Mobile Action Q-60 Q-Band User Manual

Q-60

Device Overview

Wristband

How to wear your Q-Band?

1
Wear Q-Band on your wrist
Put on the wristband with the screen facing up and the band
wrapped around your wrist. Align the clasp along the band to
find the holes where best fit the clasps.
3
Charge your Q-Band
To charge your Q-Band, plug the charging cable into a USB port and
attach the other end to the back of the Q-Band. A battery icon will
appear on the screen displaying the charging progress. It takes
around two hours to fully charge the battery.
Note: The metallic contact might affect the battery charging capability
if it's covered by grease that comes from natural oil secretion of
human body or those moisturizing lotions you apply on skin. It is
suggested that you may try using some sort of mild detergent like
pharmaceutical alcohol to sterilize the metallic contact on the charger
before charging the device, but avoid corrosive chemical cleaners.
Q-Band
Clasp
2
Fasten Q-Band with clasp
Squeeze both clasps into the holes on the wristband until you
hear a click, indicating the band is securely fastened.
4
Change the wristband
1
2
1. Spread open both bands with the screen facing up, and press down
the screen with your thumb until the core comes off the wristband.
Remove the clasp from the wristband as well.
2. Insert the core with screen facing down into the notch from the
inner side of wristband. Button up the clasp on the side of the band
with 2 holes. Please be noted that the charging contact should be
near the clasp.
User Manual
Button Core
Metallic contact for charging
EN
