CLASSIC QUARRY NOJOQUI FALLS
INSTALLATION INSTRUCTIONS
IMPORTANT – RETAIN FOR FUTURE REFERENCE – READ CAREFULLY
• Please check the contents of the boxes before attempting to assemble this product. A full checklist of parts is
in this instruction booklet. Check it very carefully. In the unlikely event that any components are damaged or
missing, please contact our customer service hotline at 407‐426‐7674, extension 2003. Do not install unit
if damaged.
• Assemble as near as possible to the point of use. Take extreme care when lifting to avoid personal
injury or damage to the product.
• Assistance in mounting your fountain is required. You will need 2-3 people.
• This product contains small items and plastic bags. Please be aware of the danger to young children and pets.
635 W. Michigan Street Orlando, FL 32805 · PH 407-426-7674 · Fax 407-426-7721
Page 1 of 8
Advertisement
Table of Contents
Summary of Contents for Bluworld CLASSIC QUARRY NOJOQUI FALLS
-
Page 1: Installation Instructions
CLASSIC QUARRY NOJOQUI FALLS INSTALLATION INSTRUCTIONS IMPORTANT – RETAIN FOR FUTURE REFERENCE – READ CAREFULLY • Please check the contents of the boxes before attempting to assemble this product. A full checklist of parts is in this instruction booklet. Check it very carefully. In the unlikely event that any components are damaged or missing, please contact our customer service hotline at 407‐426‐7674, extension 2003. - Page 2 Fountain Components Not Shown - Classic Quarry Stone, Rock Tray A. Bracket Template 1 each B. Stone Wall Bracket 1 each C. Remote 1 each D. Reservoir Wall Bracket 1 each E. Water Disperser w/ Plumbing 1 each F. Water Diffuser 1 each G.
-
Page 3: Section 1- Initial Prepping
Section 1- Initial Prepping 1. Carefully remove and inspect all your Classic Quarry components from its shipping carton. Do not operate unit if any parts are damaged. Please retain all packaging until your unit is installed correctly and running successfully. You may leave the stone on the pallet until ready to hang. 2. -
Page 4: Section 3- Mounting The Reservoir And Water Disperser
Section 3- Mounting the Reservoir and Water Disperser 1. Locate the reservoir (L) and hang it on the reservoir wall bracket (D) cleats. Make certain the reservoir (L) is well seated and centered on the bracket. 2. Place the pump assembly (H) inside the reservoir (L) close to the right edge. DO NOT plug the pump (H) into an outlet. -
Page 5: Section 5 - Setting The Disperser And Diffuser
Section 4 – Mounting the Stone Continued It is a good idea to have someone spot you on the position of the bracket and to see if you are centered or not inside the basin. Lift the stone up just past the mounting cleat and tip the top back so it is just under the disperser (E) and then tilt the bottom back towards the wall clearing the reservoir lip. -
Page 6: Section 6 - Installing The Header And Shroud
Section 6 – Installing the Header and Shroud Locate the Header and Shroud (G). Install the Header by simply sliding it into the support clips located on the stone wall bracket (B). It may be a very tight fit so you may need to pull the disperser forward to allow for the header to slide down into the clip. - Page 7 Section 4 - Operating the Waterfall 1. After mounting your fountain to the wall, fill the reservoir (L) with water (distilled water is strongly recommended). 2. The water level must be maintained at least 1/2” above the pump. If the water level drops below the pump, splashing and damage may occur.
-
Page 8: Warranty
Bluworld, then the Warranty shall be null and void. The Warranty is in effect for a period of six months beginning from the date of sale to the original retail purchaser and the rights under this Warranty are limited to the original retail purchaser.
