Cam Sat CAM-9 Operating Manual

Wireless system for simultaneous transmission of video, audio and control for ptz cameras

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

CAM-9

Wireless system for simultaneous transmission of

video, audio and control for PTZ cameras

IP65

5,8

VIDEO:

GHz

869

DATA:

MHz

Operating manual

Warranty Terms

SMA

9 V DC

ANTENNA

14 V DC

CONNECTOR

PAL

NTSC

300

GFSK

RS-485

-20ºC

+55ºC

BNC

UTP

VIDEO

CHANNELS

Table of Contents

Need help?

Do you have a question about the CAM-9 and is the answer not in the manual?

Questions and answers

Summary of Contents for Cam Sat CAM-9

Page 1 CAM-9 Wireless system for simultaneous transmission of video, audio and control for PTZ cameras 9 V DC -20ºC IP65 ÷ ÷ ANTENNA +55ºC 14 V DC CONNECTOR VIDEO: VIDEO VIDEO VIDEO NTSC CHANNELS GFSK RS-485 DATA: CHANNELS Operating manual Warranty Terms...
Page 2: Declaration Of Conformity
I, the undersigned, representing the following company: CAMSAT Przemysław Gralak ul. Ogrodowa 2a 86-050 Solec Kujawski hereby declare, with full responsibility, that the following device: CAM-9 is approved for operation within the EU and conforms to the fundamental requirements and other relevant provisions of Directive 1999/5/WE:...
Page 3: Table Of Contents
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Removing a transmitter from the CAM-9 Rx receiver memory .
Page 4: Product Features
Product features The CAM-9 kit is an integrated transmission system comprised of a module for video transmission and data transmission to and from industrial cameras in a single compact case . Kit contents The kit includes: ANTENNA SIDE 1 . Video/audio transmitter (Tx) with an IP65 antenna x 1 pcs .
Page 5: Recommendations
.e . the power supply should be connected to the next kit only after the previous kit has been set up precisely . 2 . It is recommended to install CAM-9 receivers at least 7 m away from digital receivers (CDS-5021, CDS-5IP and other) .
Page 6: Technical Data
Technical data DANE AUDIO-WIDEO Frequency 869 MHz 5 .8 GHz Number of operating channels 8/16* Radio link modulation GFSK EIRP radiated power 300 mW 25 mW Receiver sensitivity −118 dBm@1200 bps / ≤ −85 dBm −114 dBm@9600 bps Antenna connectors SMA-RP F 50 Ω...
Page 7 VIDEO CH. DATA CH. LINK T×D R×D ENTER BNC VIDEO CAM-9 WIRELESS VIDEO & TELEMETRY RX-M RX-S MENU BASIC: F1 - baud rate set | F2 - data format set V-Reg ADVANCED: F3 - pairing | F4 - video channel set...
Page 8: Switch Settings
Switch settings Installation 1 . Fasten the transmitter and receiver to a stable pole with the mounts. 2 . Screw the 869 MHz [A] antennas into SMA antenna connectors at the top of the case . 3 . Connect the video cables with the coaxial cable [M], or the UTP twisted pair cable [N] .
Page 9: Basic Settings
Basic settings Operating the dip-switch SWITCH 1 [J] – enables / disables the 120 Ω resistor (terminator) in parallel with the RS-485 interface terminals . This resistor should always be added at the end of every RS-485 line to avoid interference . In order to enable the resistor (RS-485 line terminator), it should be set to the ON position;...
Page 10 Method for setting the transmission rate and data format 1 . In order to get to the settings, enter the device menu by holding the ENTER button [I] for three seconds (until appears on the display) . 2 . You can switch between the menu options ( ) by pressing the ENTER button [I] shortly .
Page 11: Advanced Settings
After a few seconds, the device will return to the main menu . 4 . The procedure from section 3 should be repeated for each CAM-9 Tx transmitter . 5 . In order to end the assigning procedure, turn off the function in the receiver by holding the ENTER button [I] .
Page 12: Setting The Video Operating Channel Remotely
Setting the data transmission parameters remotely In order to set the data transmission parameters (data rate and format) remotely from the CAM-9 M Rx receiver level, follow the instructions in the [Method for setting the transmission rate and data format] section at page 10 .
Page 13: Removing A Transmitter From The Cam-9 Rx Receiver Memory
Removing a transmitter from the CAM-9 Rx receiver memory - If there is a need to turn one of the transmitters off permanently (removal, damage), it should be deleted from the CAM-9 M Rx receiver memory . In order to do this, select the option from the main menu in the receiver .
Page 14: General Warranty Terms
General warranty terms Camsat grants a 24 month warranty for the Cam-9 transmission kit 1 . If the device is not be operating properly, make sure, before returning the device for servicing, that everything was done according to the operating manual .
Page 15: Device Disposal
The warranty does not cover - Mechanical damage of devices and failures occurring due to fortuitous events, such as: fire, power grid overvoltage, electrical discharges, power supply, effects of chemical substances. - Damage occurring due to: improper handling of the device, using the device against its intended use or the operating manual, customer’s negligence, improper use (temperature, humidity, flooding, dust, sanding up, improper power supply voltage) .
Page 16 Manufacturer: CAMSAT Gralak Przemysław Ul . Ogrodowa 2a 86-050 Solec Kujawski Product offer and information: www.camsat.com Service: service@camsat.com...
