FLY-X3-PLUS
3-Axis Smartphone Gimbal Stabilizer
What's Included
1 x Gimbal
1 x Smartphone Clamp
1 x Battery Grip
1 x Bag with Shoulder Strap
1 x Charger & Plugs
1 x Counterweight
www.ikancorp.com
support@ikancorp.com
QUICKSTART GUIDE
© 2015 ikan Corporation. All rights Reserved
CHECKED BY
713.272.8822
Advertisement
Table of Contents
Summary of Contents for Ikan Fly-X3 Plus
- Page 1 QUICKSTART GUIDE What’s Included 1 x Gimbal 1 x Smartphone Clamp 1 x Battery Grip 1 x Bag with Shoulder Strap 1 x Charger & Plugs 1 x Counterweight CHECKED BY www.ikancorp.com 713.272.8822 support@ikancorp.com © 2015 ikan Corporation. All rights Reserved...
- Page 2 Gesture Control System. Initiate Gesture Control by tilting and panning the handle, and the camera will follow these movements smoothly. Sales: 713.272.8822 or sales@ikancorp.com | Support: 713.272.8822 or support@ikan.com | Hours: Monday thru Friday 9:00am–6:00pm CST...
-
Page 3: Specifications
SPECIFICATIONS: Smartphone Clamp Size: Fits 2.49”–3.6” (63.24 mm–91.44 mm) Accepts: iPhone 6,6 Plus, Samsung Galaxy Series and Phones up to 3.6” Wide Battery Capacity: 16.6 watt/hour Weight: 1 lb (0.46kg) Will Support Smaller Smartphones: With Optional Accessory (iPhone 4 & 5) Gesture Control System Customized High Quality Brushless DC Motors 6-Axis IMU Incorporated... - Page 4 3 - A X I S FUNCTION TILT/PITCH AXIS MOTOR Slows down the rate of tilt/pitch to stabilize against sudden and quick tilting motions. To tilt the camera angle, simply tilt the gimbal forward (away from you) or backward (toward you). CONTROL BOARD INSIDE THE BOX ROLL AXIS MOTOR...
-
Page 5: Charging Instructions
CHARGING INSTRUCTIONS: When the RED LED light blinks, please recharge battery. Remove battery from handle to check battery level. Press once to check power level and press again to power off. To charge the FLY-X3-PLUS remove the battery from the handle and make sure the switch is in the OFF position. - Page 6 GETTING STARTED WITH FLY-X3-PLUS Step 1: Remove smart phone from any cases and place in clamp. Slide your phone left or right to level as much as possible. Step 2: Adjusting the counterweight to balance it along the roll direction Based on the weight of larger phones, it may be necessary to attach the included counterweight, you may need to adjust the weight to compensate for...
- Page 7 Step 3: After leveling the phone, it is best to turn ON Camera Lens favors left your camera and orient the screen to face you. side of the cradle Keep it balanced along pitch direction. Fits 2.49”-3.6” (63.24 mm-91.41 mm) Expandable Clamp Step 4: Turn on the FLY-X3-PLUS now by pressing power...
- Page 8 HOW TO CHANGE MOUNTS: You may change the mounts on the FLY-X3-PLUS to accept to GoPro, smaller and larger smart phones. Remove the hex screws from the smart phone cradle. To remove the mount, press the clamp towards the top as indicated by the arrows.
-
Page 9: Troubleshooting
TROUBLESHOOTING: Q: The gimbal won’t stabilize and would not hold my smartphone horizontal. A: Ensure that you have charged the battery of the gimbal before operating it, and then repeat Step 2 of the Quick Start guide. Also ensure that the phone is fully placed in the holder or the gimbal will have difficulty achieving balance. -
Page 10: Optional Accessories
(Included with Gimbal) • Quick release with 2 screw attachment • Exact OEM Replacement for FLY-X3-PLUS Gimbal FX3P-SMLC FLY-X3 PLUS Small Phone Cradle Features: • Supports smaller phones like iPhone 4 & 5 FLY-X3-PLUS with • Quick release with 2 screw attachment... - Page 11 www.ikancorp.com CONDITIONS OF WARRANTY SERVICE • Free service for one year from the day of purchase if the problem is caused by manufacturing errors. • The components and maintenance service fee will be charged if the warranty period is expired. Free Service will not be Provided in the Following Situations: (*Even if the product is still within the warranty period.) •...
