- Page 1 ™ EOS Mini OwnEr’S Manual...
-
Page 2: Table Of Contents
Table of ConTenTs Halcyon eos Mini features ™ light Components High/Low Power Setting Battery Operation Rear Attachment Point Handle Operation Handle adjustment Charger Operation Charger Warning Contacting Halcyon... -
Page 3: Halcyon Eos Mini ™ Features
Compact, auto, voltage-sensing charger ©2013 Halcyon Manufacturing, Inc. This owner’s manual is copyrighted, all rights reserved. It may not, in whole or in part, be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form without prior written consent from Halcyon Manufacturing, Inc. -
Page 4: Light Components
Components Your Halcyon EOS Mini is made from ™ two sealed compartments using gold plated connectors to support trouble-free operation. Your light is actuated by turning the battery clockwise into the housing; twist counterclockwise to turn off. Two sealed compartments with gold-plated... -
Page 5: High/Low Power Setting
High/Low Power Setting Three (3) high-power LED modules emit more than 13,000 Lux. Turning the light on, then off, then immediately back on reduces the intensity to half power. To ensure a proper seal, never unscrew past the first O-ring while underwater. Three high-power LEDs compliment a robust design and highly adjustable handle. -
Page 6: Battery Operation
Battery Operation The battery compartment contains two O-rings. The one farthest from the light head is used primarily as a reference; it also serves as a backup seal. You should be sure both are clean and slightly lubricated. Sealed LiOn battery with about three hours of operation;... -
Page 7: Rear Attachment Point
Rear Attachment Point The rear attachment point accommodates nearly any bolt snap or wrist lanyard. You may secure the light to your harness or in a pocket. The rear clip is also useful when a temporary storage location is required; clipping to an upper D-ring will help illuminate your working area. -
Page 8: Handle Operation
Handle Operation The EOS Mini handle protects the ™ LED module while closed and may be opened by using the lock knob on the side. Rotate the tip of the handle toward “RH” or “LH” for right- or left-hand use. Do not force the lock knob past its natural stopping point. -
Page 9: Handle Adjustment
Handle adjustment The handle can be height or width adjusted. Use the lock knob to adjust height; pull the handle gently apart to set the appropriate width. The bungie can be secured around your thumb for extra security. Some divers prefer the light without the bungie in place. -
Page 10: Charger Operation
Charger Operation Your compact Halcyon charger has automatic voltage sensing. You can use it interchangeably with 110v or 220v supply. In order to charge your light you should screw the battery into the charger, taking care not to cross-thread during assembly. Do not leave the battery in the charger unless it is plugged into a wall outlet. -
Page 11: Charger Warning
Charger Warning The light on the charger will burn green when power is supplied. It will turn red when charging. It takes approximately three hours to completely charge the battery. Please note the charger will slowly discharge the battery unless plugged into a wall outlet. Remove the battery from the charger base when not plugged into a power source. -
Page 12: Contacting Halcyon
ConTaCTIng HalCyon Halcyon Manufacturing, Inc. 386.454.0811 1110 S. Main Street 800.HALCYON High Springs, FL 32643 USA 386.454.0815 (fax) www.halcyon.net info@halcyon.net...
