Sony ICF-SW11 Operating Instructions

Fm stereo/sw1-9/mw/lw 12 band receiver.
Hide thumbs


Advertisement

3-867-546-07(1)
FM
/SW
/MW/LW 12
1-9
FM Stereo/SW
/MW/LW 12 Band Receiver
1-9
사용설명서
Operating Instructions
ICF-SW11
© 1999 Sony Corporation
Printed in China
Telescopic antenna
TUNE
TUNING
VOLUME
2
DC IN 3V
Only for the
Japanese model and Sony
world model
Stand
A
'
Insert the
side of the battery first
'
B
FM
SW
MW/LW
1. POWER
2. BAND
FM SW1 9
MW
LW
3. TUNING
TUNE
4. VOLUME
POWER
OFF
FM
12
FM
FM
SW1-9 MW LW
FM
FM
SW
MW/LW
A
1.
2.
3
2
3
R6
JEITA
30
JEITA
2
AC
DC IN 3V
DC IN
3V
AC
DC IN 3V
AC
JEITA
AC
AC
ON
6
English
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
To avoid electrical shock, do not open the
cabinet. Refer servicing to qualified personnel
only.
Features
1
• FM Stereo/SW1-9/MW/LW 12 band receiver
with high sensitivity and selectivity
• Band spread system enables you to easily tune
2
in SW stations
• FM stereo reception through stereo
headphones (not supplied)
Choosing Power
FM: 87.5 - 108 MHz
Sources
B
76 - 108 MHz
Batteries
SW1: 4.750 - 5.060 MHz
1
2
3.850 - 4.050 MHz
SW2: 5.900 - 6.200 MHz
SW3: 7.100 - 7.350 MHz
SW4: 9.400 - 9.990 MHz
SW5: 11.600 - 12.100 MHz
SW6: 13.570 - 13.870 MHz
SW7: 15.100 - 15.800 MHz
Battery life
SW8: 17.480 - 17.900 MHz
Using Sony R6 (size AA) batteries:
Approx. 30 hours
SW9: 21.450 - 21.750 MHz
40°C
MW: 525 - 1620 kHz
Replacing batteries
LW: 141 - 290 kHz
When the sound becomes weak or distorted,
5.7 cm
4
1
replace all batteries with new ones.
140 mW JEITA
1
/DC
Notes on batteries
2
3.5 mm
• Do not charge the dry batteries.
• Do not carry the dry batteries with coins or
DC 3 V
3
2
• When you are not going to use the unit for a
DC IN 3V
162 93.8 34.8 mm
JEITA
1
340 g
House current
(Only for the Japanese model and
Sony world model)
Connect the AC power adaptor (not supplied) to
3
2
2
the DC IN 3V jack, and plug it into a wall outlet.
1
Be sure to firmly connect the jack and plug.
Power is automatically supplied from the
1
external power source even when the batteries
1
are placed in the receiver.
1
2
Notes on the AC power adaptor
• To prevent battery leakage, we recommend
removing the batteries when the receiver is
connected to a wall outlet.
AC
• When the AC power adaptor is not to be used
AC-E30L
for a long period of time, unplug it both from
the DC IN 3V jack and from the wall outlet.
LW/MW/SW
• Use only the recommended Sony AC power
AN-12 AN-102
adaptor (not supplied)*. Do not use any other
AC power adaptor.
1
JEITA
Polarity of the plug
1
2
* For details of the AC power adaptor (not
supplied), see "Specifications".
Operating the Radio
1
Set POWER to ON to turn on the radio.
2
Select a desired band using BAND.
3
Tune in a station using TUNING.
The TUNE indicator lights up when a
station is tuned in.
4
Adjust the volume using VOLUME.
To turn off the radio
Set POWER to OFF.
To listen with headphones (not
supplied)
For FM stereo, connect the stereo headphones to
the 2 (headphones) jack.
The speaker is deactivated when you connect the
headphones.
To improve reception (See fig. B)
FM: Extend the telescopic antenna and adjust the
angle for optimum reception.
SW: Extend the telescopic antenna vertically.
MW/LW: Rotate the unit horizontally for
optimum reception. A ferrite bar
antenna is built into the unit.
Precautions
(See fig. A)
• Operate the unit only on 3V DC. For battery
operation, use two R6 (size AA) batteries. For
AC operation, use only the recommended AC
Open the battery-compartment cover.
power adaptor.*
Insert two R6 (size AA) batteries (not
• The unit is not disconnected from the AC
supplied) with correct polarity.
power source (mains) as long as it is connected
to the wall outlet, even if the unit itself has
A ribbon is attached to the battery-
been turned off.*
compartment cover to prevent the cover from
• Do not leave the unit in a location near heat
falling accidentally. Place the ribbon across
sources, or in a place subject to direct sunlight,
the inserted batteries and close the battery-
sand, excessive dust, or mechanical shock.
compartment cover. Do not pull out the
• The nameplate indicating operating voltage,
ribbon forcibly. Otherwise, the ribbon may be
etc. is located on the rear exterior.
detached.
• Should any solid object or liquid fall into the
unit, disconnect the AC power adaptor and
remove the batteries, and have the unit
checked by qualified personnel before
operating it any further.*
• Since a strong magnet is used for the speaker,
keep personal credit cards, etc., using magnetic
coding away from the unit.
• When the casing becomes soiled, clean it with a
soft cloth dampened with mild detergent
solution. Never use abrasive cleansers or
chemical solvents, as they may mar the casing.
• In vehicles or in buildings, radio reception may
be difficult or noisy. Try listening near a
other metallic objects. It can generate heat if
window.
the positive and negative terminals of the
batteries are accidentally contacted by a
* The AC power adaptor can be used for the
metallic object.
Japanese model and Sony world model only.
long time, remove the batteries to avoid
If you have any questions or problems
damage from battery leakage and corrosion.
concerning your unit, please consult your nearest
Sony dealer.
Specifications
Frequency range:
FM: 87.5 - 108 MHz (Chinese model)
76 - 108 MHz (Other models)
SW1: 4.750 - 5.060 MHz (Chinese model)
3.850 - 4.050 MHz (Other models)
SW2: 5.900 - 6.200 MHz
SW3: 7.100 - 7.350 MHz
SW4: 9.400 - 9.990 MHz
SW5: 11.600 - 12.100 MHz
SW6: 13.570 - 13.870 MHz
SW7: 15.100 - 15.800 MHz
SW8: 17.480 - 17.900 MHz
SW9: 21.450 - 21.750 MHz
MW: 525 - 1 620 kHz
LW: 141 - 290 kHz
Speaker
1
inches) dia., 4 Ω
Approx. 5.7 cm (2
/
4
Power output
140 mW (at 10 % harmonic distortion)
Output
2 (headphones) jack (stereo minijack, 3.5 mm
dia)
Power requirements
3 V DC, two R6 (size AA) batteries
External power source (Only for the Japanese
model and Sony world model)
DC IN 3V
Dimensions
Approx. 162 × 93.8 × 34.8 mm (w/h/d)
× 3
× 1
(6
1
/
3
/
3
/
inches)
2
4
8
Mass
Approx. 340 g (12 oz) incl. batteries
Supplied accessory
Short wave guide (1)
Optional accessories
AC power Adaptor* AC-E30L (in Japan)
LW/MW/SW wide range antennaAN-102
* The voltage of power supply is different
depending on the country. Please buy an AC
power adaptor in the country/region where the
radio is to be used.
Your dealer may not handle some of the above
listed accessories. Please ask the dealer for
detailed information.
Design and specifications are subject to change
without notice.
