Summary of Contents for Prime Source GRC58A
- Page 1 OPERATOR’S MANUAL AND PARTS LIST MODEL GRC58A PLASTIC CAP STAPLER Distributed By www.grip-rite.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS SPECIFICATIONS TABLE OF CONTENTS -------------------------------- 2 MODEL GRC58A Plastic Cap Stapler SPECIFICATIONS --------------------------------------- 3 STAPLE GAUGE 21 GA. (.080”) (2 mm) Flat Wire Staples SAFETY ---------------------------------------------------- 4 STAPLE SIZE 1/2” (12.8 mm) Crown x 5/8” (15.8 mm) Long... -
Page 3: Safety
SAFETY SAFETY SAFETY LABELS SAFETY INSTRUCTIONS This pneumatic fastening tool includes a warning label to help remind you of important safety information when operating the tool. The safety label must be WEAR SAFETY GLASSES legible at all times, and must be replaced if it becomes worn or damaged. Always wear safety glasses with side shields that meet ANSI Z87.1 requirements when operating the tool. -
Page 4: Specifications
SAFETY SAFETY SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS DO NOT ATTEMPT TO OPERATE THE TOOL IF THE TOOL’S KEEP HANDS AND BODY PARTS AWAY FROM AREA BEING OPERATING CONTROLS HAVE BEEN MODIFIED OR ARE NOT FASTENED. WORKING PROPERLY. Fasteners can deflect and turn as they are being driven into Attempting to use a tool with modified or malfunctioning the workpiece, and penetrate fingers, hands, and other body trigger or workpiece contact can result in a fastener being... -
Page 5: Tool Parts
DESCRIPTION DESCRIPTION TOOL PARTS PART DESCRIPTIONS 1. Cylinder Cap - Covers main valve and piston assembly. 2. Handle - Cushioned handgrip provides comfortable operation. 3. Air Coupling - Quick-disconnect male coupling allows quick connection to air hose. Dust cap keeps dirt out when tool is not in use. -
Page 6: Loading Fasteners
OPERATION OPERATION LOADING FASTENERS LOADING PLASTIC CAPS LOADING INSTRUCTIONS LOADING INSTRUCTIONS 1. Disconnect tool from air supply DANGER using quick-connect coupling. 2. Open loading tower door by A fastener can be driven unintentionally if the trigger and safety bracket pulling follower handle all the are activated at the same time. -
Page 7: Operation
OPERATION MAINTENANCE LOADING INSTRUCTIONS (Cont’d) CONTACT TRIP (BUMP FIRE) DRIVING METHOD 5. Pull follower handle back and 1. Position the nose of the tool over the work surface, near the area in to close tower door. Door where the first fastener/cap is to be driven. must click into locked posi- 2. -
Page 8: Parts Schematic
PARTS SCHEMATIC PARTS LIST ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION GRBN204 MAGAZINE A GRBN312 DEFLECTOR GRBN205 PROT. HOOD COVER GRBN308 BOLT ASSY GRBN206 SPRING GRBN313 GRBN207 LATCH GRBN296 SEAL GRBN208 LATCH PIN GRBN314 COMPRESSION SPRING GRBN209 E - RING GRBN297 O - RING GRBN210 PULL SPRING... -
Page 9: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING TOOL TROUBLESHOOTING FASTENER DRIVING PROBLEMS Your pneumatic fastening tool has been designed for long life and trouble- free operation. However, if operating problems arise, please use the Fastener jammed in Depress magazine release, and open maga- troubleshooting information below to determine how to remedy the prob- tool nose, preventing zine. -
Page 10: Warranty
WARRANTY WARRANTY PNEUMATIC TOOL/COMPRESSOR WARRANTY PNEUMATIC TOOL/COMPRESSOR SERVICE INFORMATION Should any mechanical problems develop during the life of your Pneumatic nailers, staplers & compressors marketed under the equipment the following options are available for service and parts: GRIP RITE brand are warranted to be free from defects in work- manship &... - Page 11 USE GENUINE GRIP-RITE® FASTENERS FOR BEST PERFORMANCE www.grip-rite.com MANC58A...
