Summary of Contents for Soundstream iCQ.2
- Page 1 OPERATING MANUAL LINE OUTPUT CONVERTER iCQ.2 WWW.SOUNDSTREAM.COM...
- Page 2 INSTALLATION The Power Connection (12v+ and Ground) should be made with minimum 18g wire. The 12v+ terminal should be connected to 12v positive with a 1A fuse between the iCQ.2 and the power source. The GND terminal should be connected to chasis ground and should have a ring terminal crimped.
- Page 3 A. Power Connection. 12v+ , Ground, Remote turn on are made here. Use minimum of 18g wire. iCQ.2 FEATURES Check to make sure all connections are secure. Failure to do so may result in damage to the iCQ.2 B. RCA Output to aftermarket amplifier. Maximum output voltage up to 11v.
