Jay-tech HD-Sonnenbrille DL-1221C User Manual

1. Product Introduction

Power / Capture
Video / Voice
Recording
Lens
Video / Voice
Power / Shutter
Recording
Reset
Green LED
Indicator
Microphone
Micro-SD slot
USB Port
Red LED
Indicator

2. Operation Procedure

Important notIce!
A microSD card is required to be inserted into the device before
utilization.
Yellow Blue
Function Operation LED LED
Status Status
Standby Press to power on the device. On ---
Video Press once to start video recording. Keep
On
Recording Flashing
Press again to stop video recording.
Photo Flash
Press once to take one photo. On
Capture Once
Press and hold 3 seconds to start
Voice voice recording. Keep Keep
Recording Flashing Flashing
Press and hold 3 seconds again to
stop recording.
Connect the device with USB cable to
Battery adaptor or computer. Keep Keep
Charging Blue LED will stop flashing after the Flashing Flashing
battery is fully charged.
Press and hold 3 seconds to power
Power Off --- ---
off the device.

3. Connect to PC

Connect the device to a PC through USB cable. The device will
automatically been indentified as a Removable Disk. You may download,
delete, copy or paste files between device and PC.

4. Product Specification

File Format AVI / JPG / WAV
Video: 1280x720
Resolution
Photo: 2560x1920
Memory Card microSD 1GB~16GB
5V DC / 400 mAh
Power Source
Built-in 3.7V 400mAh Li-Polymer Battery
Battery Life Approx. 3-4 hours
Weight Approx. 50 g
Operating Temperature 0°C ~ 60°C
Storage Temperature -20°C ~ 80°C
Operating System Windows XP / 2000 / Vista / Windows 7
■ Carrying case
■ Cleaning cloth
■ USB cable
Package Contents
■ Power Adapter for charging
■ User's manual
■ Warranty card

EC Declaration of Conformity

The product complies with the protective requirements of
European Directives 2004/108/EC.
The conformity declaration for this product is available
under www.jay-tech.de.
Directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE)
This symbol on the product or in the instructions means that
your electrical and electronic equipment should be disposed
at the end of its life separately from your household waste.
There are separate collection systems for recycling in the
EU. For more information, please contact the local authority
or your retailer where you purchased the product.
