CDX-GT06/CXS-GT06HP
SERVICE MANUAL
Ver. 1.0 2006.07
• CXS-GT06HP is composed of CDX-GT06,
2 way speaker, 3 way speaker.
• The tuner and CD sections have no adjustments.
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
22 watts per channel minimum continuous average power into
4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more
than 5% total harmonic distortion.
CD Player section
Signal-to-noise ratio:
120 dB
Frequency response:
10 – 20,000 Hz
Wow and flutter:
Below measurable limit
Tuner section
FM
Tuning range:
87.5 – 107.9 MHz
Antenna terminal:
External antenna connector
Intermediate frequency: 10.7 MHz/450 kHz
Usable sensitivity:
9 dBf
Selectivity:
75 dB at 400 kHz
Signal-to-noise ratio:
67 dB (stereo), 69 dB (mono)
Harmonic distortion at 1 kHz:
0.5 % (stereo), 0.3 % (mono)
Separation:
35 dB at 1 kHz
Frequency response:
30 – 15,000 Hz
AM
Tuning range:
530 – 1,710 kHz
Antenna terminal:
External antenna connector
Intermediate frequency: 10.7 MHz/450 kHz
Sensitivity:
30 µV
Sony Corporation
9-887-357-01
eVehicle Division
2006G04-1
Published by Sony Techno Create Corporation
© 2006.07
(Photo: CDX-GT06)
Model Name Using Similar Mechanism
CD Drive Mechanism Type
Optical Pick-up Name
SPECIFICATIONS
Power amplifier section
Outputs:
Speaker impedance:
Maximum power output: 45 W × 4 (at 4 ohms)
General
Outputs:
Inputs:
Tone controls:
Power requirements:
Dimensions:
Mounting dimensions:
Mass:
Supplied accessories:
FM/AM COMPACT DISC PLAYER
US Model
CDX-GT10W/GT100
MG-611XE-186//C
KSS1000E
Speaker outputs (sure seal connectors)
4 – 8 ohms
Audio outputs terminal (sub/rear switchable)
Power antenna relay control terminal
Power amplifier control terminal
Antenna input terminal
AUX input jack (stereo mini jack)
Low: ±10 dB at 60 Hz (XPLOD)
Mid: ±10 dB at 1 kHz (XPLOD)
High: ±10 dB at 10 kHz (XPLOD)
12 V DC car battery (negative ground)
Approx. 178 × 50 × 179 mm
(7
× 2 × 7
in) (w/h/d)
1/8
1/8
Approx. 182 × 53 × 161 mm
(7
× 2
× 6
in) (w/h/d)
1/4
1/8
3/8
Approx. 1.2 kg (2 lb 11 oz)
Parts for installation and connections (1 set)
– Continued on next page –
