Summary of Contents for Displax Oqtopus
- Page 1 TECHNOLOGY FOR THE MULTITOUCH GENERATION DISPLAX OQTOPUS USER GUIDE...
-
Page 2: Table Of Contents
USING NON EUROPLUG POWER SOCKETS ................13 ATTACH THE GLASS AND METALLIC GRID BACK TO THE TABLE ........13 INSTALL SOFTWARE ON THE PC .....................13 SETTING UP DISPLAX OQTOPUS ................14 SKIN MULTITOUCH CONFIGURATION ..............15 DISASSEMBLE OQTOPUS ..................... 16 DISASSEMBLE THE LEGS WITHOUT OPENING THE TABLE ..........16 DETACH THE PCB CONTROLLER .....................16... -
Page 3: Packing List
PACKING LIST Oqtopus shipment contains the following equipments/components: Table 1 unit Legs 4 units Cube 1 unit Keys 2 sets (4 units) Screws legs 16 units Washers 32 units Screws cube 4 units ... -
Page 4: General Information
When moving the table, always hold it by the bottom (white structure) and never by the glass. , a strong material. The top is made of glass, has a metallic grid attached and a DISPLAX Skin Multitouch laminated on the inside. The top piece must be handled with extreme care to avoid damaging Skin Multitouch. -
Page 5: Other Information
If you are not using the default PC unit make sure to check the architecture of the processor and select the correct driver. SKIN MULTITOUCH USER GUIDE DISPLAX Oqtopus uses Skin Multitouch for touch detection The User Guide can be downloaded to answer any questions regarding the touch technology. http://www.displax.com/downloads/UserGuides/DisplaxSkinMultitouch.php OTHER INFORMATION The serial number is placed underneath the table, at the center. -
Page 6: Product Description
PRODUCT DESCRIPTION A. Table (white corian) Power cable with male connecter and a triple plug B. Glass (with DISPLAX Skin Multitouch and metallic grid) C. White iron base D. Cube Legs One of the legs has an electric cable with a female connector Screws for the leg (16) G. - Page 7 MKT.183.5 | DISPLAX OQTOPUS USER GUIDE...
-
Page 8: Leg Assembling
Push the female connector from Ea up through D. Unscrew C from A. Attach C to D using I. Make sure you pull the electric cable through C before. The longer edge of C must be aligned below. MKT.183.5 | DISPLAX OQTOPUS USER GUIDE... - Page 9 Attach A back to C making sure you align the USB door of A with the hole in C. This task is better performed using 3 persons. While two hold A, a third one connects Ea to Aa. Then A should be placed over C and screwed. MKT.183.5 | DISPLAX OQTOPUS USER GUIDE...
- Page 10 Every time you need to move DISPLAX Oqtopus from one place to another make sure to always hold it by the white corian tray and never by the glass. MKT.183.5 | DISPLAX OQTOPUS USER GUIDE...
-
Page 11: Controller Lcd And Pc Installation
CONTROLLER LCD AND PC INSTALLATION DISPLAX OQTOPUS COMES WITH LCD AND PC INSTALLED UNLESS ASKED OTHERWISE. IF YOU ORDERED DISPLAX OQTOPUS WITH LCD AND PC ASIDE YOU MUST READ THIS CHAPTER. SEPARATE THE METALLIC GRID AND THE GLASS FROM THE TABLE Unscrew the 10 screws H that connect B to A. -
Page 12: Install The Pc
Connect the loose end of N to M Align the VESA holes of M with the holes on A and use J to screw M to A, using the four holes underneath A. TIP: screw in diagonal order. MKT.183.5 | DISPLAX OQTOPUS USER GUIDE... -
Page 13: Using Non Europlug Power Sockets
Screw it again using H. TIP: Insert and screw just enough to hold all the screws and only then screw until the end. INSTALL SOFTWARE ON THE PC In the supplied unauthorized installation of software. To install software the admin password is required: #edgdisplax$ MKT.183.5 | DISPLAX OQTOPUS USER GUIDE... -
Page 14: Setting Up Displax Oqtopus
Turn off DISPLAX Oqtopus using the same process used to turn on. The PC that is shipped with Oqtopus has the driver for Skin Multitouch already installed. You should, nonetheless, learn how to handle the touch technology detection. To do so please go... -
Page 15: Skin Multitouch Configuration
SKIN MULTITOUCH CONFIGURATION To learn how to configure, fine tune and generic information about the touch technology used in DISPLAX Oqtopus, which is DISPLAX Skin Multitouch, please download the product documentation using the following links. DISPLAX Skin Multitouch User Guide http://www.displax.com/downloads/UserGuides/DisplaxSkinMultitouch.php... -
Page 16: Disassemble Oqtopus
Velcro strap match, to ensure it is in the correct position. DETACH THE GLASS TO ACCESS THE LCD OR CABLES Unscrew H from A Take B out, carefully holding by the glass edges. Always place it with the metallic grid facing down. MKT.183.5 | DISPLAX OQTOPUS USER GUIDE... -
Page 17: Care & Handling
Do not use alcohol (methyl, ethyl or isopropyl) or any strong dissolvent. Do not use thinner or benzene, abrasive cleaners or compressed air. Do not spill liquid of any kind to the interior of the table. MKT.183.5 | DISPLAX OQTOPUS USER GUIDE... -
Page 18: Support
SUPPORT If you require support or are experiencing problems, or if you have any queries, please MKT.183.5 | DISPLAX OQTOPUS USER GUIDE... - Page 19 For more detailed information contact: DISPLAX - MULTITOUCH TECHNOLOGIES Parque Industrial de Adaufe Rua Soldado Manuel Pinheiro Magalhaes, 68 4710 - 167 Braga Portugal +351 253 141 500 +351 253 265 507 www.displax.com E-mail touch@displax.com MKT.183.5 | DISPLAX OQTOPUS USER GUIDE...
