Summary of Contents for YF BEAM 230
- Page 1 Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com BEAM 230 MOVING HEAD User Manual...
-
Page 2: Table Of Contents
Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com Catalogue 1、Open-package inspection ----------------------------------------------------------------------page2 2、Attentions-----------------------------------------------------------------------------------------page2 3、Technical Parameter-------------------------------------------------------------------------page2 3、Install----------------------------------------------------------------------------------------------page2 4、The install and exchange of lamp-------------------------------------------------------------page3 5、The connecting of the signal cable------------------------------------------------------------page3 6、Button Introduction------------------------------------------------------------------------------page4 7、Executive function and start editing, exit editor---------------------------------------------page4 8、Interface introduction---------------------------------------------------------------------------page5 9、Channels------------------------------------------------------------------------------------------page7 10、 ---------------------------------------------------------------------------page8 Problems and Solutions 11、Maintenance------------------------------------------------------------------------------------page8... -
Page 3: Open-Package Inspection
Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com 1、Open-package inspection First of all thank you for buy our products.Please read this user manual completely and carefully, and keep it well for reference when needed. This use manual includes important information about the installation and using of the moving head. Please hew to the relevant specification strictly when install and use this product. -
Page 4: Install
Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com 4. Lamp：5R Philips/7R Osram 5. Bulb power：189W/230W 6. Strobe：1-13times/second 7. Color temperature：8000K 8. Horizontal scanning 540 degrees, Horizontal 16 bit, electronic error correction, vertical scanning 270 degrees, vertical 16 bit, electronic error correction. 9. Gobo：17 gobo add white and stream effect,gobo electric focus function 10. -
Page 5: The Connecting Of The Signal Cable
Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com 5、Installation and change of the Lamp 1. In order to prolong the life of the moving head light as far as possible, please choose the same type of lamp for it. 2. First of all to unscrew the four screws on the back cover of the moving head light, then open the back cover, pinch the ceramic holder of the bulb and anti-clockwise rotation 90°，... -
Page 6: Executive Function And Start Editing, Exit Editor
Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com 7、Button Instruction The “LEFT”, “RIGHT” button have the same function: Return to the last interface “UP”, “DOWN” button: Select, Edit “ENTER” button (the “OK”button): 8、Executive function and start editing, exit editor Below take “modify DMX address code”as an example, tell the use of the button: 1. -
Page 7: Interface Introduction
Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com 1. In the main interface touch the “set” button, come to the “setting”interface 2. The same to the up 4~7 step(can use both physical button and touch button), no more words. 9、 Interface introduction 9.1. - Page 8 Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com Tilt reversal Pan and Tilt exchange Exchange XY channels(including fine turning) Use encoder (light coupling) to judge the wrong Pan and Tilt encoder step and correct it automatically. Not use encoder(light coupling) to correct position...
-
Page 9: Channels
Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com 。 。 。 。 。 。 0-255 hundreds to change channel value according to the “UP”and “DOWN”button.Click”OK”again to select tens to Gobo wheel speed 0-255 edit,and then click”OK”again to select Units to edit.Click again to exit. -
Page 10: Problems And Solutions
Guangzhou Yingfeng Lighting Equipment Co.,Ltd www.yf-light.com 11、Problems and Solutions: problem solution No power supply Check the power supply voltage Power on,but the moving head Check the set of digital address code and the light do not accept the control connectivity of the control signal...
