Summary of Contents for Eyeris Digital video recorder
- Page 2 Digital Video Recorder Welcome Thank you for purchasing our DVR! This operating manual is designed to be a reference tool for the installation and operation of your system. Disclaimer: We. reserves the right without notice to change, add, modify or remove any information and materials on this manual in any manner and at any time.
- Page 3 Digital Video Recorder Features Embedded Linux OS; Support 8 Ch. 720P/ 4 Ch. 1080P HD IPC； Support 16 Ch. Video Loop-out, Support HDMI, VGA, CVBS, SPOT output, support 4/8/16 Ch. Audio input. 16 Ch. synchronous playback ...
- Page 4 Digital Video Recorder Backup from USB interface (USB Disk, USD HDD, USB CD/DVD Burner. etc) Easy backup method: network download to remote client Non-working HDD hibernation, reduce the working temperature and power consumption Looping record Special video file format, prevent malice tampering and overwritten Network ...
- Page 5 Digital Video Recorder System log enquiry Audio Two-way audio (Support BNC interface and 3.`5mm interface)； 1 / 4 / 8 /16channels audio input, 1 channel audio output Synchronized video & audio input Remote intercom while live review ...
-
Page 6: Table Of Contents
Digital Video Recorder Contents CONTENTS ..............................- 6 - INTRODUCTION ............................5 1.1 P .............................. 5 URPOSE 1.2 S ..............................5 COPE 1.3 R ............................5 EFERENCE INSTRUCTIONS ............................5 2.1H ........................5 ARDWARE NVIRONMENT 2.2S ........................6 OFTEWARE NVIRONMENT 2.3N... - Page 7 Digital Video Recorder 3.7.8 Tour ..............................44 3.8 A ............................44 DANCED 3.8.1 HDD Management ........................44 3.8.2 Digital Channel .......................... 45 3.8.3 USB Update ..........................46 3.8.4 Configuration ..........................47 3.8.5 Maintenance ..........................48 3.8.6 Default ............................49 3.8.7 Exit ..............................50 3.9 S...
-
Page 8: Introduction
1 Introduction 1.1 Purpose This user manual is provided mainly for the project managers, sales personnel, end users, engineering installers and other related personnel, facilitating the installation and maintenance and improving the work efficiency. 1.2 Scope Usage of the user manual: project managers, project installers, maintenance personel and end users, etc. -
Page 9: Softeware Environment
Digital Video Recorder Ventilation: install the DVR in an airy place, keep away from dusty Installation: horizon installation or cabinet installation, protective casing needed when outdoor installation 2.2Softeware Environment OS: embedded Linux system Device firmware: Universal version... -
Page 10: Back Panel Of Dvr
Digital Video Recorder 2.4.2 Back panel of DVR 2.5Mouse For right-hand mouse The DVR could be operated by mouse, connect the USB mouse into the USB port in front panel System pops up password input dialogue box if you have not logged in. -
Page 11: Remote Controller
Digital Video Recorder In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized). Here ← stands for backspace button. ＿ stands for space button. In English input mode: _stands for input a backspace icon and ← stands for deleting the previous character. - Page 12 Digital Video Recorder Name Icon Function Switch between one-window and multiple-window display Window switch modes. Enter DVR No. setting *999 for Administrator Main Menu->Setting->General: *DVR No. setting: DVR number Input password, switch channel and input numeral. Numeral keys 0-9 In PTZ function: enable PTZ...
-
Page 13: System Introduction
Digital Video Recorder 3 System Introduction 3.1 System Menu Tree Schedule Motion Detection Record Search Camera Masking Backup Video Lost Alarm General Alarm Input Encode Alarm Output Network Abnormality 单 Setting Display Account RS232 HDD Manage Tour Online Users TV Adjust... -
Page 14: Main Menu
Digital Video Recorder 3.2 Main Menu Recording and Alarm Main Menu Function Sub Menu Time setting for record, motion detection, external Schedule alarm. Time operated setting per day per week (Period time for record, receive external alarm signal, motion detection) - Page 15 Digital Video Recorder Digital Alarm Include channel, enable/off, alarm input type, arming time, output time delay, alarm linkage, PTZ linkage, pre-recording, patrol setting etc., copy & paste for same settings General Setting system time, time format, language, recording in HDD, series number, video system, video output format, , etc.
- Page 16 Digital Video Recorder Managemnt Tools HDD Manage HDD management, delete data and etc. Note: System will restart after setting HDD Online Users Online user management TV Adjust Adjust picture’s up, down, left, right deflate. USB Update File system, U-BOOT ， Kernel,...
-
Page 17: Shortcut Menu
Digital Video Recorder Display important event log and designate needed log. Version Display system hardware, software version and release date, etc. 3.3 Shortcut Menu Record Record video inquiry and playback Playback Record Set record status: schedule/manual/stop Control Record Record backup operation and setting... -
Page 18: Record
Digital Video Recorder means not selected. Enter main menu method: 1, press ENTER button on the panel to enter main menu directly 2, press Esc button on the panel, select MAIN MENU. 3.5 Record Note: User should have “Record” authority, HDD should be installed and format... -
Page 19: Schedule
Digital Video Recorder 3.5.1 Schedule When the system boots up, it is in default 24-hour regular mode. You can set record type and time in schedule interface. Setting at Main menu> Video function> video setting. Including schedule setting regarding Regular（R）, motion detection video (M), Alarm Manual (H) Channel: Please select the channel number first. -
Page 20: Playback
Digital Video Recorder Redundancy button to activate this function. Please note, before enable this function, please set at least one HDD as redundant. (Main menu->Advanced->HDD Management) Pack Duration: Choose the time slice of video file Pre-record: record the video previously than motion detection ●... - Page 21 Digital Video Recorder Video inquiry demonstration on-screen display enter video Select video function from main menu to enter menu page playback menu Notet: The password may needed when user logout. According to video type: all, alarm, motion detection, all alarm video, channel, time etc., you can inquire video file based on...
-
Page 22: 3Backup
Digital Video Recorder Fast forward and Slow playback Button Illustration In playback mode, click this button to switch between various fast play modes such as fast play 1,fast play 2 and more.(Fast play 1 means fast play Fast play level 1 or not about speed) -
Page 23: Alarm
Digital Video Recorder Detect: Detect the USB portable device connected with DVR, and display the device name, Free space / Total space status USB Backup: list and backup the selected file, to the USB Devices, could be sorted by Record type, channel, time... -
Page 24: Motion Detection
Digital Video Recorder 3.6.1 Motion Detection By analyzing video, when system detects sensitive moving signal, it will start motion detection alarm. Operation method: Channel: select the channel you want to implement motion detection. Enable: function enable switch Sensitivity: System supports 6 levels. The sixth level has the highest sensitivity. - Page 25 Digital Video Recorder Alarm output: when alarm occurred, system enables peripheral alarm devices Tigger Delay: System auto delays detecting for a specified time. The value ranges from 10-600 (Unit: second) Latch: when motion detection complete, system auto delays detecting for a specified time.
-
Page 26: Privacy Mask
Digital Video Recorder Tour: Here you can enable tour function when alarm occurs. It is a one-window tour. Latch: when motion detection, system auto delays recording for a specified time. The value ranges from 10-300 (Unit: second) Buzzer: Default is “off”... - Page 27 Digital Video Recorder Enable: function enable switch Sensitivity: there are six levels. The six-level has the highest sensitivity. Period: Click set button, you can see an interface is shown as below. Here you can set for business day and non-business day. You can set up six time period, but they can’t be repeated.
-
Page 28: Video Lost
Digital Video Recorder tour. Recording Latch: when motion detection complete, system auto delays recording for a specified time. The value ranges from 10-300 (Unit: second) Buzzer: Default is “Off” 3.6.3 Video Lost When video loss happens, you can select ALARM OUTPUT or video loss show information in local mainframe screen. - Page 29 Digital Video Recorder Channel: select the channel you want to enable lens shading alarm. Enable: function enable switch Period: Click set button, you can see an interface is shown as in below. Here you can set for business day and non-business day. You can set up six time period, but they can’t be repeated.
-
Page 30: Alarm Input
Digital Video Recorder Tour; Here you can enable tour function when alarm occurs. It is a one-window tour. Latch: when video lost complete, system auto delays detecting for a specified time. The value ranges from 10-300 (Unit: second) Channel: select the channel to activate recording function once alarm occurred. - Page 31 Digital Video Recorder Alarm input: select alarm channel number Enable: function enable switch Type: normal open or normal close. Period: Click set button, you can see an interface is shown as in below. Here you can set for business day and non-business day. You can set up six time period, but they can’t...
-
Page 32: Alarm Output
Digital Video Recorder Latch: Here is for you to set proper delay duration. Value ranges from 0 to 600 seconds. Alarm output: activate peripheral alarm device when motion detection occurred. Show message: System can pop up a message to alarm you in the local host screen if you enabled this function Send email: System can send out email to alert you when alarm occurs. -
Page 33: Abnormity
Digital Video Recorder Alarm Type: There are two types for you to select. Schedule: Select all or “1”●, “2”●, “3”●, “4”● for the first channel、second channel、 third channel or forth channel. Manual: Select all or “1”●, “2”●, “3”●, “4”● for the first channel、second channel、third channel or forth channel. -
Page 34: Digital Alarm
Digital Video Recorder on the screen when alarm signal happens. Latch: system auto delays for a specified time. The value ranges from 10-300 (Unit: second) Send email: System can send out email to alert you when alarm occurs. Buzzer: Default is “off”... -
Page 35: Setting
Digital Video Recorder Send email: System can send out email to alert you when alarm occurs. Tour: Here you can enable tour function when alarm occurs. It is a one-window tour. Latch: when motion detection, system auto delays recording for a specified time. The value ranges from 10-300 (Unit: second) Buzzer: Default is “off”... -
Page 36: General
Digital Video Recorder 3.7.1 General System time: here is for you to set system time Date format: there are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY. DST: Here you can set DST time and date. Please enable DST function and then click set button. -
Page 37: Encode
Digital Video Recorder recording is the present working disk is full or under covering and the next disk is non-empty. The condition of rewrite is the present working disk is full and the next disk is non-empty. DVR No: when you are using one remote control to control several DVRs, you can give a name to each DVR for your management. -
Page 38: Network
Digital Video Recorder Bit rate: system supports two types: CBR and VBR Quality: There are six levels ranging from 1 to 6. The sixth level has the highest image quality. Bit rate: 0kb/s-4096kb/s optional Frame interval: can set 1 frame, 2-12 optional. - Page 39 Digital Video Recorder Note: Please fulfill the postfix of the mail address virtual,(e.g. xxxx@yyyy.com) otherwise it is not allowed. (e.g. xxxx) Primary DNS ： According to local Secondary DNS ：According to local DDNSDDNS Type: Support DDNS server Domain Name: Your self-defined domain name.
-
Page 40: Display
Digital Video Recorder 3.7.4 Display Channel display: Click modify button. You can see an interface is shown as above, including time display, channel display, recording state, alarm state . Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255. -
Page 41: Account
Digital Video Recorder Time Display: You can select to display time by IE or playback. Channel Display: You can select to display channel name by IE or playback.； Setting: You can move or change the display location of “time display” , ”channel display”... - Page 42 Digital Video Recorder For group or user management, there are two levels: admin and user. User management adopts group and user 2 class ways, group name can not repeat, user name can not repeat, each user must belong to certain group; one user can belong to one group only.
- Page 43 Digital Video Recorder Modify group: modify existing group. Add user: add group user and select corresponding rights...
- Page 44 Digital Video Recorder There are 2 default users: “admin” “guest”. “admin” users have administrator right. The default password is “123456” for all 2 default users’ account. “guest” user only can review playback and backup. About reusable function: this function allows multiple users use the same account to login.
-
Page 45: Ptz
Digital Video Recorder 3.7.6 PTZ Note: The camera video should be in the current screen. Before setup, please check the following connections are right: Address: input corresponding PTZ address. Decoder A (B) line connects with DVR A (B) line. Boot up the DVR, input user name and password. -
Page 46: Rs232
Digital Video Recorder 3.7.7 RS232 Function: There are various devices for you to select. Console is for serial port or min-end platform to upgrade program. Keyboard is for you to control current device. Baud rate: You can select proper baud rate. -
Page 47: Tour
Digital Video Recorder 3.7.8 Tour Set tour and time, interval is 5-120s, includes single picture, 4 pictures, 8 pictures, 9 /16pictures. 3.8 Adanced Management tool menu includes: HDD management, On-line user, TV adjust, USB update, Auto Maintenance, Restore, and Shut Down. -
Page 48: Digital Channel
Digital Video Recorder If 2pcs HDD installed, then displayed as 1-2 in HDD. If selecting the first HDD, it displays current type, total capacity, and record time. You can modify HDD attribute, read-only disk, read-write disk, redundancy disk or delete all the data in the HDD. After all the setups please click OK button, system goes back to the previous menu Note: You can set proper mode for each hard disk from the dropdown list. -
Page 49: Usb Update
Digital Video Recorder Type: normal open or normal close. Decode Policy: Set the digital channel policy, there are 5 selects Video Audio: Select the Audio or Video or both Remote Channle: Select the channel for remote Steamtype: Main stream or Sub stream... -
Page 50: Configuration
Digital Video Recorder Connect to the USB port on the rear panel with the USB device, which has upgrade file, and then select the file to upgrade. The upgrade includes kernel, u-boot, setting, applications and file system. 3.8.4 Configuration... -
Page 51: Maintenance
Digital Video Recorder Output setting Connect to the USB interface on the rear panel with the USB equipment, set the system output into a file named cfg.coi Input setting Connect to the USB interface on the rear panel with the USB equipment, select setting file to input. -
Page 52: Default
Digital Video Recorder You can select proper setup from dropdown list. After all the setups please click save button, system goes back to the previous menu. 3.8.6 Default You can highlight to restore default factory setup. Select all General Encode... -
Page 53: Exit
Digital Video Recorder 3.8.7 Exit Logout: exit menu, you need to provide password again when entering the menu next time. Shut down machine: logout system turns off power Restart system: system begins rebooting. Switch: switch users When push the power switch button, will appear a confirmation progress bar, shut down 3 seconds after, can been cancelled during progress. -
Page 54: System Information
Digital Video Recorder 3.9 System Information 3.9.1 HDD Information Here is to list hard disk type, total space, free space, video start time and status Note: Please remove the broken hard disk before you add a new one. Once there is a hard disk confliction, please check hard disk time and system time is the same or not. -
Page 55: Bps
Digital Video Recorder HDD array according to SATA interface sequence. For example, SATA1 HDD in the first, SATA2 HDD in the last. 3.9.2 BPS Here is for you to view current video data stream (KB/s) and occupied hard d isk... -
Page 56: Log
Digital Video Recorder 3.9.3 LOG Here is for you to view system log file. System lists the following information. Log types include system operation, configuration operation, data management, alarm event, record operation, log clear and etc. Pleased select start time and end time, then click search button. You can view the log files. -
Page 57: Record Control
Digital Video Recorder 3.10 Record Control There are two ways for you to go to manual record menu. Right click mouse or in the main menu, Advanced->Manual Record. In live viewing mode, click record button in the front panel or record button in the remote control There are three statuses: schedule/manual/stop. -
Page 58: Ptz Control
Digital Video Recorder Menu->Setting->Schedule) Stop: all channels stop recording. Enable all channel recording: system enable all channel recording Stop all channel recording: System stops all channel recording 1．Enable/disable record Please check current channel status: “○” means it is not in recording status, “●” means it is in recording status. - Page 59 Digital Video Recorder Hide PTZ menu by double click the menu title. Click Pan/Tilt/Zoom, the interface is shown as below, Speed: mainly to control direction. For example, step 8 is much faster than step 1. (Input the number 1~8 by mouse click or front panel, 8 is the biggest)
- Page 60 Digital Video Recorder as gray, right click mouse or press ESC key on the front panel back to figure 1. Patrol setup (Tour Setup) Click patrol button. The interface is shown as below. Input preset number and add this preset to a patrol (tour). For each patrol (tour), you can input max 80 presets.
-
Page 61: Color Setting
Digital Video Recorder Note: Preset, tour and pattern all need the value to be the control parameter. You can define it as you require. You need to refer to your speed dome user’s manual for Aux definition. In some cases, it can be used for special process. - Page 62 Digital Video Recorder Adjust picture’s up, down, left, right deflate. Please drag slide bar to adjust each item, adjust range value from 0 ~ 100, default value 0.
-
Page 63: Addenda A Faq
Digital Video Recorder Addenda A FAQ 1. DVR cannot boot up properly. There are following possibilities: Input power is not correct. Power connection is not correct. Power switch button is damaged. Program upgrade is wrong. HDD malfunction or something wrong with HDD ribbon. - Page 64 Digital Video Recorder 6. Real-time video color is distorted. There are following possibilities: When using BNC output, NTSC and PAL setup is not correct. The real-time video becomes black and white. DVR and monitor resistance is not compatible.
- Page 65 Digital Video Recorder Crystal is not broken. 12. DVR cannot control PTZ. There are following possibilities: Front panel PTZ error PTZ decoder setup, connection or installation is not correct. Cable connection is not correct. PTZ setup is not correct.
- Page 66 Digital Video Recorder 16. Network connection is not stable. There are following possibilities: Network is not stable. IP address conflict. MAC address conflict. PC or DVR network card is not good. 17. Alarm signal cannot been disarmed.
-
Page 67: Appreda E: Web Client Operation
Digital Video Recorder Appreda E: WEB CLIENT OPERATION IE Browser Setup Please make sure your PC installed Microsoft Internet Explorer 6.0, and DirectX 9.0 or higher version., Note: Please turn off the Firewall and Antivirus Software if necessary. When log in the DVR first time, if all the functions run properly, in this case you could set the Security as default level. - Page 68 Digital Video Recorder the right side tree structure, when the icon becomes a small camera, you can review this channel. Toolbar There are few function buttons in the toolbar, at upside and downside Playback：Record video inquiry, playback and download Configuration：DVR parameter configuration。...
- Page 69 Digital Video Recorder : 13-channel display； ：16-channel display； ：20-channel display； ：25-channel display； ：36-channel display。 Review the channel Double click the channel number in the right side tree structure, when the icon become a small camera, you can review this channel.
-
Page 70: Ptz Control Function
Digital Video Recorder Review Review toolbar in the up-right side of channel, shown as below ； : Capture picture. You can snapshoot important video. All images are memorized in folder C:\RC\； : Local record. When you click local record button, the system begins recording and this button becomes highlighted, all videos are memorized in folder C:\RC\ ；... - Page 71 Digital Video Recorder Direction Key: 8 direction keys, Click and holding for continuous control. Step Speed: Control PTZ speed and patrol speed. Zoom: adjust and control PTZ zoom Focus: adjust and control PTZ focus Iris: adjust and control PTZ iris.
- Page 72 Digital Video Recorder Click PTZ setup button you can see the following interface Click the PTZ camera channel, move the camera to you desired location and then click left limit button. Then move the camera again and then click right limit button to set a right limit.
-
Page 73: Web Client Configure
Digital Video Recorder : Reset all to default; Other setting snapshot：Snapshot, and path：C:\RC\ record path：Record path：C:\RC\ reboot：Restart the device record size：Set file size WEB CLIENT Configure System Info In the main window, click config button, you can see an interface is shown as... - Page 74 Digital Video Recorder System Information: Click device configuration button, you can see the following interface, Hardware version, HDD information, Interface, Log inquiry. Setting: Setting includes the following items: General, Encode setup, Schedule, RS232, Network, MUL-DDNS, FTP, Alarm setup, Detect, Pan/Tilt/Zoom, Tool...
-
Page 75: System Setting
System Setting General General interface is shown as below.； System time: Here is for you to modify system time. Please click Save after your modification Data format: Here you can select data format from the dropdown list. Data separator: Please select separator such as – or /. ... - Page 76 Digital Video Recorder Encode Encode setup includes the following items Channel: Here is for you to select a channel. Compression: H.264; Data stream: Regular and extra data stream; AV enable: Video/Audio. System only displays video by default. You need to manually enable audio function ...
- Page 77 Digital Video Recorder Week: you can select from the dropdown list. Or you can select at the bottom of the interface. Prerecord: system can record the three to five seconds video before activating the record operation into the file.(Depends on data size) ...
- Page 78 RS2332 RS232 includes the following items. Function: There are various devices for you to select. Console is for serial port or min-end platform to upgrade program. Keyboard is for you to use special keyboard to control current device. Baud rate: Please select as you desire. ...
- Page 79 Network Network interface is shown as below. This interface includes the following items； DNS: Set DNS and backup DNS address DDNS: Set DDNS type, Domain name, User name, Password； UPNP: Set UPNP, Web Port, TCP Port...
- Page 80 Digital Video Recorder User Manual PPPoE: Set PPPoE User name, password, and IP address PTZ: Set PTZ channel, protocols, bitrate, stop bit, data bit, varity, Default: PELCOD,1,9600,8,1,...
- Page 81 Digital Video Recorder User Manual Reset to default: Reset selected functions to default Alarm Alarm in: Select corresponding alarm in channel...
- Page 82 Digital Video Recorder User Manual Video Detect: Set video detection area, latch, output channel, PTZ, Buzzer. Alarm output: select alarm activation channel when alarm occurs.
- Page 83 Digital Video Recorder User Manual Exception Deal: Event type: no disk space, hard disk error, Not enough space, network failure ,IP address conflict, Buzzer, send e-mail Advanced set DVR’s record, Read, Write, auto maintenance。 Disk Manage: Set HDD as Read, Write, Read-only, Reduncey, Erase the data,...
- Page 84 Digital Video Recorder User Manual Upgrade: Select update file to upgrade the DVR； Record Control : Set record status: Schedule / Manual / Stop...
- Page 85 Digital Video Recorder User Manual User Account anagement user account, adding users, modity users, User Account: M password, group. Auto Maintenance, Reboot, auto delete old file...
