Summary of Contents for Ad Notam CL_LED
- Page 1 MIRROR TIME DIGITAL CLOCK Art.No. CL_LED...
- Page 2 Specifications of the ad notam products are subject to unannounced changes; this manual may thus not reflect the current technical status.
- Page 3 With an optional Y-cable (ET_551) you might use the 12V DC power adaptor of a combined ad notam DFU monitor system to operate the Mirror Time digital clock. When installing the Mirror Time digital clock without connection to the 12V DC power adaptor of an ad notam DFU monitor system, a separate power adaptor (ET_550) is essential to operate it.
- Page 4 Add a new feature to your ad notam mirror with the new Mirror Time digital clock. Mirror Time can be positioned almost anywhere on the mirror surface beyond the active screen area to show the time with class. Mirror Time features bright white LED digit design, and can be combined with any of the ad notam illumination options for a cool complete „glowing“...
- Page 5 Option 2 - Connection to the 12V DC power adaptor of an ad notam DFU monitor system: Connect the Mirror Time digital clock with an optional Y-cable (ET_551) to the 12V DC power adaptor of an ad notam DFU monitor system.
-
Page 6: Technical Specification
51mm 2.01“ 2.01“ 12V DC 12V DC RANCE TECHNICAL SPECIFICATION Features CL_LED Display Type 4 x 1” 7-segment b�ight white LED digit design Time Format 1� / �4 hou�s selectable (default 1� hou�s) TECHNICAL SPECIFICATION TECHNICAL SPECIFICATION Power Consumption 1�V DC / 1A Inte�na... - Page 7 KEY ASSIGNMENT KEYS DESCRIPTION ON/OFF ä switch clock on/off and escape in Edit or Timer mode EDIT ä enter 12/24 hours mode to switch between 12 and 24 hours TIME ä enter Timer mode to set the time CURSOR LEFT/RIGHT ä move to the last/next digit in Timer mode CURSOR UP/DOWN ä...
- Page 8 Web: www.ad-notam.com E-Mail: info@ad-notam.com For your local distributor please visit: www.ad-notam.com / contact / worldwide reps ad notam USER GUIDE * 6. February 2013 * Version 1.0 6. February 2013 * Version 1.0 * Version 1.0...
