- Page 1 User Manual 120X90mm 100QK \Šb +zzv} 1+20Ÿu +zzv} 1+\^Ł =24 NfQŽ~¸žÑv}SpR7...
- Page 2 Function Function Thank you for choosing this camera. Please carefully read the manual before using, and keep it at a safe place for future reference. The compilation of the user manual refers to the latest information. The manual quotes captured screen displays and graphics, with the aim to introduce the digital camera through detailed and direct methods.
-
Page 3: Camera Maintenance
place near speaker or receiver of TV; ● Don’t use or keep the memory card in environment with over high or low temperature; ● Keep the memory card clean and away from contacting liquid. In case of contacting liquid, please dry it with soft cloth;... -
Page 4: System Requirements
System requirements System requirements When operating or using the digital camera, please take minimum system requirements for the computer of the camera into consideration. You are strongly recommended to use better computer equipment for operating the camera to achieve the optimized effect. The minimum system requirements are as below: System Requirements PCCAM Microsoft Window XP(SP3), Vista, 7，8... -
Page 5: Function Features
Function Features This camera is equipped with various characteristics and functions: Digital VDR; Digital camera (5 mega-pixel); Mass Storage (Removable disk); PC Camera; 8X digital zoom Seamless video Infrared remote control Appearance Appearance... - Page 7 Functions Indicators Functions Indicators Key/Indicator Function Power key Power On/Off; switch over among video recording, capturing and playback Video recording/capturing; play/stop playing video file (Playback mode); menu Shutter key confirmation MENU key Open and exit from menu；Stop play video files (playback mode) Digital zoom-in: select menu (after opening the menu);...
-
Page 8: Charge The Built-In Lithium Battery
Digital zoom-out: select menu (after opening the menu); file page-down ；Fast Down key forward video (playback mode) Indicator lights in red during charging, and the indicator turns off after charging Charger indicator full.（Power off charging） When the camera is busy (for example: during film recording, capturing, Busy indicator automatic screen-off), the busy indicator will light. - Page 9 charging, and will be off when the battery is fully charged. Generally, the battery can be fully charged after 2-4 hours. 2. How to use the memory card 2.1. Properly insert the TF card into the card holder as per the instructions indicated near the card holder. 2.2.
- Page 10 3.1 Startup: press the POWER key for 3 second, the camera will show startup screen and enters into POWER ON state; 3.2 Shutdown: press the POWER key when the camera is under idle mode to shut down; 3.3 Auto shutdown: the camera will be shut down automatically when the camera is under idle mode for a certain time to save power.
- Page 11 indicator will light; 5.2 Charging indicator: In shutdown state, the lightened indicator means the user is charging the camera. 6. Photo/recording mode It enters automatically into recording mode. Press Shutter to start recording, and press Shutter again to stop recording. Press Shutter to directly take photo.
- Page 12 1. Video mode; 2. Video quality; Video framerate 4. Video resolution； 5. Available time to record； 6. Face detect; 7. Icon of digital zoom; 8. Battery state; Note: 1. When using the HD size or FHD video, you must use the TF high-speed card at class 4 or above .
- Page 13 7. Menu Setting Mode 7.1 Menu display In photo, recording and playback mode, press Menu key to open the menu, and then press Up/Down key to select menu, press the Shutter key to enter submenu. When selecting menu, the selected menu will be displayed with blue background.
- Page 14 7.2 System mode menu setting After opening the menu by pressing Menu key, press power key to switch over to setting main menu, press Up/Down key to select menu, and after that to press Shutter key for confirming to enter the submenu. In the submenu, press Up or Down key to select menu, and press Shutter to confirm.
- Page 15 7.3 Setting date and time Press Menu key to open the menu, press Power key to switch to setting menu, and then press Shutter key to confirm. Press Down key to select “Date and time” in menu item, and then press Shutter key to enter setting window.
-
Page 16: Playback Menu
7.4 Playback mode menu setting Press Menu key to open playback main menu, press Up or Down key to select menu, press Shutter key to enter submenu. In the submenu, press Up or Down key for selection, and press Shutter key to confirm. After returning to the main menu, press Menu key to exit from the menu. -
Page 17: Video File Playback
8. Playback mode Press Power key to enter playback mode to browse photo/video, play the video recorded by this camera. Press Up/Down key to access to previous or next photo/video. Play movie: Press the shutter button to start/pause play video, press the up/down key to Retreat quickly /fast forward playback, press the MENU button to stop play video Video file playback Video pause mode... - Page 18 9. Remote control application 9.1. Remote control button instructions . 9.2 The use of remote control. Using a remote controller can not operation can realize video camera, take photos and shutdown functions. When used for remote control signal emission of infrared light reception of the camera, can press button after operation video, photo, or turn it off...
-
Page 19: Remote Controller Battery Replacement
9.3 Remote controller battery replacement When the remote control battery is low, need to replace the battery, please be careful open the battery door with a coin, avoid scratching by the appearance of the battery door. When replacing the batteries, the groove will coin card cover in the middle of the battery, according to the instructions of the battery cover unscrewing direction of the old battery, will be replaced by a new battery (batteries are installed note the positive and negative pole), then the battery cover and screw. - Page 20 10. Connect to computer to download photo/video When the camera is connected with the computer and entering removable disk mode, there will be a removable disk added in the window of “My computer”. The photo or video file may be stored in the catalogue of “DCIM\100MEDIA”...
- Page 21 Technical parameters Technical parameters Image sensor 5.0 mega-pixel CMOS image sensor Function mode Recording, photo, playback Lens F2.5 f=3.53mm Digital zoom LCD screen 2.0” LCD screen Picture resolution 12M (4000 x 3000), 8M (3264 x 2448), 5M (2592 x 1944), 3M (2048 x 1536) FHD (1920x1080 30fps)，...
- Page 22 USB port USB 2.0 Power supply Built-in 3.7V rechargeable lithium battery Menu language English/Simplified Chinese/Traditional Chinese Power Save 1 min. / 3 min./5 min./ OFF Operating system Windows XP/Vista/7/8, Mac 10.2 requirements Dimensions 58x44x23mm Note: The product design specification is made based on updated information when compiling this product manual.
