Summary of Contents for Displaze MPEG4 Media player
-
Page 1: Users Guide
DISPLAZE LIMITED MPEG4 Media Player Released MPEG4 Media Player Users Guide MPEG4 Users Guide.doc Users Guide Printed: 01/06/2005 Revision: 13 1 of 14... -
Page 2: Revision History
MOISTURE. ALSO THAT THE UNIT IS POWERED USING AN APPROPRIATE RATED POWER SUPPLY. Introduction This documents describes the use of the MPEG4 Media Player a MPEG4 Video and Still Image media Player. Document Classification This Document/message is intended only for the use of the individual or entity to which it is addressed and contains information that is privileged and confidential. -
Page 3: Specification
DISPLAZE LIMITED MPEG4 Media Player Released Specification Max Resolution 720 x 480 pixels Card Formats CF I/II, SD, MS, MS-Pro File Formats ASF, AVI, JPEG, MJPEG, MPEG1, MPEG2, MP3, MPEG4, WMA, XVID Outputs RGB VGA, Component, S-Video, Stereo Audio Controls... - Page 4 MPEG4 Media Player Released Description The MPEG4 Media Player is a Multi Format Media Player. It is capable of playing Photos, Music and Video files. If offers a choice of output format types, list below, to suite most applications. Background music files may be played whilst slideshows are being viewed.
- Page 5 DISPLAZE LIMITED MPEG4 Media Player Released Connectors The various connectors for the MPEG4 Media Player are illustrated below:- Power 1.3/3.8mm Jack Socket, all-internal electronics are supplied with power via this connector. Part No. Pin No.: Description Analogue RGB Output A high-density 15-way D-Type connector providing Colour and Sync signals to the LCD driver card.
- Page 6 DISPLAZE LIMITED MPEG4 Media Player Released S-Video video output Socket View Part No. Pin No.: Description GND ( Y ) GND ( C ) Intensity (Y Luminance) Color (C Chrominance) Composite video output Part No. Pin No.: Description Composite Video Audio Output Part No.
-
Page 7: Display Setup
DISPLAZE LIMITED MPEG4 Media Player Released Display Set-up All Control of the MPEG4 Media Player is performed via the remote control unit supplied. Key Name Description POWER Turns ON/OFF the system Zoom Zoom (2x, 4x OFF) Rotate Rotate Image by 0, 90, 180, 270 degrees... -
Page 8: Accessing The Menu System
3. To return to the previous menu navigate the to Exit Menu bar and press ENTER. Menus and Options Setup Menu Press SETUP to enter the configuration menus for the MPEG4 Media Player. This menu configures the specific options available for:- PHOTO Setup... -
Page 9: Photo Menu
Select this line and press ENTER to return to the previous menu. Main Menu If more than one memory device is inserted in to the MPEG4 Media Player this menu will appear. Select which memory device to use and press ENTER... -
Page 10: Music Menu
DISPLAZE LIMITED MPEG4 Media Player Released Press the T button to change the slideshow transition effects. You can choose from :- Full Screen Roll: Right to Left Roll: Top to Bottom Roll: Left/Right to Center Roll: Bottom to Top Roll: Center to Left/Right... - Page 11 This option will display file properties. Press ENTER to exit window. Note: Most memory card formats are supported on the MPEG4 Media Player however not all memory cards are compatible. Please check compatibility in unit prior to final selection. MPEG4 Users Guide.doc...
-
Page 12: Recommended Use
DISPLAZE LIMITED MPEG4 Media Player Released Recommended Use Safety Precautions and Maintenance FOR OPTIMUM PERFORMANCE, PLEASE NOTE THE FOLLOWING WHEN SETTING UP AND USING AN LCD MONITOR DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or removing covers may expose you to dangerous shock hazards or other risks. -
Page 13: Packing List
Packing List Part No.: Description O = Included X = Optional MPEG4 MPEG4 Media Player multi-output driver card RC-610 IR Remote Control MPEG4-CABA Stereo Audio Cable, Jack plug to RCA Phono MPEG4-CABV Composite Video Cable, Jack to RCA Phone... - Page 14 DISPLAZE LIMITED MPEG4 Media Player Released Appendix A Mechanical Dimensions Electrical Characteristics Item Symbol Condition MIN. TYP. MAX. Unit Supply Voltage ------ Current Consumption Notes : MPEG4 Users Guide.doc Users Guide Printed: 01/06/2005 Revision: 13 14 of 14...
