OWNER'S MANUAL
FOR HOUSEHOLD USE ONLY
Please read this document carefully before installing and/or
using your WallyFlex.
HEAD OFFICE | CANADA
3, Marcel-Ayotte St | Blainville (Québec) J7C 5L7
Tel.: 450 434-2233 | Fax: 450 434-6111
info@trovac.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WallyFlex and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for WallyFlex WallyFlex

  • Page 1 OWNER’S MANUAL FOR HOUSEHOLD USE ONLY Please read this document carefully before installing and/or using your WallyFlex. HEAD OFFICE | CANADA 3, Marcel-Ayotte St | Blainville (Québec) J7C 5L7 Tel.: 450 434-2233 | Fax: 450 434-6111 info@trovac.com...
  • Page 2 When using this type of attachment, basic precautions should always be followed, including the following. Read all instructions before using this attachment. 1. Do not allow the WallyFlex to be used by young children. THIS PRODUCT IS NOT A TOY.
  • Page 3 Note: Make sure that the chosen location is fully accessible for the installation of pipes and low voltage wire (to the central vacuum unit). 2. The WallyFlex can be installed on a wall, or concealed in a closet or cabinet.We recommend that you install the WallyFlex console approximately at 48 inches (1.22 meters) from the floor.
  • Page 4 installation 3. Remove screw #1 and lift the cover of the console. screw #1 lift and open 4. Remove screw #2 and open the front panel of the console. and open 5. Pass low voltage wires through the opening at the back of the console. To facilitate the insertion, moisten the seal (o-ring) on the mounting plate.
  • Page 5 installation 7. Connect the low voltage wires to the terminal screws. 8. Close the front panel of the console, ensuring the tabs on the door and console are screw align and close screw lower...
  • Page 6 11. Insert the hose into the bottom of the console, and secure by rotating the hose clockwise until it clicks. 12. Insert the nozzle into the console. The installation of the WallyFlex is now completed. For more information, contact your local authorized dealer.
  • Page 7 Note: When in use, for increased safety, the central vacuum unit can be stopped at any time, simply by pressing the switch on the WallyFlex console. * If your WallyFlex is not working as described in the owner’s manual, contact your local authorized dealer.
  • Page 8 For the maintenance of your WallyFlex, clean with mild soap on a soft, damp cloth. Never use: abrasives, liquid cleaners or aerosols - it may damage the finish of the console. general limited warranty Trovac Industries Ltd. («Trovac») offers a one-year general limited warranty for the WallyFlex, for domestic use only.
