charged in ON or OFF position. Charging time is max. 10-12 hours.
3. When the battery is nearly charged, all 4 LED indicators are ON and they will turn OFF when the unit is fully
charged. Disconnect the charger. The Portable Power Charger is now ready for use.
OPERATION OF THE PORTABLE POWER CHARGER (See illustration 4)
Important! The Portable Power Charger must be fully charged before first use.
1. Connect the micro USB cable to one of the 5V OUT ports of the Portable Power Charger.
2. Connect the other side of the cable to your device, or use your own USB charging cable (originally supplied with your
device).
3. Turn the Portable Power Charger ON by pressing the button.
4. The LED indicators turn ON, indicating that the Charger is charging your device. The number of LED's that is
ON, indicates the remaining battery capacity of the Portable Power Charger.
Remarks:
• You can charge 2 devices simultaneously. When charging 2 devices, you can use the provided micro USB cable
for one device and for the second device you should use the USB charging cable that was originally delivered
with the second device.
• The LED indicators will turn OFF after 5 seconds, the Charger will keep charging your device. To check the
remaining battery status, press the ON/OFF button once.
• When the Charger is not in use, it will switch OFF automatically to save power.

LED TORCH

Quickly press the ON/OFF button twice to activate the LED torch. Press the button once again to make the light
go into S.O.S. mode. Press the button again to turn the light off.
When the Portable Power Charger is fully charged, the LED torch can be used for over 260 hours.
SK
ES IT CZ RU
---
CUSTOMER SUPPORT
For all product related questions, please contact:
Voor alle productgerelateerde vragen kunt u zich wenden tot onze supportafdeling:
Pour toutes les questions relatives à l'utilisation de ce produit, veuillez contacter notre Service
Support Client:
Für alle produktbezogenen Fragen kontaktieren Sie bitte:
support@mrhandsfree.com
EST
GB

SAFETY INSTRUCTIONS

• The lithium-ion rechargeable battery used in this charging device may present a risk of fire or chemical
burn if mistreated. Do not disassemble, expose to heat above 100° C, or incinerate. Misusing or incorrectly
connecting the charging device may cause electric shock to users and damage equipment. Read instructions
carefully. The charging device may become warm and may reach 50°C under extended high power
operation. During operation, keep the charging device away from materials that may be affected by these
temperatures.
• When used correctly, lithium-ion rechargeable batteries provide a safe and dependable source of portable
power. However, if they are misused or abused, this may result in leakage, burns, fire or explosion/
disassembly, causing personal injury or damage to other devices.
• Do not disassemble the charging device. There are no user-serviceable parts inside. Incorrect reassembly
may result in shock or fire hazard.
• Do not drop or subject the charging device to strong mechanical shock.
• Do not expose the charging device to moisture, water, rain, snow or spray.
• Do not insert any object into the ports or openings of the charging device.
• Do not operate the charging device if it has received a sharp blow, been dropped, or otherwise been damaged
in any way.
• Do not use in environments where the temperature is 40°C or higher.
• Keep out of reach of children.
• To reduce the risk of electric shock, unplug the charging device from any power source before attempting any
maintenance or clearing.

TECHNICAL DATA

Input: DC 5V – 1000 mA
Output: A: 5.3V/1A - B: 5.3V/2.1A
Capacity: 10400mAh SAMSUNG Li-ion HP
Weight: 238 grams
Dimensions: 93 x 79 x 23 mm
Protection: IC Protector hardware & software

DISPOSAL

Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact
your local government for information regarding the collection systems available. If electrical appliances are
disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food
chain, damaging your health and well-being. When replacing old appliances with new ones, the retailer is
legally obligated to take back your old appliance for disposals at least free of charge.

GUARANTEE

Copyright © Mr Handsfree. Mr Handsfree is a registered trademark of TE-Group NV. The mr Handsfree brand stands for
superior product quality and outstanding customer service. That is why mr Handsfree warrants this product against
all defects in material and workmanship for a period of two (2) years from the date of original purchase of the
product. The conditions of this guarantee and the extent of responsibility of mr Handsfree under this guarantee can
be downloaded from our website: www.mrhandsfree.com. If you need to contact the service department, please send
an e-mail to support@mrhandsfree.com.

ILLUSTRATIONS
