Botex SD-10 User Manual

Smart director
Hide thumbs Also See for SD-10:
Table of Contents

Advertisement

Quick Links

See also: User Manual
English
USER'S MANUAL
R
SMART DIRECTOR
ON
DMX
AUDIO
MANUAL
POWER
RECORD/MODE
STROBE
PROGRAM
RECEIVE
SEND
BLACK-OUT
SPEED
FADE+SPEED/DEL
Please read before use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD-10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Botex SD-10

Summary of Contents for Botex SD-10

  • Page 1 English USER'S MANUAL SMART DIRECTOR AUDIO MANUAL POWER RECORD/MODE STROBE PROGRAM RECEIVE SEND BLACK-OUT SPEED FADE+SPEED/DEL Please read before use...

  • Page 3: Table Of Contents

    Contents Features 1 General Instructions 2 1. Overview 3 1.1 Front View 3 1.2 Back View 5 2. Operation Guide 6 2.1 Record Mode 6 2.1.1 Record Enable 6 2.1.2 Record Scenes 6 2.1.3 Delete a Program 7 2.1.4 Delete a Scene 8 2.1.5 Add a Scene 2.1.6 Change a Scene 9 2.1.7 Preview a Scene 10...

  • Page 4: Features

    Features Thank you for your purchase of this BOTEX product. This Smart Director features include: 96 DMX channels 9 chase programs & a AP program 9 strobe programs & a AS program Each chase/strobe program can record a maximum of 48 scenes...

  • Page 5: General Instructions

    General Instructions Read the instruction in this manual carefully and thoroughly, as they give important information regarding safety during use and maintenance. Keep this manual with the unit, in order to consult it in the future. If the unit is sold or given to another operator, make certain that it always has its manual, to enable the new owner to read about its operation and re lative instructions.

  • Page 6: Overview

    1. Overview 1.1 Front View AUDIO MANUAL POWER RECORD/MODE STROBE PROGRAM BLACK-OUT SPEED FADE+SPEED/DEL...
  • Page 7 1. Overview 1.1 Front View 1. Power Switch Move the slider to Up position to turn the power on. 2. Segment Display Shows the current activity or function state. 3. Up Button Tap the button to increase the display value. 4.

  • Page 8: Back View

    1. Overview 1.2 Back View DMX OUT DMX IN DC INPUT DC 12V 300mA min. Record Enable RECORD 5 Seconds until its LED Lights. Record Scenes Record Enable, PROGRAM / STROBE , RECORD to record Scenes. Record AS/AP Scenes Record enable, PROGRAM STROBE AS/AP program, RECORD ..

  • Page 9: Operation Guide

    2. Operation Guide 2.1 Record Mode 2.1.1 Record Enable Press and hold down the Record/Mode button for five seconds, the LED above it lights indicating Record mode is active, the Segment Display shows the program and its scene of last time. The DMX LED will light when DMX signal is present.

  • Page 10: Delete A Program

    2. Operation Guide 2.1.2 Record Scenes 4. Tap the Record button to record scenes. Create a desired scene on your DMX controller. Once the scene is satisfactory, tap the Record/ Mode button to record this scene as the first step, all LEDs flash briefly indicating you've record this scene into the program and the Segment Display shows the current step.

  • Page 11: Delete A Scene

    2. Operation Guide 2.1.4 Delete a Scene NOTE: You must record scenes before you can delete the scenes. 1. Record enable. 2. Repeat steps 2-3 in Record Scenes to select the program that holds the scene you wish to delete. 3.

  • Page 12: Add A Scene

    2. Operation Guide 2.1.5 Add a Scene NOTE: You must record scenes before and the program holds less than 48 scenes. 1. Repeat steps 1-3 in Delete a Scene. 2. Tap the Up/Down button to select the scene which you wish to add a new scene before. 3.

  • Page 13: Preview A Scene

    2. Operation Guide 2.1.6 Change a Scene 3. Create a scene on your DMX controller, tap the Record button to change the step(scene), all LEDs flash briefly indicating the old scene is replaced by the new one. 2.1.7 Preview a Scene NOTE: You must record scenes before you can preview the scenes.

  • Page 14: Exit Record Mode

    2. Operation Guide 2.1.8 Exit Record Mode P 3 0 0 Tap the Black-out button until the Record LED goes out, this unit is out of Record mode. 2.2 Record AS/AP Scenes 1. Record enable. 2. Tap the Up/Down button to select AS or AP . (AS for strobe program, AP for chase program) A P 0 0 3.
  • Page 15 2. Operation Guide 2.2 Record AS/AP Scenes 4. Create a scene on your DMX controller, tap the Record button, all LEDs flash briefly indicating you've record a scene(step) into this program. 5. Continue recording scenes until you've got a desired program. You may record a maximum of 60 scenes into this AP/AS program.
  • Page 16 2. Operation Guide 2.2 Record AS/AP Scenes 8. Tap Up/Down button to adjust the beat time or 3 2 5 fade time of the current step. A P 0 2 9. Tap the Program(for AP scenes) or Strobe(for AS scenes) button to enter next step. 10.

  • Page 17: Run Programs

    2. Operation Guide 2.3 Run Programs Every time you turn on this unit, it is always in Run mode, you may tap the Mode button to activate the programs with Audio/Manual/Auto mode. Be sure the programs have record scenes before you can run the programs. 2.3.1 Manual Mode 1.

  • Page 18: Audio Mode

    2. Operation Guide 2.3.2 Audio Mode 1. Tap the Mode button several times until the a dot LED near Audio lights. 2. Tap the Program or Strobe button to select S 2 0 2 chase program or strobe program. S 3 0 5 3.

  • Page 19: Auto Mode

    2. Operation Guide 2.3.3 Auto Mode 1. Tap the Mode button several times until both Manual and Audio LEDs go out, that is, Auto mode is active. P 3 0 6 2. Tap the Up/Down button to select the program you wish to run.

  • Page 20: Send Data File

    2. Operation Guide 2.4 Speed Setting 2. Tap the Up/Down button to adjust the speed 2 0 5 within 0.1-600 seconds, the Segment Display shows the current speed. For Example: 1:00 represents 1 minute, 1.00 represents 1 second. S 2 0 2 3.

  • Page 21: Receive Data File

    2. Operation Guide 2.5 Send Data File 3. Before you can send data file, make sure the receiving unit has been in "RECEIVE" mode so that it can receive correct and complete data file. Tap the Fade+Speed button to send data file. During the course of sending, all other operation doesn't work.

  • Page 22: Black-Out Mode

    2. Operation Guide 2.6 Receive Data File 3. Tap the Fade+Speed button to receive data file, the Segment Display shows "IN". Attention: please be sure you proceed receiving before sending so that you can receive complete data file. During the course of sending, all other operation doesn't work.

  • Page 23: Initialization

    2. Operation Guide 2.7 Black-out Mode 3. Tap the Fade+Speed button to change between "N-BO" and "Y-BO". 4. Tap the Program button to leave this P 2 0 2 mode. 2.8 Initialization All the programs are blank when this unit is packed. If you are not satisfied with your programs, you can initialize this unit to clear all memory.

  • Page 24: Technical Specifications

    DMX Out/In ........ 3 pin female & male XLR socket Audio Input ..........By built-in microphone Fuse(Internal) ..........F0.5A 250V 5x20mm Accessory ........... AC/DC adaptor x1PC Dimensions ............190X80X31mm Weight ................0.52 Kg All Rights Reserved! 24-004-0556 E-mail: info@botex.com Rev 1.3 Web Site: www.botex.com...
