TABLE OF CONTENTS SECTION 1 GENERAL OVERVIEW ..........................4 Foreword ................................. 4 About This Manual ..............................4 Safety Warnings and Cautions ............................ 4 Design Change Disclaimer............................4 Reproduction Disclaimer ............................4 Technical Support ............................... 4 Important information............................. 4 Manufacture Default Code Setting: ..........................4 LED and Audio Indicator:............................
Page 3
Activation / Expiration Date Setting ......................... 23 Exception Date Setting.............................. 24 IV. Mission Management............................24 Set Parameter Key..............................24 Set Time Key ................................25 Get Information Key ..............................25 Lockout Key................................26 One-Off key/One-Off Code ............................26 One-Off Key ..............................26 One-Off Code..............................
Section 1 General Overview I. Foreword About This Manual This manual is designed for users of Eternity 4 and Eternity 5. All installation, setup, operational information, procedures, screen captures, and other relevant materials are contained in this manual. Safety Warnings and Cautions When handling a printed circuit board (PCB), guard against possible static discharges by touching a grounded object BEFORE touching the board.
III. General Lock Spec This page shows the similar specifications of the Eternity 4 and Eternity 5. Keypad: 12 all weather numeric keypad Keypad Functions: Permanent codes, Temporary codes, one-time service codes Power Supply: 4 standard AA batteries with a weatherized battery pack for all weather conditions Power Supply Life Expectancy: 10,000 operations, low battery warning when system drops below 4.8 volts...
IV. Eternity IV Datasheet (Heavy Duty keypad Lock) Hardware Spec PARAMETER DETAIL Lock Weight 6 Lb Working Current <10 mA Idle Current 5 µA 5 (1 – 25) Seconds Lock Back Time Working Voltage 4.8-6.4V Low Battery Warning 4.8V or lower 4 AA Alkaline Batteries Power Source Keypad...
Eternity IV Installation Instruction Step 1. Install the latch Step 4. Install inside lock housing • • Insert the latch into 1″ hole on edge of the Plug the power cable into the door. inside lock housing. • • Secure the latch in place with two screws. Place inside lock housing on top of the mounting plate, •...
V. Eternity V Datasheet (Medium Duty keypad Lock) Hardware Spec PARAMETER DETAIL Weight (Lock only) 4.2 Lbs Working Current 250 mA 15 µA Idle Current Motor Running Time 0.4 Second Working Voltage 4.2-6.4V Low Battery Warning 4.2V 4 AA Alkaline Battery Power Source Keypad Weather Proof Keypad...
Eternity-V-Installation Step 2 Step 1 Insert the square shaft (A) into the center hub (B) (Fig 1). Insert the position Insert the latch into door pin into the hole on the center hub to secure the square shaft. Bend the end hole.
Page 12
Step 5 Step 6 Attach the battery plate onto the door, with the Install batteries, and plug in the power rubber gasket between the door and battery cable. Secure the back lock housing onto plate. Make sure the power plug go through the the battery plate.
Eternity-V-Mortise-Installation Step 1 Step 2 Insert the lock case into mortise Insert the square shaft (A) into the center hub (B). (Fig 1) pocket. Secure the lock case with Insert the position pin into the hole on the center hub to two screws.
Page 14
Step 5 Step 6 Attach the battery plate onto the door, with the rubber Install batteries, and plug in the power gasket between the door and battery plate. Make sure the cable. Secure the back lock housing onto power plug go through the hole on the plate. Secure the the battery plate.
Page 15
Major Lock Parts 1. Rear Handle Back View 2. Rear Lock housing Screws Installation 3. Rear Housing 4. Battery Plate Screw 5. Battery Plate 6. Rear Rubber Gasket 7. Door 8. Lock case (Mortise) 9. Latch Screws 10. Dust Boot 11.
Section 2 Eternity Software Guide 1. Software Setup The Eternity Software works the same for both Eternity 4 and Eternity 5. Operating System Eternity software is compatible with Microsoft Windows 98/2000/XP/Vista. All software must be installed using Windows administrator account, but all level Windows users can use the program. Failure to install the applications may result in error messages and an incomplete installation.
License Name: Input the name of your company User Name: dallas Password: ibutton Default User Name and Password can be modified but can’t be deleted. Change System Password The default system password is 000000(6 Zeros). It is mandatory to change and remember the facility system password when the user is ready to use this software.
Steps to set up a new lock mission Snap the program key (DS1977) onto the USB blue dot receptor, login to the software and click on the New Lock Setup icon, and click issue key. Click ok to clear the pop up warning message box. Now take the program key to the lock, hold the reset button on the lock until there are two beeps and a solid green light;...
II. User Setup Onsite User Setting Add/Edit user information To add/edit iButton / key code user, click “Add” button in the key setting menu, and following screen will pop up: To add iButton user, click ok and snap a user iButton key into the encoder. Click on the empty field of “Serial ID”, the iButton key ID will be detected by the system and automatically entered.
Assign Onsite user to lock Single-lock key Assignment Mission: This mission is to assign iButton keys and user codes to one lock. o Select lock from lock list o Change the time shift if needed o Click to change the ‘Selected’ Column for the assigned users to the lock o Snap in programming key o Click “Issue Key”...
Remote User Code Setting Create remote Access Code Click on the “Remote Code” icon, the following screen will show: Click on Lock Name field, the list of existing locks window will pop up, selects the lock from the list. Fill in the Guest First, and last name. Select the starting date and ending date you want the temporary codes to have access to the lock.
One Time Service code Up to 16 one-time service codes can be generated during the same time window. Note: the access codes and service codes are accurate to the hour. Setting an ending time of 3:30 will prevent the code from working any time after 3:00 on that date.
• Storehouse Mode: In this mode, the Lock will lock back in a few seconds (0.1-25.5 seconds). • Classroom Mode: In this mode, the lock does not lock back. The use of a valid iButton or code simply makes the lock go from unlocked to locked or locked to unlocked.
Exception Date Setting This function is used to set restrict access during periods such as holidays, facility shutdowns, vacations. The first group set as No Limit default setting. The holidays can be set as a single day or multiple days. The selected user iButton keys or codes will be restricted from access for all of the exception dates.
Set Time Key This step uses the DS1904 or DS1994 to set the real time of the lock Tip: Other than DS1904/1994 real time key, the DS1977 program key can also set the time of the lock. But program key will cause time delay since programming the mission key and programming the lock will take time.
Lockout Key Lockout forbids all assigned keys/codes from operating the lock. Apply any Lockout key to put the lock in Lockout Mode, and apply again to release the Lockout Mode. To apply the key, snap the program key into the encoder, select open door or close door, press the “Issue Key”...
V. Audit Trial Click “Mission Management” on the main screen toolbars and select “Advanced Mission” from the drop down menu, select “Get Audit Trial”: Snap the program key to the encoder and click on “Issue Key” button. A “Write Get Audit Trail key OK” message will pop up. Click OK to close the screen. Unplug the program key and touch the lock’s iButton reader, you will hear a long series of chirps followed by two beeps.
VI. History Lock Audit History Click “History” and choose “Lock Audit History” from drop down menu, the following screen will pop up: Here’s how to view the saved data: 1. On “Query By” give the time window of the audit records, and check the key words. 2.
Section 3 Non-software Guide This section is for the use of either the Eternity 4 or Eternity 5 without software. If you use the software to setup the lock, then you can no longer use these functions without resetting the lock. Likewise, if you use the programming code to manually setup the lock, you can not use the software with the lock unless you reset and do a new lock setup mission.
Reset: To set the lock back to default (123456), press and hold the reset button for about 10 seconds (3 beeps with LED blink red). The reset button is located below the battery holder. The reset button for the Eternity 4 is shown below. Eternity 4Reset Button The reset button for the Eternity 5 is shown below.
• One time service code: One time code, # • Manual key: Turn the override key 90 degree clockwise, then turn the handle V. Terms: Program code: The program code puts the lock into a programming mode. It will not lock/unlock the lock. When #, program code, # is entered, the red LED starts to flash indicating the lock is in a programming mode.
Page 32
How to add one user access code (with time restriction) Function Code: 01# {#Master code#}+{01#}+{user code#}+{yymmddhhmm#(start time)}+{yymmddhhmm#(ending time)} How to add multi-user code (with time restriction) Function Code: 01# {#Master code#}+{01#}+{user code#(1)}+{yymmddhhmm#(start)}+{yymmddhhmm#(ending time)} + {user code#(2)}+{yymmddhhmm#(start)}+{yymmddhhmm#(ending)} …and so on How to add one iButton key (no time restriction) Function Code: 01# {#Master code#}+{01#}+{touch iButton # #} How to add multi-user iButton key (no time restriction)
How to delete user code or iButton key with index # Function Code: 44# {#Master code#}+{44#}+{index#} How to delete one user code / iButton key (without index number) Function Code: 46# {#Master code#}+{46#}+{user code#} (or iButton key) How to de-active user code / iButton key (without index number) Function Code: 48# {#Master code#}+{48#}+{user code} (or iButton key) How to In-active user code or iButton key without index number...
#23456# 2222# 135# 0830 1730# Master code Function code User code Mon/Wed/Fri Beginning time 4. Ending time 0800=8:00AM 1730=5:30PM Section 4 Case Study University Park Business Center, Denton, TX Problem: The Luxury Home Builders is one of the largest custom home / office builders in north Texas. One of the examples is the University Park Business Center.
Step 1: Time Setting, set Time Shift 3 from Monday to Friday, 6:30PM to 10:00PM, Saturday from 1:00PM to 10:00PM, and Sunday from 8:00AM to 9:00PM. Here is the timetable for the keys: Begin Time End Time Day of Week 6:30:00PM 10:00:00PM Monday...
Warranty Registration Form Customer Information: Date Purchased: Purchase From (company name): Model: Serial Number: First Name: Last Name: Daytime Phone: E-mail: Shipping Address: City: State: Zip Code: --------------------------------- -------------------------------- --------------------------- Mail Registration Form to: Attn: Registration Dept PO Box 250128 Plano, TX 75025 ____________ Warranty and RMA Guidelines...
