Summary of Contents for Rsuppoer RemoteWOL WV0101
- Page 1 RemoteWOL User Guide RemoteWOL WV0101 User Guide Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com...
- Page 2 DISCLAIMER Document Version: 1.0.2 Date: 2013.07.09 RemoteWOL Model: WV0101 Copyright ⓒ 2013 RSUPPORT Co., Ltd. All Rights Reserved The information contained in this manual and future improvements are subject to change without notice. Rsupport does not take any responsibility for any marketability nor compatibility apart from the usage described in the manual.
-
Page 3: Table Of Contents
Table of Contents Introduction of RemoteWOL ....................5 1.1. What is RemoteWOL? ..........................5 1.2. RemoteWOL Power Management ......................5 RemoteWOL Components ....................... 6 2.1. Check the product components ......................6 2.2. Name of parts ..............................6 Configure RemoteWOL Connection..................7 RemoteWOL Equipment Management ................. -
Page 4: Copyright © 2001~2013 Rsupport Co., Ltd. All Rights Reserved. Www.rsupport.com
9.1. WOL Equipment agent Detailed menu .................... 31 9.2. WOL PC agent Detailed menu ......................32 9.3. Turn ON vPro PC ............................33 10. Customer Support ........................34 Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com... -
Page 5: Introduction Of Remotewol
1. Introduction of RemoteWOL 1.1. What is RemoteWOL? Rsupport RemoteWOL (Model: WV0101) helps to turn on a PC remotely suing a PC. Wake up PC in Hibernation or in Sleep Mode and use it in remotely also before you arrive at home or office you can turn on your PC which will increase your business productivity. -
Page 6: Remotewol Components
2. RemoteWOL Components 2.1. Check the product components 2.2. Name of parts ① SYS: LED indicating the state of the power. ② WAN (front): LED indicating the modem and internet connection (FTTH) status. ③ LAN (front): LED indicating status of PC and wired connection to LAN port. ④... -
Page 7: Configure Remotewol Connection
3. Configure RemoteWOL Connection. ① Connect LAN cable to the Router and WOL equipment. ② Connect LAN cable to the Router and PC ③ Connect WOL equipment and PC to the internet through the Router. Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com... -
Page 8: Remotewol Equipment Management
4. RemoteWOL Equipment Management In the RemoteView administrator page, WOL equipment and all WOL PC on the network can be managed if they are registered. Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com... -
Page 9: Remotewol Setup Prerequisites
5. RemoteWOL Setup Prerequisites 5.1. Initializing RemoteWOL ① Press and hold the reset button on the RemoteWOL appliance for 10 seconds. The reset button can be found on the back-side of the device. The System LEDs will turn on and blink with the WAN LED turning on and blinking afterwards. -
Page 10: Remotewol Installation
6. RemoteWOL Installation 6.1. DHCP Network Environment (Obtain IP Address Automatically) The RemoteWOL appliance and PC must be on the same network. DHCP Network must be supported. ① Connect the RemoteWOL appliance to the power adapter. ② Connect the RemoteWOL WAN port to the router via LAN cable. ③... - Page 11 ⑤ Once the RemoteWOL appliance has been detected, connect to the device by clicking “Connect”. ⑥ This will bring you to the RemoteWOL Setup page. Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com...
- Page 12 ⑦ Enter network settings and register an administrative account. Set the network to: “Obtain an IP Automatically using DHCP”. ⑧ Once the network settings have been properly configured, click “Next” to continue. ⑨ Verify that the network settings are correct then click “Yes” to confirm the configuration. Copyright ©...
- Page 13 ⑩ Once the network settings have been saved, the RemoteWOL appliance will restart and the installation process will be complete. Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com...
-
Page 14: Static Ip Environment (Use The Following Ip Address)
6.2. Static IP Environment (Use the following IP address) Directly connect the computer to the RemoteWOL appliance. ① Connect the RemoteWOL appliance to the power adapter. ② Connect the RemoteWOL WAN port to the computer via LAN cable. ③ Open a web browser and type the following IP address into the URL bar: 10.10.10.1 If an error occurs during this process, navigate to http://wol.rview.com to resolve it. - Page 15 ⑥ Once the network settings have been saved, the RemoteWOL appliance will reconnect. ⑦ Connect the RemoteWOL WAN port to the router via LAN cable. ⑧ Once the network settings have been saved, the RemoteWOL appliance will restart and the installation process will be complete.. Copyright ©...
-
Page 16: Using Remotewol
7. Using RemoteWOL 7.1. Log-in/Log-out ① When RemoteWOL initial setting is all finish WOL equipment will reboot and it will connect automatically to the set IP address. The User can Log in to the account. ② To Log out, click “Log out” button at the Top-Right Corner. Copyright ©... -
Page 17: Screen Configuration
7.2. Screen Configuration Consist of RemoteView settings, network settings, user management, Turn ON PC, System Usage Log, Equipment information, Contact us. 항목 설명 RemoteView settings RemoteView Agent features used register RemoteWOL. In the RemoteView, more than one WOL PC can be managed Network Settings You can change the set network in information on RemoteWOL... -
Page 18: Setting Remoteview
7.3. Setting RemoteView 7.3.1. RemoteView agent Register/ unregister ① Click “Register Agent” button. ② Enter RemoteView user information. Select which version of RemoteView you are currently using (RemoteView Enterprise or RemoteView server). All the part marked with ‘*’ Must be entered Copyright ©... - Page 19 ③ To gain access to RemoteView agent, you have to set up the ID and PW of the agent. ④ Connection log for registered RemoteView Agent information and session server. Agent can be disconnected. Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com...
- Page 20 ⑤ Click “Unregister Agent” button ⑥ Enter RemoteView user ID/PW after that the Un-registration will be complete Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com...
-
Page 21: View Session Server Connection Log
7.3.2. View session server connection log ① Click “view session server connection log” button. ② Jump to “System usage log” page. You can view Session server connection log. Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com... -
Page 22: Network Settings
7.4. Network Settings 7.4.1. Change Network Information The set network information on WOL equipment can be changed. After modifying the Network information, DNA information, and Proxy server settings, click “Apply” button at the bottom of the page. Part marked with ‘*’ mark must be entered. Copyright ©... -
Page 23: Network Testing
7.4.2. Network Testing ① Click “Network Test” button at the bottom of the page. ② Through Network Test, WOL functionality can be confirmed if it’s working properly. Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com... -
Page 24: Proxy Lookup Program
7.4.3. Proxy Lookup program ① For Proxy server settings, select “download Proxy Lookup program” link at the right- hand side ② When running the downloaded proxy lookup program, you can search for server and port information. Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com... -
Page 25: User Management
7.5. User Management User account ID/PW can be changed. After changing ID/PW, click “Apply” Button below Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com... -
Page 26: Turn On Pc
7.6. Turn On PC 7.6.1. Search PC You can search registered WOL PC in RemoteView and ON/OFF state can be viewed. 7.6.2. Turn On PC Select WOL PC you want to turn on the power and then click “Turn On PC” button at the top-right side. -
Page 27: Using The System Log
7.7. Using the System Log In each menu, Set Log and session server’s hourly log history can be viewed. Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com... -
Page 28: Equipment Information
7.8. Equipment information 7.8.1. To download Latest firmware When you click “Download latest firmware” button, latest firmware update file will be downloaded. Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com... -
Page 29: To Update Firmware
7.8.2. To Update Firmware ① When you click “Update firmware” button, WOL equipment downloaded firmware update file will be applied. ② To select the Firmware update file click “Browse” button and to apply the firmware update file click “Upload” button. Copyright ©... -
Page 30: Contact Us
8. Contact us Rsupport Physical address information of its Branches and Website information is available Copyright © 2001~2013 RSUPPORT Co., Ltd. ALL RIGHTS RESERVED. www.rsupport.com... -
Page 31: Configuring Remoteview Administrators Page (Enterprise Type)
9. Configuring RemoteView Administrators Page (Enterprise type) 9.1. WOL Equipment agent Detailed menu Detailed menu consist of View WOL PC list, Check connection, View Log, Favourites, Change account, etc 항목 설명 View WOL PC list You can view the List of WOL PC which are registered and are on the same network as WOL equipment 전체... -
Page 32: Wol Pc Agent Detailed Menu
9.2. WOL PC agent Detailed menu Consist of Check Power state, Turn ON PC (WOL), Favourites, Move, Delete, and Registered Info. 항목 설명 Check Power State WOL PC power state (ON/OFF) can be confirmed. Turn ON PC (WOL) WOL PC can turn On the power Favourites Agent can be added to favourites. -
Page 33: Turn On Vpro Pc
9.3. Turn ON vPro PC “Turning ON vPro PC” feature can be added to detail information on the vPro PC agent. 항목 설명 Turn ON vPro PC When vPro PC power is OFF you can turn it ON through WOL equipment even if there is no turn ON PC on the same network. -
Page 34: Customer Support
Customer Support The goal of this manual is for even beginners to easy understand how to user RemoteWOL. But through this manual you believe that you did not understood or got enough information, please refer to the information below. Rsupport Homepage. If you need technical answers and more helpful information about RemoteWOL follow website below..
