Cheetah RadarDetector Interface User Manual

1 x In-line fuse unit (3 Amp)
1 x POWERSENSEnode engine running sensor
1 x Power cable
1 x RADARnode wireless transmitter
1 x RDI software card for the V1 (inserted in RADARnode)
1 x Radarnode connector cable
1 x Cheetah V1 remote adapter
1 x Cheetah connector cable for the V1
1 x User manual
Cheetah parts are pre-connected for your convenience. Our
2-pin mini connectors push-fit together and lock securely. To
unclip, press the lever down and gently pull them apart.
The RADARnode is a wireless transmitter (433 Mhz) that
connects up to your radar detector's power supply socket.
When your radar detector gives an alert, the RADARnode
digitally analyzes the alert data and transmits a radio code to
your helmet display.
The small flying lead with half a bullet connector at the end
(plastic sheathed) is an over-ride cable for connecting to a
Cheetah Laser Jammer Interface in motorcycle installations.
The POWERSENSEnode is a clever "engine running" sen-
sor that turns on power when you start up your motorcycle
and turns it off when you stop the engine. It's an instant,
"ignition-switched" supply that makes it quick and easy for
anyone to create a safe power supply directly from the battery
terminals. It eliminates the need for direct wiring into your
bike's electrical system.
The RADARnode Transmitter
Over-ride cable for
Cheetah LASERnode
Test button
RDI Software card
Power socket
Detector socket
