Durabrand ADB2737BDS Quick Setup Manual

E9G05BD_QSG_EN.fm Page 1 Wednesday, April 11, 2007 9:57 AM

Finalising a Disc

Finalise
You must first finalise the disc before playing it back on other unit.
SETUP
1 Press [SETUP] in stop mode.
Setup Menu will appear.
2 Select "DVD Menu" using [U / D], then press
[ENTER].
3 Select "Finalise" using [U / D], then press
ENTER
[ENTER].
Format
Finalise
Disc Protect OFF ON
Delete All Playlists
Select "Yes" using [U / D], then press [ENTER].
4
Finalise disc?
ENTER
Yes
No
Finalising will start.
• This operation may take awhile to be completed.
• If you insert a DVD-RW disc finalised with this unit, "Undo
Finalise" will appear instead of "Finalise". To Undo the
finalisation of the disc, select "Undo Finalise" and press
[ENTER].

VCR Playback / Recording

Playback
STANDBY-ON 1 Press [STANDBY-ON] to turn on the unit.
To play back a tape, turn on the TV and be sure to select the
input to which the unit is connected.
VCR
2 Press [VCR ].
PLAY
3 Insert a pre-recorded tape, then press [PLAY P] to
begin playback.
PAUSE
4 During playback, press [PAUSE p].
Playback will be paused and sound will be muted.
PLAY
5 Press [PLAY P] to resume playback.
STOP
6 Press [STOP S] to stop playback.
7 Press [OPEN / CLOSE O] to eject the tape.
OPEN/CLOSE
Note
• When a tape without record tab is inserted, the unit will start playback
automatically.
• Tracking will be automatically adjusted upon playback. To adjust the
tracking manually, press [PROG. K / L].
Produced for ASDA Stores Ltd., LEEDS LS11 5AD

DVD Playback

Direct Playback
STANDBY-ON
1 Press [STANDBY-ON] to turn on the unit.
Turn on the TV and be sure to select the input to which the
unit is connected.
DVD
2 Press [DVD ].
3 Press [OPEN / CLOSE O] to open the disc tray.
OPEN/CLOSE
4 Place the disc on the disc tray with its label facing
up. Be sure to align the disc with the disc tray
guide.
Disc tray guide
5 Press [OPEN / CLOSE O] to close the disc tray.
OPEN/CLOSE
6 Press [PLAY P] to start playback.
Playback will start.
PLAY
• Depending on the media, the playback may start from a
resume point. (See page 43 on the Owner's Manual for
details.)
• If you are playing back a DVD-Video, a Disc Menu may
appear. Refer to page 42 on the Owner's Manual for more
details about the Disc Menu.
STOP
7 Press [STOP S] to stop playback.
Note
• Some discs may start playback automatically.
Basic Recording
Before recording, make sure:
• The desired channel is selected by pressing [the Number buttons] or
[PROG. K / L] on the remote control.
• There is a tape with a record tab in the unit.
• The desired recording speed is selected in SP (standard play) or LP
(long play) mode by pressing [REC SPEED] on the remote control.
Tape speed Recording / Playback Time
Type of tape E60 E120 E180 E240
SP mode 1 hour 2 hours 3 hours 4 hours
LP mode 2 hours 4 hours 6 hours 8 hours
1 Turn on the unit and insert a recordable tape.
Make sure that the TV input is set on the unit.
2 Press [VCR ].
VCR
3 Press [REC / OTR] to start recording.
REC/OTR
To temporarily stop recording or to resume it, press
[PAUSE p].
After the unit has been in pause mode for 5 minutes, it will
stop automatically to protect the tape and the video head from
damage.
4 Press [STOP S] when the recording is completed.
STOP
1VMN23765 / E9G05BD
EN
QUICK SETUP GUIDE
Congratulations on your purchase of a DVD Recorder with Video Cassette Recorder. This Quick Setup Guide takes you through the first-time setup with simple
instructions so you can enjoy exceptional audio and video quality as soon as possible. Please refer to the Owner's manual for detailed instructions. If you have
read your instructions and still need assistance, call ASDA helpline at 0845-300-7775. Unless stated, all procedures described use the remote control.
Recording and Playback Information
Playable Discs
Disc Logo Disc Logo
DVD-RW
DVD-Video
(VIDEO/VR mode)
DVD-R CD-DA
(VIDEO mode) (AUDIO CD)
CD-R CD-RW
(CD-DA FORMAT, (CD-DA FORMAT,
MP3, JPEG files) MP3, JPEG files)
Kodak Picture CD

Connecting to a TV

Using the Scart jack
To Aerial jack
TV
Audio/Video cable (not supplied)
Scart/RCA cable
Scart adaptor
(not supplied)
Scart cable (supplied)
(not supplied)
DVD/VCR DVD ANTENNA
AV2(DECODER) DIGITAL AUDIO S-VIDEO
AUDIO OUT OUT OUT
IN
L
OPTICAL COAXIAL
AV1(TV)
R
OUT
Using the S-VIDEO OUT jack and the AUDIO OUT jacks (only for DVD)
To Aerial jack
TV
AUDIO IN S-VIDEO IN
Audio cable
S-Video cable
(not supplied)
(not supplied)
DVD/VCR DVD ANTENNA
AV2(DECODER) DIGITAL AUDIO S-VIDEO
AUDIO OUT OUT OUT
IN
L
OPTICAL COAXIAL
AV1(TV)
R
OUT
Note for a TV with no S-Video input jack or Scart jack:
• This unit has no RF modulator, so this type of TV cannot be used.
for ADB2737BDS
Recordable Discs
Disc type Disc format Functions
Playing back, Limited
Video mode
recording, Limited editing
Playing back, Recording,
VR mode
Original / Playlist editing
Playing back, Limited
Video mode
recording, Limited editing
This unit can play back DVD discs labelled with the
following region codes only:
2
Antenna
Connect AV1 (TV) Scart jack of this unit to
the Scart jack of your TV.
Cable
Use the supplied Scart cable.
Signal
Note
• If your TV does not have a Scart jack, use a
or
commercially available Scart adaptor or Scart /
RCA cable to connect.
• Connect this unit directly to the TV. If the AV
RF cable
cables are connected to a VCR, pictures may
(supplied)
be distorted due to the copy protection
system.
RF cable
(not supplied)
Antenna If your TV has an S-Video input jack, use
S-Video and Audio cables to connect.
Cable
Signal
1 Connect S-VIDEO OUT jack of this
unit to the S-Video input jack of your
TV. Use a commercially available
or
S-Video cable.
RF cable
(supplied) 2 Connect the AUDIO OUT jacks of
this unit to the analogue Audio input
jacks of your TV. Use a commercially
available Audio cable.
RF cable
(not supplied)
EN
