Summary of Contents for FMUser FUTH804B 2010
- Page 1 Operating Manual Telephone Hybrid F U TH804B (2010) Broadcast System Equipment Version 2.0...
- Page 2 Suzhou Fortune Technology Co., Ltd persists in sustainable strategy. Part of the additional or revised functions does not included in the manual; please pay attention to additional announcement. Please refer to the latest user manual in the following website: http://www.fmuser.net Service Hotline:...
-
Page 3: Safety Instructions
Model: Description: Software Version: Hardware Version: Product No.: Safety Instructions Please read the following simple rules. Breaking these rules will probably lead to Symbol Illustration risk and violation laws. This manual provides detail information about safety The lightning flash with instructions. - Page 4 Important Notice All the safety and operating instructions should be read before the appliance is operated. The safety and operating instruction should be retained for further reference. Warning To reduce the risk of electrical shock, short circuit, damage, fire and other dangers, make sure to follow the following instructions which may not cover all.
-
Page 5: Contents Of The Package
Fortune Professional Audio Coupler Website Http:// www.fmuser.net Contents of the Package The Package consists of the following components: ●TH804B Hotline access and control device (Master equipment) 1 set ●TH804B Telephone Control box 2 sets ●Control Cable (2.5M &7.5M) 2 pcs ●Power Cord... -
Page 6: Table Of Contents
Content 1. Introduction………………………………………………………………………………1 Features………………………………………………………………………….…...1 Specifications………….…...…………………………………………………………1 2. Function……………………….…………………………………………………………2 3. Structure & Installation………………………………………………………………….3 Front & Rear Panel………..………………………………………………………….3 Control box……………….………………………………………….………………...5 4. Operation…………………………………………………………….………..…………6 Installation Setting……………………………………………………………………...6 Function Operation…….…………………………………………………………….…8... -
Page 7: Introduction
Introduction TH804B Telephone hybrid coupler is the professional telephone call-in and control equipment, which was designed for live broadcasting program on all kinds of radios and television programs in living, and also suitable for teleconference or telephone record. Features: Four Channels Call-in, Multiparty Call Selection of Audio &... -
Page 8: Function
Functions ◇ TH804B Telephone Hybrid is the professional telephone call-in and control equipment, which was designed for the live broadcasting program on radio and TV, and also suitable for teleconference or telephone record. ◇ With the technology of microprocessor chip and electric switch, it can realize the function of separate control of each channel, convenient operation of cut-in and cut-out, at most four channels call-in at the same time and the module of multi-party call &... -
Page 9: Structure & Installation
Structure & Installation Front & Rear Panel Front Panel Rear Panel (1)TEL OUT LEVEL The adjustment button for high-low signal from live room to phone line with level indicator. (2) TEL IN LEVEL The adjustment button for high-low signal from phone line to live room with level indicator. - Page 10 (7) Power switch (8) Power plug (9) Fuse block (0.25A) (10) Control cable interface The control cable interfaces are connected with studio, live room2 and live room2 from left to right. (11) Audio in-out interface The audio in-out interfaces are hybrid input, to live room1, to live room2,.from live room2,and from live room2 from left to right.
-
Page 11: Control Box
Control Box Control box panel Rear panel interface （1）Loudspeaker （2）Interphone （3）Volume adjustment for loudspeaker （4）Power indicator light （5）Interphone indicator light （6）Interphone button （7）Indicator light for status of hotline call （8）Out-in switch for hotline call （9）Control cable interface （10）Interface for output of external loudspeaker Interphone signal will be output after plugging in a 6.35mm three-pin plug and disconnecting the loudspeaker. -
Page 12: Operation
Operation Installation Setting 1. Proposed to install the master equipment in the major studio, LINE for call from outside and PHONE for call from instructors. 2. Connect the studio box to the “DIRECTOR” interface of master equipment; connect the living box to live ROOM1 and ROOM2 interface of master equipment. (Remark: The boxes for studio and living are the same, just with the different interfaces connected to master equipment.) 3. - Page 13 The location map for Anti-side tone adjusted-switch and adjusted-POT 6. Installation and adjustment for internal communication The internal communication can be used after the installation for director’s and live room’s control box. Method: Press “TALKBACK”, speak to microphone, if the local box is green light and red light for other side box, internal communication is getting through.
-
Page 14: Function Operation
7. Thunder precaution As the device is connected with the local telephone line, in the spring and summer it is vulnerable by thunder and lightning. TH804B has the lightning protection device inside, in order to protection better, the case should be ground protected well with a 3-pin cable ground connection. - Page 15 Auto-direct Model Auto-direct Model is suitable for calls cut-in and cut-out automatic if the radio host is in live broadcast only. Press the button1# and 3# of control box in studio, at the same time open the equipment and then turn into the Auto-direct Model. The AUTO light is on; If press the button2# and open the equipment, it will quit out from Auto-direct Model and AUTO light is out.
-
Page 16: Order Information
ORDER INFORMATION ● Interview & Edit System and Coupler ◎ DJ200+ Digital Audio Interview Recorder ◎ Best Edit nonlinear Audio Editor ● Broadcast Control System and Coupler ◎ RadioPro2.0 Digital Audio Workstation System ◎ DY3000 Professional Radio Broadcast Digital Audio Delayer ◎...
