Summary of Contents for Microlatch BIO-13
- Page 1 Microlatch™ Wireless Fingerprint Access Control BIO-13 BIO-14 BIO-15 Installation and Operation Manual...
- Page 3 Microlatch™ Wireless Fingerprint Access Control BIO-13 BIO-14 BIO-15 Installation and Operation Manual...
-
Page 4: Table Of Contents
3.2 REC-18 RF Controller 3.3 Battery Replacement Warranty Information ………………………………………………………………………. 13 4.1 Warranty Product Specifications …………………………………………………………………….. 14 5.1 Microlatch™ BIO-13 / BIO-14 / BIO-15 Biometric Fingerprint Readers 5.2 Microlatch™ REC-18 RF Controller Authorised User List ……………………………………………………………………….. 15 - 2 -... -
Page 5: Overview
BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual OVERVIEW Thank you for purchasing Microlatch™ BIO-13 / BIO-14 / BIO-15 Wireless Fingerprint Access Control. Your newly purchased BIO-13 / BIO-14 / BIO-15 is a unique, self contained biometrics fingerprint reader that requires: • NO external power source •... -
Page 6: Biometric Fingerprint Reader - Operation Instructions
BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual BIOMETRIC FINGERPRINT READER – OPERATION INSTRUCTIONS 1.1. Description The Biometric Fingerprint Reader (BIO-13, BIO-14 or BIO-15) has three LED status indicators as shown below: AMBER During operation the AMBER (CENTRE) AMBER... -
Page 7: Enrolment
Microlatch BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual 1.3. Enrolment 1.3.1. Enrolment - On First Power Up When you purchase the Biometric Reader new, there are no fingerprints in the database. The first TWO fingerprints enrolled will become "Administrators", namely ADMIN 1 and ADMIN 2 On first power up unit automatically enters the ENROLMENT MODE emitting the tone (dit dit dit dit). -
Page 8: 1.3.2. Entering Enrolment When There Are Fingerprints In The Database
Microlatch BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual 1.3.2. Entering enrolment when there are fingerprints in the database ONLY the TWO administrators (ADMIN 1 & 2) can access ENROLMENT MODE. An administrator places finger as per normal operation (See 1.2. - Page 9 Microlatch BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual 1.3.3. Deleting Fingerprints of All Users Enter ENROLMENT MODE using ADMIN 1 finger. (See 1.3.2.) Re-enrol ADMIN 1. On the THIRD finger presentation do not remove finger when AMBER LED goes OFF.
-
Page 10: User Groups
Microlatch BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual NOTE: A HIGHER RANKING finger (user) is a finger which is enrolled after the presented finger. For example, by presenting finger of user No. 5, the system will delete user No. -
Page 11: Rec-18 Rf Controller - Installation Instructions
Microlatch BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual REC-18 RF CONTROLLER – INSTALLATION INSTRUCTIONS NOTE - These instructions are designed for professional installers only 2.1. Description Drill cable entry hole in cable entry area of case. Wiring may be brought into the case from the rear, side or bottom. -
Page 12: Rec-18 Connection Terminals - Outputs Description
Microlatch BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual 2.4. REC-18 Connection Terminals – Outputs Description Door lock output. (User group 1) This output is timed and the time is set using the 4 way DIP switch in the REC-18 C1, NC1, NO1 Controller. -
Page 13: Care & Maintenance
These batteries should all last at least 6 – 12 months before replacement is required. To replace the batteries: For the BIO-13 and BIO-14 fingerprint readers remove the security screw at bottom of the case using the tool supplied. Remove the front case by grasping between the thumb and forefinger and applying pressure at the two marks on either side of the case. - Page 14 Microlatch BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual For the BIO-15 fingerprint reader remove the faceplate and then using a screwdriver to remove the Bio15 from the wall box unit. Ensure correct polarity and use only batteries specified.
-
Page 15: Warranty Information
Malfunction or failure of product due to the use of non-genuine, Microlatch parts. To the extent permitted by law, Microlatch shall not be liable to the products, common user or any other person for any incidental or consequential damages arising howsoever and including but not limited to damages from and defects, malfunction, or failure of any product or component. -
Page 16: Product Specifications
Microlatch BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual PRODUCT SPECIFICATIONS 5.1. Microlatch™ BIO-13 / BIO-14 / BIO-15 Biometric Fingerprint Readers Operating Voltage 6VDC BIO13 - 1.5 V AA Alkaline Cell x 4 BIO14 - 3V CR123A Lithium Cell x 4 Battery Type BIO15 - 1.5 V AA Alkaline Cell x 4 or... -
Page 17: Microlatch™ Rec-18 Rf Controller
Microlatch BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual 5.2. Microlatch™ REC-18 RF Controller 10 - 15VDC regulated 300mA minimum battery Operating Voltage backed supply recommended. Power ON indicator Green LED 26mA standby 175mA doorchime 1 second Current consumption... -
Page 18: Authorised User List
Microlatch BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual AUTHORISED USER LIST Zone: ___________ Access Access User Name User Name Level Level User Group Admin 1 1 / 2 User Group Admin 2 1 / 2 User Group User Group... - Page 19 Microlatch BIO-13 / BIO-14 / BIO-15 Installation and Operation Manual NOTES - 17 -...
- Page 20 WARRANTY CARD Model Number Serial Number Date of Purchase Name Address City, Postcode State, Country Email address Dealer Stamp Here...
- Page 21 Microlatch Limited ABN 52 059 640 747 www.microlatch.com Microlatch™ is a registered trademark of Microlatch Pty Ltd BIO-13, BIO-14 & BIO-15 are worldwide patented products. PCT/2004/001083 © 2009 Microlatch™ All rights reserved N14528 V6.0.2 EN...
