  • Page 1 Professionally approved products. Instruction Manual RS 3D Printer...

  • Page 2: Software Installation

    RS 3D Printer. Please read these instructions carefully and save them for future reference. 2) WARNING Place RS 3D Printer in a dry environment and keep a safe distance from other  Shovel Chisel Cut pliers objects, fire or water.
  • Page 3 3D Printer/English might be not compatible with RS 3D Printer. The driver for software is in the SD card. Please copy the driver to your  Please shutdown all firewalls or antivirus software before installing  Doraware. “Disable Driver Signature Enforcement” is required for Windows 8 or 8.1.
  • Page 4 3D Printer/English 5.2.5 Select [install]. (Pic 5.2-05) (Pic 5.2-01) (Pic 5.2-05) 5.2.6 Select [Finish] to complete software installation. (Pic 5.2-06) (Pic 5.2-02) (Pic 5.2-06) 5.2.3 Click [next]. (Pic 5.2-03) 5.3 Confirm installation for Windows 7, 8 or 8.1 5.3.1 Right click「Computer」, select「Manage」, and then select「Device Manager」.

  • Page 5: Preparation For Printing

    Notice: Please insert the SD card into RS 3D Printer before printing, otherwise the software will not be able to connect RS 3D Printer. If RS 3D Printer is disconnected with your pc due to interruption, please pull out and re-insert the USB cable.

  • Page 6: Pic

    (Pic 6.1-05) 6.1.1 Turn on the Power Switch of RS 3D Printer, and connect your pc with RS 3D Printer by the USB cable. Open DoraWare-W 1.0, click [Flush] and select the Put a business Combo, then click [Connect] to connect RS 3D Printer.
  • Page 7 Click [Size setting], new data will be saved on the program. (Pic 6.2-01) Notice: each RS 3D Printer may have different Z-height. In this case, it is 7) FILAMENT 145.5mm. Please follow this User Manual and save the Z-height of RS 3D Printer.
  • Page 8 7.1.1 Load the filament spool on the spool holder, and install the filament tube 7.1.4 After reaching the Target Temperature (220℃, see 4.2.1), click guide in the tool box on RS 3D Printer by a screw. (Pic 7.1-02) 「Forward」until the filament emerges from the nozzle. Click「Stop」to discontinue the process or it will stop automatically after 10 seconds.

  • Page 9: Maintenance Instruction

    3D Printer/English 8) MAINTENANCE INSTRUCTION 1.Cut the end to be flat and hold the left filament straight. 8.1 Functions 2. Bended filament will block the 8.1.1 Software interface(Pic 8.1-01) extruder. Editing menu Main menu Model display area (Pic 7.2-01) 3-axis reference Keeping pushing down the leftover filament until the filament get stuck into the gear.
  • Page 10 3D Printer/English 8.1.7 The Property on the right side contains: [Model Edit], [3 Axis], and [Extruder]. Model Edit includes: [Edit Model], [Configuration parameter] and [Generate Gcode]. (Pic 8.1-08) (Pic 8.1-04) 8.1.4 There are 14 function icons in total in the menu. (Pic 8.1-05) (Pic 8.1-05)
  • Page 11 3D Printer/English Click Ctrl and left mouse to choose more models. Pic d Pic e 8.2Setting Set the parameter according to the structure and size of model. (Pic 8.2-02) 8.2.1 Print Base 8.3 Generate Gcode With Print Base: When the parameter is set, click [Generate Gcode] and a green progress bar will appear.
  • Page 12 (Pic 8.4-03) 8.4.2 For offline printing, please click [SD] to save x3g file, and copy the x3g file to your SD card by the SD card reader, and then insert your SD card into RS 3D (Pic 8.4-07) Printer to select printing file. (Pic 8.4-04) Click [Yes] or [No] to discontinue or continue printing.
  • Page 13 9) MAINTENANCE INSTRUCTION Extruder Blocking 9.1.1 Connect RS 3D Printer with your pc, increase the extruder temperature from 220℃ by 5-10℃ each time, click [Forward] and push the filament by hand to extrude the filament until the filament emerges from the nozzle. (Pic 9.1-01) 9.1.2 If the nozzle is coated by filament, please heat up the extruder temperature...

  • Page 14: After Sales Service

    3D Printer/English (Pic 9.1-02) 10) AFTER SALES SERVICE Each RS 3D Printer has a unique identifier, which is an 11 digits series number. (Pic 10-01) Please provide this number with pictures/videos of your problem for after sales service. (Pic 10-01)
