Page 1
G 2 G O M 2 0 0 0 u s e r g u i d e User Guide...
Page 2
G2G0 M2000 User Guide This manual is based on the production version of the Kyocera M2000 phone. Software changes may have occurred after this printing. Kyocera reserves the right to make changes in technical and product specifications without prior notice. The products and equipment described in this documentation are manufactured under license from QUALCOMM Incorporated under one or more of the following U.S.
thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are conducted using standard operating positions specified by the FCC with the phone transmitting at its highest...
Hearing aids—Some digital wireless phones may interfere with hearing aids. In the event of such interference, you may want to consult your service provider or call the customer service line to discuss alternatives. Other medical devices—If you use any other personal medical device, consult the manufacturer of the device to determine if it is adequately shielded from external RF energy.
Page 5
Radio Frequency (RF) energy Your telephone is a radio transmitter and receiver. When it is on, it receives and sends out RF energy. Your service provider’s network controls the power of the RF signal. This power level can range from 0.006 to 0.6 watts. In August 1996, the U.S.
Get Started Phone Battery Install the Battery 1. With the back of the phone facing you, press on the back cover and slide it to the bottom of the phone. 2. Lift the back cover from the bottom to remove. 3.
Page 10
Battery Safety Guidelines • Do not disassemble or open the battery. • Do not crush, bend, deform, puncture, or shred the battery. • Do not attempt to insert foreign objects into the battery. • Do not immerse the battery or expose it to water or other liquids.
Memory Card Install the Memory Card To install the memory card: 1. With the front of the phone facing you, locate the rubber memory card cover on the lower right hand side. 2. Remove the cover. 3. Insert the memory card with the metal contacts facing toward the front of the phone until it is securely in place.
Phone Overview Get to Know Your Phone The following shows the front of the phone with the slide closed. 1. LED indicator. 2. Rewind, Play/Pause, and Fast Forward keys for the Music Player. Press the Play/Pause twice to activate the Music Player.
Page 13
The following shows the phone’s QWERTY keypad with the slide open. 1. Right softkey selects items that appear on the lower right of the display. 2. Enter key generates a carriage return in text entry. 3. Back key erases characters in text entry or returns you to the previous screen when navigating through menus.
LED Indicator Your phone’s LED indicator displays different colors depending on the alert. Incoming call Low battery New message Missed call In call Battery charging Fully charged battery Alarm or scheduler alert Bluetooth Green—blinks (not for call waiting calls). Red—blinks until you charge the phone. Red—blinks for the first minute or until you respond to the alert, whichever happens first.
Screen Icons These icons may appear on your phone’s screen. The phone is operating in IS2000 (1X) digital mode. The phone is in airplane mode. The alarm clock is set. The phone is set to auto answer. The battery is fully charged. The more black bars, the greater the charge.
Main Menu Press the OK key or select Menu when the phone is in idle state to access the main menu. Idle State > Level 1 > Menu BREW Contacts Recent Calls Media Gallery Messaging Tools & Games Browser Music Player Settings Camera Note: The menu items on your phone can change depending on the services provided by your service provider.
Guide Conventions In this guide, the following conventions are used when describing phone features. Select means to press the Left softkey, Right softkey or OK key to select an item seen on the display. For example, “Select Menu” tells you to physically press the left softkey to choose Menu from the display.
Call Features This section describes the basic features related to calls. Power Phone Up • To turn your phone on, press the End key and wait until the phone display lights up. • To turn your phone off, press and hold the End key until the phone plays a short musical sound and turns off.
End Phone Calls Press the End key. Activate Voice Dialing 1. Press and hold the Send key. 2. Follow the prompts. For more information, see “Voice Commands” on page 82. Volume Control Adjust Volume during a Call Press the Volume key up or down to adjust the earpiece volume during a call.
Emergency Services Call Emergency Service You can call an emergency code even if your phone is locked or your account is restricted. When you call, your phone enters emergency mode. This enables the emergency service exclusive access to your phone to call you back, if necessary.
Text Entry You can enter letters, numbers, and symbols in contacts, text messages, and your banner. Text Entry Modes The text entry screen has the following features: 1. Characters remaining that you can type. Allowed length of messages can vary depending on your service.
Page 22
Rapid Entry with QWERTY Keypad When you press a series of keys using Rapid entry, your phone checks its dictionary and guesses at the word you are trying to spell. From a text entry field, select Options > Rapid Entry to speed up word completion. To enter words, press a key once.
Text Entry Quick Reference This table gives instructions for entering letters, numbers, and symbols. To.. Enter a letter Enter a number Enter a symbol Enter a space Erase a character Erase all characters Move the cursor right or left Move the cursor up or down Change input mode Change case mode Capitalize any letter...
BREW How does BREW Work? Your Kyocera phone has the added ability to download and manage applications through BREW. BREW brings you the full range of applications and services you have come to expect from the Internet: Email and instant messaging, real-time navigation services, group chat, games, relevant news, and much more.
Contacts Use Contacts to store information about a person or company. Contacts Menu Select Contacts from the main menu to access the following functions: Level 1 > Level 2 > Contacts View All Add New Groups Speed Dial List Voice Dial List Erase Contacts Contacts Count Access Contacts...
Use Fast Find With Fast Find enabled, you can press one or two keys to view close matches of the contact. See “Call Contact using Fast Find” on page 72. Add Contacts Add Contacts from Home Screen 1. From the home screen, enter a phone number to save (include the area code).
Send a Multimedia Message to Contacts 1. From View All, select a contact. 2. At the contact details screen, select a number or email address. 3. Select Send Pic Msg. 4. Complete your multimedia message and select Send. Send a Contact vCard 1.
Add a Prefix to Phone Numbers Use Prepend to add a prefix, such as an area code, to a phone number: 1. From View All, select a contact. 2. At the contact details screen, select a number. 3. Select Prepend to enter the prefix at the beginning of the number.
Erase All Contacts From Erase Contacts, select Contacts Only > Yes > Yes to erase all your contacts. Note: You cannot recover deleted information. Erase All Contacts and Groups From Erase Contacts, select Erase All > Yes > Yes to erase all your contacts and groups. Note: You cannot recover deleted information.
Page 30
Assign Message Tones to Groups 1. From Groups, select a group. 2. At the group details screen, scroll to the group name. 3. Select Options > Msg Tone > Assign Msg Tone and a ringer from the list. (Scroll to play the ringers.) Assign Pictures to Groups 1.
Speed Dial List Assign Speed Dial Numbers 1. From Speed Dial List, highlight an unassigned number (marked as empty). 2. Select Assign. 3. At the contacts list, select a contact. 4. At the contact details screen, select a phone number. Clear Speed Dial Numbers 1.
Recent Calls Recent Calls Menu Select Recent Calls from the main menu to access the following functions: Level 1 > Level 2 > Recent Calls Incoming Outgoing Missed Erase Call List Call Timers Kilobyte Counter Work with Call Lists Return Any Call 1.
Deal with a Missed Call When you have missed a call, “Missed Call” appears on your screen. You can do one of the following: • To clear the screen, select OK. • To view the call details, select Calls and press the OK key.
View Home Calls Timer Select Home Calls to view the number of calls and the total call time. Select Done when finished. This timer tracks all calls made and received in your home network since you last reset the timer. To reset this timer to zero, select Reset > Yes.
Media Gallery Use Media Gallery to retrieve and playback media files and other downloads. Media Gallery Menu Select Media Gallery from the main menu to access the following functions: Level 1 > Level 2 > Media Gallery Images Sounds Delete All Images Send a Picture 1.
Change the Default Wallpaper 1. From Wallpapers, select a wallpaper. 2. Select Set Default. Edit the Wallpaper Shuffle 1. From Wallpaper Shuffle, select Edit. With no wallpapers saved, you need to add files. 2. Select Add to include a file in the shuffle, Remove to remove a file from the shuffle, or Options to access more features.
Play a Song 1. From My Music, select All Songs. 2. Choose a song and select Play. Use the Navigation key to control the playback tools displayed. Access a Playlist 1. From My Music, select Playlists. 2. Choose a playlist and select Play. Use the Navigation key to control the playback tools displayed.
Page 38
Play a File 1. From a media file list, highlight a file. 2. Select Options > Play. Use the Navigation key to control the playback tools displayed. Copy a File to a Memory Card 1. From a media file list, highlight a file. 2.
Erase Media Files Erase a Single File 1. From a media file list, highlight a file. 2. Select Options > Erase > Yes. You can only erase unlocked files. Preloaded files on your phone are always locked. Erase All Files in a Folder From a media file list, select Options >...
Messaging Use Messaging to send, receive, and erase messages from your phone. Messaging Menu Select Messaging from the main menu to access the following functions: Level 1 > Level 2 > Messaging New Text Msg New Pic Msg Voicemail Inbox Browser Alerts Sent Msgs Outbox...
Send Messages Create a Text Message You can only send text messages to phone numbers capable of receiving them or to email addresses if supported. 1. From New Text Msg, enter a recipient’s phone number or email address. (Select Options to access contacts, groups or recently used addresses.
Page 42
Add Recipients from Recent List 1. At the compose message screen, select Options > Recent List when entering a phone number or email address. 2. Select a number or address. 3. Complete your message. Add Recipients from Recent Calls 1. At the compose message screen, select Options >...
Page 43
Save Messages as Preset Text 1. At the compose message screen, select Options > Save as QuickText when entering the text to use it later as preset text. 2. Complete your message. Save Received Messages as Preset Text When viewing a received message, select Options >...
Page 44
Add Media Files to Messages 1. At the compose message screen, select Options > Media Gallery when adding a media file. 2. Select a file to add to your message. To remove a media file, select the applicable option. For example, to remove a sound, select Options >...
Page 45
Change the Callback Number 1. When entering the message, select Options > Msg Settings > Callback Number. 2. Enter your callback number and select OK. 3. Complete your message. Send Messages Later 1. When entering a message, select Options > Msg Settings >...
Handle Received Messages Reply to Text Messages When receiving a message, your phone displays a notification and the message icon appears at the top of your screen. The message icon flashes with an urgent message alert if the message is urgent.
Page 47
Reply with a Copy of the Message 1. When viewing a received message, select Options > Reply with Copy. The original message appears in your reply message. 2. Complete your message and select Send. Call Sender When viewing a received message, select Options >...
View Message Information When viewing a received message, select Options > Message Info to view the message priority, sent time, size, and so on. Replay Messages When viewing a received message, select Options > Replay to restart the message (including a slide or sound if contained) from the beginning.
Check Message Status in Outbox Use the following symbols to check your Outbox for the status of messages sent but still in process. The message is pending and will be sent when possible. You can cancel delivery of the message. The message cannot be sent because service is not available.
Page 50
Set Message List View From Msg List View, select one of the following to set your message list display: • Sender & Preview displays the sender and first part of messages. • Sender & Date-Time displays the sender and sent time of messages. •...
Page 51
Enable Auto-Erase Use Auto-Erase to set your phone to erase messages automatically when it needs memory for incoming messages. From Auto-Erase, select one of the following: • Disabled erases no messages. • Inbox Msgs erases old messages in Inbox when memory is needed. •...
Message Groups You can create groups for messaging. View Message Groups List 1. From Message Groups, view your preloaded groups, followed by the custom groups you have created. 2. Highlight a group and do one of the following: – Press the OK key to view the groups details.
Erase Messages Erasing old messages frees up memory in your phone. You can erase messages as you send or read them, erase them one at a time, or erase them all at once. Erase a Single Message When viewing a received message, select Options >...
Tools & Games Tools & Games Menu Select Tools & Games from the main menu to access the following functions: Level 1 > Level 2 > Tools & Games Brick Attack Voice Memo Scheduler Alarm Clock Tip Calculator Calculator Timer Stopwatch Memopad World Clock...
Record Voice Memos 1. From Voice Memo, select Record New. 2. Record your voice memo and select Stop when done. 3. Select Save. If you receive an incoming call while recording a memo, the memo is saved and the incoming call screen appears.
Page 56
3. Do one of the following: – Scroll left or right to move to another date. – Select an event. – Scroll to a time and select Add New to create a new event. – Select Options to access more features. View Events by Date From View Day, do one of the following: •...
Page 57
Erase Events Erase an Event 1. From View Day, select an event. 2. At the event details screen, select Options > Erase > Yes. Erase the Current Day’s Events From View Day, select Options > Erase Today’s Events > Yes to erase all events on that day.
Alarm Clock You can set up to four alerts with your phone’s three alarm clocks and one quick alarm. Note: The alert occurs only if the phone is on. Set an Alarm 1. From Alarm Clock, scroll to one of the alarms and select Set.
Use Calculator 1. From Calculator, enter the first number. 2. Select a mathematical operation: – Scroll left to multiply. – Scroll right to divide. – Scroll up to add. – Scroll down to subtract. Your selection will appear highlighted. 3. Enter the second number, and press the OK key to view the result.
Memopad Write a Memo 1. From New Memo, enter the memo. 2. Select Save. View a Memo From View Memos, select View to open a memo or Options to access more features. Edit a Memo 1. From View Memos, highlight a memo. 2.
10 Browser You can use your phone to browse the Internet if you have obtained phone Internet services from your service provider and if over-the-air Internet access is available in your area. Launch Browser Select Browser to launch the browser. An alert appears notifying of airtime fees, if you have enabled web alerts.
11 Music Player Use Music Player to play and manage media files. Play a Song 1. From the home screen, select Menu > Music Player. 2. At the song list, scroll to a song. 3. Select Play to play the song or Options to access more functions.
View Song Details To view the details of the song your are currently playing, select Options > Details. Work with Songs 1. From Music Player, select Options > Music Library. 2. Select All Songs or other song list. 3. Scroll to a song and select Options to access functions such as locking or assigning the file.
Page 64
Set Auto Off Duration Use Auto off to set the duration for which your phone is paused or stopped before automatically turning off Music Player. From Auto off, select one of the following: • 10 Minutes automatically turns off Music Player after the phone pauses or stops for 10 minutes.
12 Settings Settings Menu Select Settings from the main menu to access the following functions: Level 1 > Level 2 > Settings Bluetooth Sounds Display Convenience Voice Features Accessories USB Mode Network Security Phone Info User Guide Level 3 Access these options: On/Off, My Devices, and Settings. Access these options: Ringers, Ringer Mode, Volume, Slide Sounds, Pwr On/Off Sound, and Keypad.
Bluetooth The Bluetooth® wireless technology (not available on all phones) enables wireless connectivity with accessories such as portable or installed hands-free car kits, headsets, handsets, computers, and so on. For details, check with your service provider. You must use a Bluetooth device (compatible with Class 2 Bluetooth wireless technology, version 1.2) in order to use this phone wirelessly.
View Device Services A Bluetooth device paired with your phone may have more than one service profile (such as Headset, Handsfree, and so on). Do the following to check the services available: 1. From My Devices, highlight a device. 2. Select Options > Services. 3.
Page 68
– View Ringer Shuffle 1. From Ringer Shuffle, select View. Only the files used in your shuffle appear. 2. Select Edit to modify the shuffle list or press the Back key to exit. Set Ringer Mode Your phone is set to make sounds when you receive calls, press keys, navigate through menus, and receive alerts (such as new messages).
Set Power On/Off Sounds 1. From Pwr On/Off Sound, select Power On Sound or Power Off Sound. 2. Select a sound to play when your phone powers on or off. (Scroll down the list to play the sounds.) Keypad From Keypad, you can modify the following settings.
Set Screensaver Screensavers appear on the home screen, activated ten seconds after the last keypress. Incoming calls and alerts override the screensavers. 1. From Set Screensaver, select Camera Pictures, Saved Images, or Screensavers. To turn off screensaver, select None. 2. Select a file. You may need to resize or crop the file.
Set Time and Date Format From Time/Date Format, select a time and date format. Convenience Use these settings to make your phone more convenient to use. Set Date and Time In Airplane mode, you can set the time and date manually.
Page 72
Use 1-Touch Dialing The 1-Touch Dialing feature is the fastest way to call a speed dial location. To call a contact with speed dial, press and hold the speed dialing location. If it is a two-digit location, press the first digit briefly, then press and hold the second digit.
Enable Frequent List From Frequent List, select Enabled. With Frequent List enabled, the last 15 of your most frequently called contacts appear at the beginning of your contacts list. Scroll past the double line to view the entire contacts list. Enable Minute Alert From Minute Alert, select Enabled.
Set Display Results You can set the phone to display up to three voice recognition contacts when calling or searching for a contact with voice commands. From Display Results, select Single Best or Three Best. Set Digit Lengths You can set the number of digits used for a phone number in your voice dial list.
Memory Card Choose Files to Save 1. From Memory Card, select Items to Save to choose what files you save to your memory. 2. Select file types from the list provided. A checkmark appears next to each file type that is saved to the memory card. Press the OK key to add or remove checkmarks.
Page 76
Enable Roaming Service Alert Use this setting if you want the phone to alert you when you roam outside of your home service area. From Roam/Svc Alert, select one of the following: • Disabled turns roaming service alert off. • When no svc alerts you with three tones decreasing in pitch when service is lost and three tones increasing in pitch when service is acquired again.
Enable Roaming Call Alert You can set the phone to warn you before you answer or place a call while roaming. Note: Call prompt is disabled when the phone is in Emergency Mode. From Roam Call Alert, select Enabled. The phone emits a distinctive ring to indicate when you are roaming during a call.
Phone Info View Version Information Select Build Info to check your phone’s software and hardware information. View Phone Icons Select Icon Key to view the icons used in your phone. Access User Guide From User Guide, access the user guide for your phone.
13 Camera Camera Tips Your phone comes with a camera. Before using your phone’s camera, here are some tips: • You cannot activate the camera while on an active call or while browsing files in the media gallery. • Once the camera is active, the home screen acts as the viewfinder.
Page 80
Enable Date/Time Stamp From camera mode, select Options > Settings > Date/Time > On to place a date/time stamp each picture taken. icon indicates when the date/time stamp is on. Enable Multishot Mode From camera mode, select Options > Settings >...
Other Camera Options Set Brightness Level 1. From camera mode, select Options > Brightness. 2. Scroll left or right to change the brightness level. Press the OK key to set the brightness. Go to Camera Pictures From camera mode, select Options > Camera Pictures to see all of the pictures you have taken.
14 Voice Commands You can do certain commands through voice recognition. To control the settings associated with voice commands, see “Voice Features” on page 73. Call a Contact 1. From the home screen, press and hold the Send key. The phone prompts, “Say a command”.
Play a Playlist 1. From the home screen, press and hold the Send key. The phone prompts, “Say a command”. 2. Say “Play” and then a playlist name. If you pause, the phone prompts you to say a playlist name. 3.
15 Get Help User Guide From Phone Info, select User Guide to access the user guide. You can also find the user guide at www.kyocera-wireless.com/support. Customer Support Your service provider’s customer support department may be accessible directly from your phone when you dial a number, such as *611 (check with your service provider).
