A.E.B. INDUSTRIALE s.r.l.
Via Brodolini, 8 - 40056 Crespellano (Bo) - ITALIA
Tel. + 39 051 969870 - Fax. + 39 051 969725
Internet: www.dbtechnologies.com
E-mail: info@dbtechnologies-aeb.com
S
Digital Vertical Array
Digital Vertical Array
1 1
5 5 2 2
1 1
MANUALE d'USO - Sezione 1
USER MANUAL - Section 1
BEDIENUNGSANLEITUNG - Abschnitt 1
CARACTERISTIQUES TECHNIQUES - Section 1
COD. 420120188A Rev 5.0
Made in Italy
Advertisement
Table of Contents
Related Manuals for AEB DVA S1521N
Summary of Contents for AEB DVA S1521N
- Page 1 Via Brodolini, 8 - 40056 Crespellano (Bo) - ITALIA USER MANUAL - Section 1 Tel. + 39 051 969870 - Fax. + 39 051 969725 BEDIENUNGSANLEITUNG - Abschnitt 1 Internet: www.dbtechnologies.com CARACTERISTIQUES TECHNIQUES - Section 1 E-mail: info@dbtechnologies-aeb.com Made in Italy COD. 420120188A Rev 5.0...
-
Page 2: Comandi E Funzioni
Sezione “Status” acustico, la risposta in frequenza ed il limiter. Il DVA S1521N è in legno di betulla, studiato per sonorizzare ambienti medio grandi; è INDICATORE LUMINOSO “LIMITER” costruito utilizzando la tipologia “BASS REFLEX” che permette di ottenere alte pressione Questo indicatore s’illumina di colore rosso per indicare l'intervento del circuito... - Page 3 ® rilancio di alimentazione di rete. amplificatore DVA S1521N tramite un computer ed un programma dedicato. Questa presa ha lo scopo di rilanciare l’alimentazione ad un altro diffusore riducendo i collegamenti diretti alla rete. Gli assorbimenti massimi degli amplificatori sono riportati sul pannello dell’amplificatore.
-
Page 4: Dati Tecnici
Input Control Status Link Limiter Active +4dB Signal Data Mute/Prot Input Ready TECHNOLOGIES TECHNOLOGIES Input Link Input Sens Audio Balanced Input/Link mSec 0° Service 180° Data Digital Vertical Array Data 5 5 2 2 Remote Phase Delay Link Xover Frequency Preset selection 24dB/oct Active... -
Page 5: Controls And Functions
"Status" section DVA S1521N is made of birch wood, designed for medium size rooms. The subwoofer speaker is made using "BASS REFLEX" which produces high pressure and a deep bass “LIMITER”... -
Page 6: Loudspeaker Installation
“Service Data USB” Connector Main power supply linking Via this USB connector, it is possible to update the firmware of the DVA S1521N On the rear of the speaker, a Neutrik POWER CON® connector (grey) offers linking the amplifier module using the computer and a dedicated program. -
Page 7: Technical Specification
Input Control Status Link Limiter Active +4dB Signal Data Mute/Prot Input Ready TECHNOLOGIES TECHNOLOGIES Input Link Input Sens Audio Balanced Input/Link mSec 0° Service 180° Data Digital Vertical Array Data 5 5 2 2 Remote Phase Delay Link Xover Frequency Preset selection 24dB/oct Active... -
Page 8: Bedienelemente Und Funktionen
BEDIENELEMENTE UND FUNKTIONEN BESCHREIBUNG Der DVA S1521N Subwoofer ist mit einem hohen Hochleistungs-Verstärker DigiPro Abschnitt “Balanced Audio” 1500S der digipro ® G2-Serie ausgestattet und liefert 1500 W RMS . Die Versorgungsspannung des Verstärkers DIGIPRO® wurde für den Fullrange-Betrieb EINGANGSBUCHSE "INPUT”... - Page 9 MERKMALE UND SCHUTZ Abschnitt “SUB Phase/Delay” Frontverkleidung A n g e s i c h t s d e s p r o f e s s i o n e l l e n E i n s a t z e s d i e s e r L a u t s p r e c h e r s i n d WAHLSCHALTER “PHASE”...
-
Page 10: Technische Daten
4 3 5 6 Input Control Status Link Limiter Active +4dB Signal Data Mute/Prot Input Ready TECHNOLOGIES TECHNOLOGIES Input Link Input Sens Audio Balanced Input/Link mSec 0° Service 180° Data Digital Vertical Array Data 5 5 2 2 Remote Phase Delay Link Xover Frequency... -
Page 11: Commandes Et Fonctions
Signal Processing) gère le croisement audio des composants acoustiques, la réponse Section “Status” en fréquence et le limiteur DVA S1521N est un diffuseur actif en bois de bouleau, étudiés pour la sonorisation INDICATEUR LUMINEUX “LIMITER” des lieux moyennement grands, est réalisée en utilisant la typologie “ BAND PASS ”, Cet indicateur s'allume de couleur rouge pour indiquer l'intervention du circuit qui permet d'obtenir des pressions acoustiques élevées et un son de basse profonde. - Page 12 CARACTERISTIQUES ET PROTECTION Section “SUB Phase/Delay” Grilles frontales SÉLECTEUR “PHASE” Etant donné l'utilisation professionnelle de ces diffuseurs, les composant sont protégés Ce sélecteur permet d'obtenir une rotation de 180° du signal audio reproduit par frontalement par une tôle percée d'une épaisseur de 1,5 mm et mousse interne. le caisson de grave.
- Page 13 Input Control Status Link Limiter Active +4dB Signal Data Mute/Prot Input Ready TECHNOLOGIES TECHNOLOGIES Input Link Input Sens Audio Balanced Input/Link mSec 0° Service 180° Data Digital Vertical Array Data 5 5 2 2 Remote Phase Delay Link Xover Frequency Preset selection 24dB/oct Active...
- Page 14 SCHEMA A BLOCCHI COLLEGAMENTI BLOCK DIAGRAM CABLE CONNECTIONS BLOCKSCHALTBILD VERKABELUNG DIAGRAMA EM BLOQURES CABLAGE Balanced Audio PUSH Input Digital Vertical Array Link Balanced Audio PUSH Input Digital Vertical Array Link Balanced Audio PUSH Input Digital Vertical Array Link Balanced Audio PUSH Input Digital Vertical Array...
- Page 15 INSTALLAZIONE INSTALLATION INSTALLATIONEN INSTALLATIONS In appoggio con flybar (opzione DRK 10) Groundstack with flybar (DRK 10 option) In appoggio In appoggio - impilato Groundstack Groundstack - stacked...
- Page 16 Opzione DSA 4 DSA 4 Option In appoggio Floor stack Per supporto asta Stand adaptor In appoggio a pavimento con supporto asta provvisto di piedi Groundstack to floor with stand adaptor with feet Set di 4 ruote - opzione SWK 18 Set of 4 wheels - SWK 18 option In appoggio son supporto su asta per Groundstack with stand adaptor...
- Page 17 Nota: E’ possibile montare 4 piedi in gomma sul fianco per utilizzo in appoggio (in dotazione) CONFIGURAZIONE CARDIOIDE Note: It is possible to mount 4 rubber feet on the CARDIOID CONFIGURATION side for bookshelf use (provided) Anmerkung: Es ist moglich, 4 Gummifu e auf die ß...
