Boss Audio Systems 640CA User Manual
Boss Audio Systems 640CA User Manual

Boss Audio Systems 640CA User Manual

In-dash am/fm cd receiver

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 640CA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Boss Audio Systems 640CA

  • Page 2 640CA OWNER’S MANUAL Mobile Audio System PLL Synthesizer Stereo Radio CD/WMA Player Automatic Memory Storing Full Detachable Panel Preset Equalization Electronic Shockproof (ESP) Function Auxiliary Input Function Remote Control...
  • Page 3: Table Of Contents

    CONTENTS Repeating tr acks ....... 11 Installation ........... 3 Take out screw before installation ..3 Playing tracks in random ....11 DIN Front-Mount (Method A)....3 Ejecting a disc ........11 Installing the unit ....... 3 Special function for WMA disc ...11 Removing the unit ......
  • Page 4: Installation

    INSTALLATION Notes: TAKE OUT SCREW BEFORE INSTALLATION Choose the mounting location where Before install the unit, please remove the the unit will not interfere with the normal two screws. driving function of the driver. Take out screw Before finally installing the unit, connect before installation.
  • Page 5: Removing The Unit

    INSTALLATION to fit your vehicle’s mounting area. Then use the supplied hardware (Tapping Screw and Plain Washer) to attach the other end of metal strap to a solid metal part of the vehicle under the dashboard. This strap also helps ensure proper electrical grounding of the unit.
  • Page 6: Din Rear-Mount (Method B)

    INSTALLATION Note: The outer trim ring, sleeve and the 5. Insert both of the supplied keys into the slots at the middle left and right sides of metal strap are not used for method B the unit, then pull the unit out of the installation.
  • Page 7: Using The Detachable Front Panel

    Precautions when handing USING THE DETACHABLE FRONT PANEL Do not drop the front panel. REMOVING THE FRONT PANEL Precautions when handling 1. Press the release button on the front 1. Do not drop the front panel. panel and pull off the front panel. 2.
  • Page 8: Wiring Connection

    WIRING CONNECTION FOR 50X4W SYSTEM...
  • Page 9: Operation

    OPERATION LOCATION OF KEYS release button 13. Liquid crystal display (tune/seek/track up) 14. BND/LOU/ENT button 3. Volume knob (when rotated) (tune/seek/track down) SEL button (when pressed) 16. 4 SHF button 4. Disc slot 17. Auxiliary input jack 5. 1 PAU button 18.
  • Page 10: Basic Operation

    OPERATION BASIC OPERATION SET THE CLOCK Press the DISP button (22) until the clock SWITCHING ON/OFF THE UNIT is shown on the display. Then hold the Press PWR/MUT button (23) to switch on button until the clock flashes. Then press the unit.
  • Page 11: Radio Operation

    OPERATION The reset button is to be activated for the - Program scanning following reasons: Press AS/PS button (10) shortly to scan Initial installation of the unit when all preset station. When the field strength wiring is completed. level is more than the threshold level of All the function buttons do not operate.
  • Page 12: Previewing Tracks

    OPERATION Directory or File Name”=> “Navigation” PREVIEWING TRACKS from root => “Navigation” from current Press SCN button (6) to play first several seconds of each track on the current disc. directory. Press again to stop intro and listen to track. Searching Track Directly When playing WMA disc, press and hold Press AS/PS (Navi-SCH) button (10)
  • Page 13: Disc Notes

    OPERATION 3) DISPLAY INFORMATION Press DISP button (22) to show the following information, such as the clock, ID3 TAG (if available: song title, directory name, artist name, other contents…) (FOR WMA ID3 FUNCTION VERSION ONLY) and other information. DISC NOTES A.
  • Page 14: Remote Control

    REMOTE CONTROL 1. VOL+: Volume Up Button (Character Select (A, B~8,9,0, _,-,+) For WMA Operation) MUTE: Power ON/OFF/MUTE Button 3. SELECT: Sound Mode Select Button (Character Shift Right For WMA Operation) 4. TUNE/SKIP : Tune/Seek Down Button 5. DISP: Display Button 6.
  • Page 15: Specification

    SPECIFICATION GENERAL Power Supply Requirements : DC 12 Volts, Negative Ground Chassis Dimensions : 178 (W) x 160 (D) x 50 (H) Tone Controls Bass (at 100 Hz) : ±10 dB Treble (at 10 kHz) : ±10 dB Maximum Output Power : 50X4 watts Current Drain : 5 Ampere (max.)
  • Page 16: Trouble Shooting

    TROUBLE SHOOTING Before going through the checklist, check wiring connection. If any of the problems persist after checklist has been made, consult your nearest service dealer. Symptom Cause Solution The car ignition switch is If the power supply is No power. not on.
