Summary of Contents for Australion monitor AMIS23X
- Page 1 SERVICE INFORMATION AMIS23X CROSSOVER CONTENTS: OPERATION MANUAL SCHEMATIC DIAGRAMS Australian Monitor 1 Clyde Street, Silverwater NSW 2128 Australia +61 2 9647 1411 www.australianmonitor.com.au...
- Page 2 Clever Features, Contractor Friendly AMIS23X Stereo 2-way/Mono 3-way crossover Installation Operation Manual...
- Page 3 Introduction The Australian Monitor Installation Series AMIS23X is a one rack unit, fourth order Linkwitz-Riley electronic crossover. The AMIS23X can be configured as either a stereo two way or a mono three way crossover. Featuring clip LED indication per band per channel, frequency range selector switch, CD horn boost switch &...
-
Page 4: Front Panel
Front Panel 1. Power Switch This switches the mains power “on” to the unit. 2. Channel 1 Crossover Section This section refers to the controls for channel one. This section is duplicated for channel 2. - Page 5 3. Clip LED’s These LED’s indicate that the high range or low range signals are clipping & entering distortion. Occasional flickering of these LED’s is acceptable but if the LED remains on continuously, the level should be turned down to avoid distortion.
-
Page 6: Back Panel
Back Panel 1. Channel 2 High output XLR Channel 2 XLR high frequency output/ Mono 3 way high frequency output. 2. Channel 2 High output Jack Channel 2 Jack high frequency output/ Mono 3 way high frequency output. 3. Hi Phase. This switch reverses the polarity of the high frequency output. - Page 7 8. Channel 2 Input XLR This input accepts a balanced line level signal in 2 way stereo mode. This input is not used in 3 way mono mode. 9. Channel 2 Input Jack This input accepts a balanced line level signal in 2 way stereo mode. This input is not used in 3 way mono mode.
-
Page 8: Modes Of Operation
Modes of Operation 2 Way Stereo When using the AMIS23X in 2 way stereo mode, firstly ensure the Stereo/Mono Mode switch (7) is set to the correct position (switch “out”), then simply patch the left line level output signal into input 1 (16 or 17) & the right line level output signal into input 2 (8 or 9). - Page 9 1 0 K R102 R103 LED102 LED101 2R2 1/2W 2R2 1/2W High J101 C101 POWER 104K/400JS 7815 2200uF/35V 470uF/16V AC230V POWER 250V/1A AC230/110V LC-410104 104Z/Y5V 104Z/Y5V AC110V 104Z/Y5V 7915 104Z/Y5V 104Z/Y5V 104Z/Y5V W04M ±15V Australian Monitor 2200uF/35V 470uF/16V AMIS23X Crossover 472M/400-AA...
- Page 10 104Z 104M5Z 104M5Z 104M5Z 104M5Z 104M5Z 104M5Z 100uF/25V 100uF/25V B10K IC204B R239 IC212A R225 JRC2068DD 3K92 4990R R224 R287 JRC2068DD P202 27K4 1 0 K R202 R203 LED202 LED201 2R2 1/2W 2R2 1/2W High J101 POWER Australian Monitor AMIS23X Crossover...
