FilmMe My Personal Cameraman User Manual

Specifications

My Personal Cameraman System
Weight Approximately 16 kg
Size 258 x 258 x 600 mm
Power 100 W
Camera
AXIS Q6035-E PTZ Dome Network Camera
Image Sensor
1/2.8" Progressive scan CMOS
Lens
f 4.7 – 94 mm, F1.6 – 3.5, autofocus, automatic day/night, horizontal
angle of view: 54.1° – 2.9° in HDTV 1080p, horizontal angle of view:
37.6° – 2° in HDTV 720p
Shutter speed
1/30000s – 1/4 s
Pan/Tilt/Zoom E-flip
100 preset positions, Pan 360° endless, 0.05° – 450°/s, Tilt: 220°, 0.05°
– 450°/s, 20x optical zoom and 12x digital zoom, total 240x zoom
Video
Video Compression H.264 (MPEG-4 Part 10/AVC), Motion JPEG
Resolutions HDTV 1080p 1920x1080 to 320x180
HDTV 720p 1280x720 to 320x180
Frame rate H.264 Up to 30/25 fps (60/50 Hz) in HDTV 1080p
Up to 60/50 fps (60/50 Hz) in HDTV 720p
Frame rate Motion Up to 30/25 fps (60/50 Hz) in HDTV 1080p
JPEG Up to 60/50 fps (60/50 Hz) in HDTV 720p
Image Settings Wide Dynamic Range (WDR), manual shutter time, compression, color,
brightness, sharpness, white balance, exposure control, exposure zones,
backlight compensation, fine tuning of behavior at low light
Supported Protocols IPv4/v6, HTTP, HTTPS*, SSL/TLS*, QoS Layer 3 DiffServ, FTP, CIFS/SMB,
SMTP, Bonjour, UPnPTM, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP,
RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, etc.
Casing
IP66- and NEMA 4X-rated metal casing (aluminum), acrylic (PMMA) clear
dome, sunshield (PC/ASA)
Memory 256 MB RAM, 128 MB Flash
Power High Power over Ethernet (High PoE) IEEE 802.3at, max 60 W, AXIS T8124
High PoE Midspan 1-port: 100 – 240 V AC, max 74 W
Connections RJ-45 10BASE-T/100BASE-TX PoE, IP66-rated RJ-45
Additional Memory SD/SDHC memory card slot (card not included)
Conditions of Use -40 °C to 50 °C (-40 °F to 122 °F), humidity 20 - 80% RH
Weight of the 3.5 kg (7.7 lb.)
Camera
Computer
Model IPC-D2x2-C847-H320-WB-XLM-FM4U
Processor Intel Celeron 847E 1,1GHz Dual-core
Graphics Processor HD Graphics 2000
Main Memory 4GB DDR3, 1333MHz, 64-bit
Recording 320 GB HDD
Operating System Linux Mint
Storage Locations 2 x eSATA
Display Interfaces HDMI 1.4a (max. 1920x1200), DisplayPort (max. 2560x1600)
Audio Connections Stereo line in & out, 7.1 S/PDIF
Network
Connections 2 x Ethernet 1000BaseT, WiFi 802.11b/g/n 150Mbps, two antennas
USB Connectors 2 x USB 3.0, 6 x USB 2.0
Serial Interfaces RS-232 mini-connectors, Bluetooth 3.0, mini PCIe-slot
Operation Voltage
and Power
Consumption 10...16 V / 9...19 W
Size 19 x 16 x 4 cm
