- Page 1 User's Manual CM-040MCL/040MCL-RA CB-040MCL/040MCL-RA Digital Monochrome / Color Progressive Scan Camera Document Version: Ver.1.3 CM/CB-040MCL_Ver.1.3_July2012 1006E-0906...
- Page 2 JAI Ltd., Japan and may only be used by the purchasers of the product. JAI Ltd., Japan makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.
- Page 3 CM-040MCL Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera. mark shows that the environment-friendly use period of contained Hazardous Substances is 15 years.
- Page 4 CB-040MCL Supplement The following statement is related to the regulation on “ Measures for the Administration of the control of Pollution by Electronic Information Products “ , known as “ China RoHS “. The table shows contained Hazardous Substances in this camera. mark shows that the environment-friendly use period of contained Hazardous Substances is 15 years.
-
Page 5: Table Of Contents
CM-040MCL /-RA / CB-040MCL /-RA Table of Contents General ....................4 Camera nomenclature ................4 Main Features ..................5 Locations and Functions ................6 Pin Assignment ..................7 12-pin Multi-connector (DC-in/GPIO/Iris Video) ............. 7 Digital Output Connector for Mini Camera Link ............. 7 DIP switch SW600 .................. - Page 6 CM-040MCL /-RA / CB-040MCL /-RA 8.6. Using the Camera Control Tool ................31 External Appearance and Dimensions ............32 Specifications ..................34 10.1 Spectral response ..................34 10.2. Specification table ..................35 Appendix .................... 36 11.1. Precautions ....................36 11.2. Typical Sensor Characteristics ................36 11.3.
-
Page 7: General
Hereafter, CM-040MCL/CB-040MCL will represent a whole series except for specific descriptions. The CM-040MCL and CB-040MCL are JAI C3 Compact series digital cameras utilizing a Mini Camera Link interface. Both standard optical configurations (CM-040MCL/CB-040MCL) and right angle configurations (CM-040MCL-RA/CB-040MCL-RA) are available. The monochrome version CM-040MCL and the color version CB-040MCL provide a frame rate of 61 frames/second at a full resolution of roughly 450,000 pixels. -
Page 8: Main Features
CM-040MCL /-RA / CB-040MCL /-RA 3. Main Features Member of C3 Compact camera series Mini Camera Link interface 776 (h) x 582 (v) 8.3 µm square pixels 1/2 inch progressive scan – monochrome and Bayer mosaic color versions ... -
Page 9: Locations And Functions
CM-040MCL /-RA / CB-040MCL /-RA 4. Locations and Functions ⑤ ④ POWER/ TRIG MINI-CL ② ① ⑥ ③ 1. Lens mount C-mount (Note *1) 2. CCD sensor 1/2 inch CCD sensor 3. 26-pin multi connector Camera Link interface(Miniature type)(Note*2) 4. 12-pin connector DC +12V power and trigger input 5. -
Page 10: Pin Assignment
CM-040MCL /-RA / CB-040MCL /-RA 5. Pin Assignment 5.1 12-pin Multi-connector (DC-in/GPIO/Iris Video) Type: HR10A-10R-12PB (Hirose) male. Pin no. Signal Remarks (Seen from the rear of camera) +12 V DC input Iris Video out Continuous and RCT XEEN output Trigger input (Note*1) + 12 V DC input *1: Default setting is via Camera Link. -
Page 11: Input And Output Circuits
XEEN rear board. As changing the position requires removal output output of the circuit board, it is necessary to consult with JAI sales representatives. Factory default is complementary emitter followers. Output level 4 V from 75. (No termination). EEN is also found in Camera Link. -
Page 12: Video Output Bit Allocation
CM-040MCL /-RA / CB-040MCL /-RA 5.4.5 Video Output Bit allocation Digital Out Analogue Out CCD out (Equivalent) 8bit 10bit Black Setup 3.6%, 25mV 8LSB 32LSB 300mV 100% 700mV 222LSB 890LSB 342mV↑ 114% 255LSB 800mV 1023LSB 1023 White Clip Level 100% Level Black Level Analog Out [mV] Fig.8. -
Page 13: Functions And Operations
CM-040MCL /-RA / CB-040MCL /-RA 6. Functions and Operations 6.1. Basic functions The CM-040MCL and CB-040MCL cameras are progressive scan cameras with 10- or 8-bit video output via a Mini Camera Link interface. The cameras have 2/3, 1/2, 1/4 or 1/8 partial scanning for faster frame rates. -
Page 14: Cb-040Mcl Bayer Mosaic Filter
CM-040MCL /-RA / CB-040MCL /-RA 6.1.2 CB-040MCL Bayer mosaic filter FVAL Timing CB-040MCL is a color camera based on a CCD Line # from FVAL raising edge sensor with a Bayer RGB color mosaic. Actual V Line # The color image reconstruction is done in the host PC. -
Page 15: Electronic Shutter
CM-040MCL /-RA / CB-040MCL /-RA 6.1.4 Electronic Shutter CM-040MCL / CB-040MCL has conventional shutter functions such as preset shutter and programmable shutter. Preset Shutter 9 steps of preset shutter are available: OFF (1/61); 1/100,1/120,1/250,1/500,1/1,000,1/2,000, 1/4,000,1/8,000,1/10,000 sec. Programmable Shutter It is possible to set the shutter speed in the range of 2L to 596L by 1L unit, in the case of full frame operation. -
Page 16: Auto-Detect Lval-Sync / Async Accumulation
CM-040MCL /-RA / CB-040MCL /-RA 6.1.6 Auto-detect LVAL-sync / async accumulation This function replaces the manual setting found in older JAI cameras. Whether accumulation is synchronous or asynchronous in relationship to LVAL depends on the timing of the trigger input. -
Page 17: Sensor Layout And Timing
CM-040MCL /-RA / CB-040MCL /-RA 6.2. Sensor Layout and timing 6.2.1 CCD Sensor Layout The CCD sensor layout with respect to pixels and lines used in the timing and video full frame read out is shown below. Active Pixels Output Video Output 776 (H) x 582 (V) Pixel ( 1,1 ) -
Page 18: Horizontal Timing
CM-040MCL /-RA / CB-040MCL /-RA 6.2.2 Horizontal timing The LVAL period is shown for normal continuous mode. Fig.16 Horizontal timing 6.2.3 Vertical timing The FVAL period for normal continuous mode full scan is shown. Fig.17 Vertical timing for full scan... -
Page 19: Partial Scanning
CM-040MCL /-RA / CB-040MCL /-RA 6.2.4 Partial Scanning The FVAL period is shown for 1/2 partial scan in normal continuous mode. Vertical Timing The diagram and table below provide vertical timing information for the fixed partial scan settings 1/2, 1/4, 1/3 and 2/3. Values for vertical timing in partial scan continuous mode. -
Page 20: Vertical Binning
CM-040MCL /-RA / CB-040MCL /-RA Horizontal Timing The horizontal timing is the same as that of the full scanning. Fig.19 Horizontal Timing for Partial Scanning 6.2.5 Vertical binning Vertical binning combines charges from two adjacent lines, reducing the vertical resolution to half and at the same time increasing frame rate and sensitivity. -
Page 21: Operation Modes
CM-040MCL /-RA / CB-040MCL /-RA Vertical timing V binning FRAME RATE 301 L 111.019 fps LVAL FVAL 579+ 580 581 + 582 1+2 3+4 291 L DAVL Valid data DATA CCD Exposure Fig.21 Vertical Timing for Vertical Binning 6.3. Operation Modes This camera can operate in 4 primary modes. -
Page 22: Edge Pre-Select (Eps) Trigger Mode
CM-040MCL /-RA / CB-040MCL /-RA 6.3.2 Edge Pre-select (EPS) Trigger Mode An external trigger pulse initiates the capture, and the exposure time (accumulation time) is the fixed shutter speed set by registers. The accumulation can be LVAL synchronous or LVAL asynchronous. -
Page 23: Pulse Width Control (Pwc) Trigger Mode
CM-040MCL /-RA / CB-040MCL /-RA LVAL async timing EPS LVAL aSYNC 3.05 μ s± 1μ s Trigger 1L(min) CCD Exposure Exposure FAVL Trigger is input during FVAL LOW period, 3L～4L LVAL a-SYNC mode is automatically set. ( Full : 82.3 us ～ 110 us V Binning : 90 us ～ ... - Page 24 CM-040MCL /-RA / CB-040MCL /-RA LVAL sync timing Fig.24 Pulse width control LVAL sync. LVAL async timing PWC LVAL ASYNC μ s ± 1μ s 3.05 Trigger 1L(min) CCD Exposure Exposure FVAL When the trigger is input during FVAL LOW period, 3L～4L ( Full : 82.3 us ～...
-
Page 25: Reset Continuous (Rct) Trigger Mode
CM-040MCL /-RA / CB-040MCL /-RA 6.3.4 Reset Continuous (RCT) trigger mode The RCT mode operates like EPS (edge preselect) mode with smearless function. An external trigger pulse will immediately stop the video read out, reset and restart the exposure, then operate as normal mode until the next trigger. After the trigger pulse is input, a fast dump read out is performed. -
Page 26: Operation Mode And Functions Matrix
CM-040MCL /-RA / CB-040MCL /-RA Fig.26 RCT mode timing 6.4. Operation Mode and Functions matrix Vertical Shutter LVAL Auto Iris Partial Binning Mode Preset / Sync/ Value output Scanning Program. Async (Note 2) (Note 1) Continuous Edge Pre- select Auto (PS) Pulse Width Auto... -
Page 27: Configuring The Camera
RS-232C control All configuring of the CM-040MCL and CB-040MCL cameras is done via Camera Link. The camera can be set up from a PC running terminal emulator software, or using JAI's camera control software. Below is the description of the ASCII based short command protocol. -
Page 28: Setting Functions
CM-040MCL /-RA / CB-040MCL /-RA Setting functions 7.2.1 Bit allocation. BA=0, BA=1 This command sets the output to 8-bit or 10-bit 7.2.2 Partial scan. SC=0 through 4 The CCD scanning format can be selected between full or partial scanning. With partial scanning only the vertical central part of the CCD sensor is read out with a higher frame rate. -
Page 29: Cm-040Mcl / Cb-040Mcl Command List
CM-040MCL /-RA / CB-040MCL /-RA CM-040MCL / CB-040MCL command list Command Format Parameter Remarks Name A - General settings and utility commands. EB=[Param.]<CR><LF> 0=Echo off Off at power Echo back EB?<CR><LF> 1=Echo on Camera Status ST?<CR><LF> Actual setting Request Online Help HP?<CR><LF>... - Page 30 CM-040MCL /-RA / CB-040MCL /-RA Command Format Parameter Remarks Name D -Image Format BA=[Param.]<CR><LF> Bit Allocation 0=10bit, 1=8bit BA?<CR><LF> 0=Full Frame, 1=2/3 Partial SC=[Param.]<CR><LF> 2=1/2 Partial, 3=1/4 Partial Scan Format SC? <CR><LF> 4=1/8 Partial VB=[Param.]<CR><LF> 0=OFF Only V-Binning VB?<CR><LF> 1=On CM-040MCL E - Gain, Black and signal settings GA=[Param.]<CR><LF>...
-
Page 31: Camera Control Tool For Cm-040Mcl / Cb-040Mcl
CM-040MCL /-RA / CB-040MCL /-RA 8. Camera Control Tool for CM-040MCL / CB-040MCL The Camera Control Tool for Windows 2000/XP/Vista can be downloaded from www.jai.com. The control tool contains a camera control program and a developer's kit for integrating the control tool in your own software. -
Page 32: Communication Window
8.4. Communication Window The Communication Window is used to connect the Camera Control Tool with the JAI camera. Camera Link communication: The CL Manufacturer/COM-ports‟ list box also contains DLL file names (or frame grabber names) for all Camera Link frame grabbers that are installed in the pc. -
Page 33: Camera Control Window
CM-040MCL /-RA / CB-040MCL /-RA Files When clicking the Write to File or Read from File button, the user is prompted for a file using a standard file dialog. New files are created if they do not already exist. Files for camera settings have the extension cam. Information about the communication port is not stored in the files. -
Page 34: Using The Camera Control Tool
3. It is possible to work with the Camera Control Tool when the camera is online and when the camera is offline. 4. The newer JAI cameras always start up with the last used user area (but for some old models it will start up with the last saved user area.) 5. -
Page 35: External Appearance And Dimensions
CM-040MCL /-RA / CB-040MCL /-RA External Appearance and Dimensions 3-M3 depth 3.5 (0.2) (depth0.14) (2.28) (1.73) (2.60) POWER/ TRI G M I NI - CL C-Mount (1.97) (0.51) 6-M3 depth 3.5 (depth0.14) (0.2) Unit:mm ( ) :inch Outsi de si ze tol er ance：± 0. 3m m Fig.27 Outline for CM/CB-040MCL... - Page 36 CM-040MCL /-RA / CB-040MCL /-RA 3-M3 depth 3.5 (depth0.14) (1.02) 6-3M depth 3.5 (depth0.14) C-Mount (1.73) (1.14) (1.02) 4-3M depth 3.5 (1.22) (depth0.14) (1.02) Unit:mm, ( ) inch Outside size tolerance：±0.3mm Fig.28 Outline for CM/CB-040MCL-RA...
-
Page 37: Specifications
CM-040MCL /-RA / CB-040MCL /-RA 10. Specifications 10.1 Spectral response 1000 Wave length (nm) Fig.29 Spectral response for CM-040MCL/040MCL-RA 1 .0 1 .0 IR stop IR stop W ave length (nm) W ave length (nm) Fig.30 Spectral response for CB-040MCL/040MCL-RA... -
Page 38: Specification Table
CM-040MCL /-RA / CB-040MCL /-RA 10.2. Specification table Specifications CM-040MCL/-RA CB-040MCL/-RA Scanning system Progressive scan Frame rate full frame 60.15 frames/sec. Progressive (596 lines/frame) Pixel clock 33.75 MHz Line frequency 36.447 kHz (1H = 27.437 µs) (926 pixel clock/line) CCD sensor 1/2 inch Monochrome ICX415AL 1/2 inch Bayer Color ICX415AQ Sensing area... -
Page 39: Appendix
CM-040MCL /-RA / CB-040MCL /-RA 11. Appendix 11.1. Precautions Personnel not trained in dealing with similar electronic devices should not service this camera. The camera contains components sensitive to electrostatic discharge. The handling of these devices should follow the requirements of electrostatic sensitive components. Do not attempt to disassemble this camera. -
Page 40: Caution When Mounting The Camera
When exporting this product, please follow the export regulation of your own country. 11.6. References 1. This manual for CM-040MCL/040MCL-RA / CB-040MCL/040MCL-RA can be downloaded from www.jai.com 2. Datasheet for CM-040MCL/040MCL-RA / CB-040MCL/040MCL-RA can be downloaded from www.jai.com 3. Camera control software can be downloaded from www.jai.com... - Page 41 CM-040MCL /-RA / CB-040MCL /-RA Index Auto Iris Lens..........12 Lens mount ..........35 Bayer mosaic filter ........11 partial scan ..........16 Blemishes ..........36 Partial scanning .......... 16 Partial Scanning ......... 11 Pixels in video output ........35 Preset Shutter........
-
Page 42: Change History
CM-040MCL /-RA / CB-040MCL /-RA Change History Month/Year Revision Changes June 2009 New release Sept 2009 Change the depth in chassis from 4mm to 3.5mm and add caution May 2011 he description in the chapter 7.2 RS-232C control is corrected since CMCB-040MCL does not have RS-232C interface through 12pin connector. -
Page 43: User's Record
Company and product names mentioned in this manual are trademarks or registered trademarks of their respective owners. JAI A-S cannot be held responsible for any technical or typographical errors and reserves the right to make changes to products and documentation without prior notification.
