Saxon P700 User Manual

S
PECIFICATION
Maximum Output Power 8 Ohms/20-20kHz
Output Impedance
Frequency Response
Signal - to - Noise Awtd
Mains Voltage
Dimensions H.W.D in mm excluding connections
Weight packed
un-packed
Saxon Audio's policy of continued research and development means that the above specification may change without
notice. The power amplifier has been manufactured to conform with the protection requirements of the EC Council directive
89/336/EEC relating to EMC by application of the following standards:
EN50081-1 1992 Emissions Standard
EN50082-1 1992 Immunity Standard
and also the requirements of the EC low voltage directive relating to electrical safety by application of the following standard
BSEN60065: 1994 Safety standard
For the purposes of testing, the power amplifier was used with the mains cables and high quality interconnects supplied by
Merlin Cables. Compliance with the above standards can only be made if the unit is installed as per this manual and using
the correct cables.
Guarantee: 3 Years return to dealer.
To help us provide you with the most efficient service please return your guarantee card promptly. Your power amplifier is
guaranteed against manufacturing and component defects for a period of 3 years. The guarantee does not cover and dam-
age caused by accident, misuse, neglect or through incorrect installation, adjustment or repair by unauthorised personnel
or the cost of collecting the power amplifier from you and returning it to the dealer. The above does not effect your statutory
rights as a consumer. E & OE
S A T O B H P F
AXON UDIO HE LD ARN IGHER ARK ARM
T : +44 (0)8456 123388 E- : info@saxonaudio.com website:- www.saxonaudio.com
EL MAIL
P700
100W
<0.03 Ohms
10-100kHz */- 3db
-86dB
ALL 230V /115V/100V AC ± 10%
87x440x300
8.5kg
7.1kg
Due to recent EU regulation
known as the Waste Electrical
and Electronic Equipment
directive (WEEE) all units MUST
be returned to ourselves at
the end of their life for proper
disposal or recycling. Items within
the UK will be collected free
of charge by contacting us via
email: weee@saxonaudio.com
H L C S GU24 8SL E
ALEBOURNE ANE HOBHAM URREY
Saxon P700 Power Amplifier
I
NTRODUCTION
Thank you for choosing a power amplifier.
We are confident that it will provide you
with many years of musical enjoyment and
reliable service. However, please take the
time to read this guide thoroughly before
using the amplifier. It explains how to
install and connect it, and suggests how to
ensure that you always enjoy its optimum
performance.
U
NPACKING LIST
Power amplifier
Instruction manual
AC power cord
Guarantee card
NOTE: We recommend that the supplied AC power
cord is replaced with a high quality Merlin Cables
power cord for best results.
Please be aware that this unit is not supplied with
interconnects and we recommend the use of the
Merlin series of interconnect cables.
I
NSTALLATION
How t o sit e and connect your Saxon power ampl if ier
f or best per f or mance and saf e oper at ion
Please unpack your amplifier carefully and position
it on a stable, level surface close to a mains socket.
Before attempting to connect it into your system
please read this manual carefully.
The Saxon power amplifier will perform well when
placed on a coffee table or bookshelf but if you
wish to achieve the best performance we suggest
you place it on a specialist hi-fi support. There are
many suitable designs available, which your dealer
will be happy to advise you about.
Position the amplifier so that it will not be
subjected to high ambient temperatures: avoid
sites where it will be in direct sunlight or close to
NGLAND
a central heating radiator. For your own safety

User Manual

- and your amplifier's well-being - do not allow
it to come into contact with water. Keep it away
from potted plants to avoid those all-too-common
watering accidents! To clean the amplifier's case
disconnect it from the wall socket and wipe it with
a barely damp, lint-free cloth or chamois leather. If
you suspect that water has entered the casework,
return the amplifier to your dealer so that he can
examine it.
Once you have installed the amplifier please do
not throw away its packaging. If you move home or
need to return the unit to your dealer or ourselves,
for example for upgrade or at the end of it's life
- see section on WEEE on the rear of this manual,
the original packaging will protect it and ensure it
arrives undamaged.
E
LECTRICAL CONNECTIONS
Using your mains lead of choice, connect the
amplifier directly to a wall socket. We strongly
recommend that you do not use extension blocks
as they degrade sound quality. For the same reason
we also advise against "line filters" and "mains
conditioners". If your mains supply is noisy or you
have household appliances that generate clicks
and pops that can be heard through your hi-fi
I
NSTRUCTIONS
system, have an electrician correct the problem
at its source. We do however recommend the use
of 'Merlin Cables' power chords which do not
interfere with the current flow and offer a significant
performance improvement.
Should you need to replace the fuse in your (UK)
mains plug, please fit only the correct replacement
type. This is a standard 5A.
If, for any reason, you wish to replace the plug or
cable, please note that the lead must be connected
as follows. NOTE: These instructions apply in the
United Kingdom only - consult your dealer about
wiring conventions in other countries.
Green and yellow wire connects to EARTH (E or
symbol
Blue wire connects to NEUTRAL (N)
Brown wire connects to LIVE (L)
This unit must be earthed.
)
