Mintron MHD-61S2S User Manual

Model: MHD-61S2S

GENERAL:

MHD-61S2S is able to extend the HD-SDI signal transmission distance between HD-SDI
devices at data rates up to 1.485Gb/s and be compliant with SMPTE 292M, 296M standards.
In addition, it allows simultaneous signal transmission, camera control (RS-485) and power
over a single cable which is with re-use of coax infrastructure.

FEATURES:

 Support high-definition HD-SDI digital video at 720p60, 1080i60 and 1080p30 formats at
all frame rates.
 HD-SDI standard SMPTE292M, 296M at 1.485Gb/s data rate.
 Integrated cable equalizer for long distance video transmission without loss of quality.
 High quality digital video and audio transmission with near zero latency.
 Re-clocker to resynchronize the signal—bring it back to its original condition.
 Cable Driver to retransmit the signal with its original characteristics restored.
 Support Coaxial-link(C-LINK),
o Cameras and repeaters' power can be powered by coaxial cable.
o Camera control signal (RS-485) can be transmitted by coaxial cable.
P
ACKAGE CONTENT
 Main unit(MHD-61S2S) ---------X1
 User manual------------------------X1
 AUX cable--------------------------X1
User Guide
HD-SDI Repeater
1
