ACCESSORIES
MP-6 and MP-6P
T
his is a 19 inch, 1RU mounting panel for 6 modems. The basic
unit comes complete with all necessary mechanical hardware, with
the exception of the mounting screws necessary to attach the
panel to the rack . The un-powered version MP-6 is shown in the
picture.
The powered version, MP-6P adds the power supply and the
harness shown below. The power supply has universal AC input.
100-240Vac (LTIPS-6-2-U).
MC-OMT8B
This is a machined plastic mounting clip, used for surface mounting
the modem. The clip may be mounted to any flat surface using
two screws (user provided) or with double-sided adhesive tape
(user provided). The modem simply snaps in and out of the clip.
POWER ADAPTERS
The OMT-8B is supplied with the LTIPS-6 shown below on the
right. An optional universal cube LTIPS-6-2-U shown on the left
may also be ordered.
LTIPS-6-2-U
LTIPS-6
ORDERING INFORMATION
OMT8B-M-ST
850nm Standard version, ST connector
OMT8B-M-SC
850nm Standard version, SC connector
OMT8B-MM-ST
1300nm multimode version, ST connector
OMT8B-MM-SC
1300nm multimode version, SC connector
OMT8B-SM-ST
1300nm singlemode version, ST connector
OMT8B-SM-SC
1300nm singlemode version, SC connector
MP-6
Un-powered rack
MP-6P
Powered rack
MC-OMT8B
Mounting clip
LTIPS-6
6V DC, 300mA power cube (supplied)
LTIPS-6-2-U
6V DC, 2A Universal cube
(Input voltage 100-240Vac, 50/60Hz)
Manual Revision Record
Revision 1.0 is the original version
Revision 1.1 added new photograph, added information to
specifications, added ACCESSORIES section.
Revision 1.2 updated specifications, added SC connector
information, updated mounting section
Revision 1.3 converted manual to foldout format, corrected
accessory part numbers.
Revision 1.4 added universal power supply LTIPS-6-2-U.
P/N 98-023-0
REV. 1.4
February 24, 2006
OMT-8B
Fiber Optic Ethernet Transceiver
Operating Manual
