wood shark 2275 Instruction Manual

Hide thumbs

Table Of Contents

INSTRUCTION MANUAL

IMPORTANT INFORMATION: Please read these instructions carefully

and make sure you understand them before using this unit. Retain these

instructions for future reference.

MANUEL D'INSTRUCTIONS

RENSEIGNEMENTS IMPORTANTS: Avant d'utiliser cet appareil,

veuillez lire atentivement les instructions et assurez--vous de les avoir

comprises. Conservez les instructions pour référence ultérieure.

BETRIEBSANWEISUNG

WICHTIGE INFORMATION: Lesen Sie diese Hinweise zur Handha-

bung des Geräts aufmerksam durch. Verwenden Sie es erst, wenn

Sie sicher sind, daß Sie alle Anweisungen verstanden haben und

gut aufbewahren.

MANUAL DE INSTRUCCIONES

INFORMACIÓN IMPORTANTE: Lea atentamente las instrucciones y

asegúrese de entenderlas antes de utilizar esta aparato. Conserve las

instrucciones para la referencia en el futuro.

545123686 Rev. 2 1/31/07 BRW

Table of Contents

Need help?

Do you have a question about the 2275 and is the answer not in the manual?

Questions and answers

Summary of Contents for wood shark 2275

Page 1 INSTRUCTION MANUAL IMPORTANT INFORMATION: Please read these instructions carefully and make sure you understand them before using this unit. Retain these instructions for future reference. MANUEL D’INSTRUCTIONS RENSEIGNEMENTS IMPORTANTS: Avant d’utiliser cet appareil, veuillez lire atentivement les instructions et assurez--vous de les avoir comprises.
Page 2: Identification Of Symbols
IDENTIFICATION (WHAT IS WHAT?) Chain Front Handle Front Hand Guard Adjustment Tool Starter Rope (Bar Tool) Idle Speed Screw ON/STOP Muffler Switch Chain Primer Bulb Bumper Starter Spike Bar Oil Fill Cap Fuel Mix Fill Cap Housing Cylinder Cover Chain Throttle Direction Lockout...
Page 3: Safety Rules
IDENTIFICATION OF SYMBOLS Starting Reminder Move ON/STOP switch to Pull the starter rope the ON position. sharply 5 times with your right hand. Push the choke/fast idle Slowly press primer bulb lever in to the HALF 6 times. CHOKE position. Pull choke/fast idle lever Pull the starter rope sharply out to the full extent (to...
Page 4 S Do not operate a chain saw that is dam- S Rotational Kickback can occur when the aged, improperly adjusted, or not com- moving chain contacts an object at the up- pletely and securely assembled. Always per tip of the guide bar. This contact can replace bar, chain, hand guard, or chain cause the chain to dig into the object, brake immediately if it becomes damaged,...
Page 5: Maintain Control
manufacturer’s chain sharpening and main- S Do not cut above shoulder height. It is diffi- tenance instructions. Check tension at regu- cult to maintain control of saw above lar intervals with the engine stopped, never shoulder height. with the engine running. Make sure the bar KICKBACK SAFETY FEATURES clamp nuts are securely tightened after ten- sioning the chain.
Page 6: Chain Brake
from a servicing dealer, or to the nearest au- DO NOT ASSUME THAT THE CHAIN thorized master service dealer. BRAKE WILL PROTECT YOU IN THE S Tip contact in some cases may cause a EVENT OF A KICKBACK. lightning fast reverse REACTION, kicking SAFETY NOTICE: Exposure...
Page 7: Chain Tension
Adjusting the tension: Depth Gauge Cutters Chain tension is very important. Chain stretches during use. This is especially true during the first few times you use your saw. Always check chain tension each time you use and refuel your saw. You can adjust the chain tension by loosening the chain brake Drive Links nuts and turning the adjusting screw 1/4 of a...
Page 8 STARTING A COLD ENGINE (or a FUELING ENGINE warm engine after running out of WARNING : Remove fuel cap slowly fuel) when refueling. NOTE : In the following steps, when the cho- This engine is certified to operate on unleaded ke/fast idle lever is pulled out to the full ex- gasoline.
Page 9: Important Points
CHAIN BRAKE Braking function control CAUTION: The chain brake must be WARNING : If the brake band is worn checked several times daily. The engine too thin it may break when the chain brake is must be running when performing this proce- triggered.
Page 10 S DO NOT cut down a partially fallen tree with Plan a clear retreat path your saw. Be extremely cautious with par- tially fallen trees that may be poorly sup- ported. When a tree doesn’t fall completely, set the saw aside and pull down the tree with Direction of Fall a cable winch, block and tackle, or tractor.
Page 11: Limbing And Pruning
LIMBING AND PRUNING First cut on pressure side of log WARNING : Be alert for and guard against kickback. Do not allow the moving chain to contact any other branched or objects Second cut at the nose of the guide bar when limbing or pruning.
Page 12: Service And Adjustments
SERVICE AND ADJUSTMENTS sary to service your bar. A worn bar will dam- WARNING age your chain and make cutting difficult. : Disconnect the spark After each use, ensure ON/STOP switch is plug before performing maintenance, except in the STOP position, then clean all sawdust for carburetor adjustments.
Page 13: Troubleshooting Table
CHAIN SHARPENING STORAGE Chain sharpening is a complicated task that WARNING requires special tools. We recommend that : Stop engine and allow to you refer chain sharpening to a professional cool, and secure the unit before storing or chain sharpener. transporting in a vehicle.
Page 14: Declaration Of Conformity
DECLARATION OF CONFORMITY EC Declaration of Conformity (Only applies to Europe) We, Husqvarna Outdoor Products Italia, S.p.A., Valmadrera, Italy. Tel: +39- -0341- -203211, declare that the chain saw model Woodshark 2775 CSI---AV from serial numbers 2004- -136(N or D) 00001 and onwards (the year is clearly stated on the rating plate, followed by the serial number), comply with the requirements of the COUNCIL’S DIRECTIVES: of 22 June 1998 “relating to machinery”...
Page 15: Technical Data Sheet
TECHNICAL DATA SHEET MODEL: Woodshark 2275 ENGINE Cylinder volume, cm Stroke, mm Idle speed, rpm 3000 Recommended max speed, unloaded, rpm 13000 Power kW IGNITION SYSTEM Manufacturer Walbro Type of ignition system Spark plug Champion Electrode gap, mm FUEL AND LUBRICATION SYSTEM...
