Summary of Contents for Johnson&Starley Dryflow E1004
- Page 1 Publication No. ZZ1342 March 2009 SAP Appendix Q Eligible E1004 Installation & Operating Instructions...
- Page 2 CONTENT Description Features Installation Wiring Diagrams Maintenance Dismantling & Recycling THIS LEAFLET MUST BE LEFT AVAILABLE FOR THE USER...
- Page 3 1. DESCRIPTION This E1004 extractor fan is for exhausting air directly outside or through medium lengths of ducting and is suitable for wall or ceiling installation. To ensure optimum operation and guarantee a long life, please read this manual carefully. It explains how to install correctly, use and maintain the product properly. Following these instructions will ensure the reliability of the product and extend its working life. The manufacturer will not be held responsible and will not accept any responsibility for damage caused to persons or things due to improper use with reference to the precautions outlined in this leaflet. .
- Page 4 • Always request original spare parts for repairs • If the product needs to be removed, turn off the mains supply circuit-breaker and then disconnect the fan. • The fan MUST BE installed as detailed in this leaflet WARNING: Damage could be caused to the product if the installation instructions are not followed • The product should not be used in an ambient temperature higher than 40°C (104°F). • The product should not be exposed to atmospheric agents (rain, sun, snow, etc.). • The product or its parts should not be placed in water or other liquids. • Routine maintenance as described below should be carried out to check the condition of the fan. • The air or fumes being extracted must be clean and free from greasy particles, soot, chemical and corrosive agents, flammable or explosive mixtures. • The product must be installed by professionally qualified personnel. Incorrect installation can cause damage to people, animals or property, for which the manufacturer cannot be held liable.
- Page 5 . INSTALLATION 1. Check there is nothing missing in box and that 2. Drill hole in wall - minimum dia 99.8mm instruction leaflet is included. - allow extra width if using ducting - it is the installer’s responsibility to use the appropriate core cutter to obtain the correct hole. 3. Use fan assembly as template to mark drill 4. Drill 3 x 6mm diameter holes.
-
Page 6: Wiring Diagrams
7. Make electrical connection . WIRING DIAGRAMS E1004 - JUMPER 8. The E1004 is designed to run continuously at one of 2 lower speeds fixed at installation using the jumper switch. Fan supplied ready for Speed 1 - lowest speed. Installer can change to Speed 2 if required. The user can boost the fan speed to its maximum performance by using remote switch. VIA LIGHT SWITCH VIA REMOTE ILLUMINATED SWITCH E1004 - 3 SPEED E1004 - 3 SPEED... - Page 7 9. Replace front cover. . MAINTENANCE Before any maintenance or cleaning operation, switch off the fan and disconnect it from the main power supply. The front cover and grille can be cleaned with a dry cloth or soft brush. The fan must not come into contact with any kind of liquid or solvent. If this should occur, contact a qualified technician before reassembling the fan. NOTE: The motor does not require lubrication as it is maintenance free “sealed for life” type. . DISMANTLING & RECYCLING This product has been designed and constructed using high-quality materials and components that can be recycled or re-used. Under the EU Directive 2002/96/EC on Waste Electrical and Electronic Equipment, this product must not be treated as household waste and should be disposed of accordingly.
- Page 8 Rhosili Road, Brackmills, Northampton NN4 7LZ Main Switchboard Tel: 01604 762881 Fax: 01604 767408 Spares Tel: 01604 707012 Fax: 01604 764879 Service Tel: 01604 707011 Fax: 01604 707017 www.johnsonandstarley.co.uk...
